GAS PRESSURE WASHER
039-8582-6
Congratulations on the purchase of your new
pressure washer. In order to ensure you have the best
possible experience please read through the following
instructions. If you require any help please contact the
customer service department at:
1-866-4SIMONIZ (1-866-474-6664
®
1-800-544-2444 (KOHLER
Engine)
Advertisement
Table of Contents
Troubleshooting
Related Manuals for Simoniz Platinum 039-8582-6
Summary of Contents for Simoniz Platinum 039-8582-6
- Page 1 GAS PRESSURE WASHER 039-8582-6 Congratulations on the purchase of your new pressure washer. In order to ensure you have the best possible experience please read through the following instructions. If you require any help please contact the customer service department at: 1-866-4SIMONIZ (1-866-474-6664 ®...
-
Page 2: Table Of Contents
Table of Contents 1. Safety Advice......................3 1.1 Definitions......................3 1.2 Safety Warnings.....................3 1.3 Intended Application....................7 2. Parts List........................8 3. Assembled Model Diagram..................10 4. Assembly Instructions....................12 5. Operating Instructions....................15 5.1 Using Spray Nozzle.....................15 5.2 Water Supply (Cold Water Only)................15 5.3 Adjusting Water Pressure..................15 5.4 Starting Pressure Washer..................15 5.5 Cleaning with Detergents..................16 5.6 Shutting Down and Cleaning Up................16... -
Page 3: Safety Advice
Safety Advice 3 TOXIC GASES 1. S AFETY DVICE Alerts against possible toxic gases which can be harmful to your health or deadly if IMPORTANT: RETAIN FOR FUTURE you are exposed to them. REFERENCE AND READ CAREFULLY! FLAMMABLE AND COMBUSTIBLE MATERIALS Do not attempt to install or operate this product Alerts against the presence of until you have read the safety instructions in... - Page 4 Safety Advice 1.2 Safety Warnings CAUTION – HOT ENGINE AND MUFFLER DANGER – WORK AREA SAFETY THE ENGINE AND MUFFLER AND EXHAUST FUMES BECOME VERY HOT DURING • Keep work area clean and well lit. Cluttered AND AFTER USE. AVOID and dark areas invite accidents.
- Page 5 Safety Advice 5 1.2 Safety Warnings CAUTION – ENGINE SAFETY • Certain components in this product and its related FLAMMABLE AND POISONOUS accessories contain chemicals which are known to MATERIALS cause cancer, birth defects, or other reproductive harm. Wash hands after handling. •...
- Page 6 Safety Advice 1.2 Safety Warnings CAUTION – SPECIFIC SAFETY ADVICE CAUTION – SPECIFIC SAFETY •This product is capable of producing high pressure ADVICE as rated in the Technical Specifications. To avoid • Avoid dangerous conditions. Always operate this rupture and injury, do not operate this product with product on dry, solid and level ground.
-
Page 7: Intended Application
•Low-Oil Auto Shut-Off: Protects the engine and refer to our website at www.simoniz.ca or prevents operating without proper lubrication. If the engine oil level goes below the recommended level, call us at 1-866-4SIMONIZ the pressure washer will shut off automatically. -
Page 8: Parts List
Parts List 2. P ARTS Ref. Description Qty. Visual Main frame Wheel with axle Handle & panel with five nozzles Spray gun with metal wand High-pressure hose 30’ (9 m) - Page 9 Parts List 9 Ref. Description Qty. Visual Knob Gun holster Hose hook Spray tip cleaner Spark plug wrench Pump breather Spare O-rings (two for high-pressure hose, one for quick-connector) Oil funnel...
-
Page 10: Assembled Model Diagram
Assembled Model Diagram 3. A SSEMBLED ODEL IAGRAM... - Page 11 Assembled Model Diagram 11 3. A SSEMBLED ODEL IAGRAM Ref. Description Ref. Description Spray nozzles(x5) Fuel tank Trigger safety lock Start cord handle Spray gun with wand Detergent dial Pump fresh water inlet 3/4” Muffler (2 cm) 3 in 1 switch Spark plug Water outlet for pressure Air filter...
-
Page 12: Assembly Instructions
Assembly Instructions 4. A SSEMBLY NSTRUCTIONS Wheel Assembly NOTE: Make sure that there is enough air in wheel before assembly. Lift the frame (A) with one hand and Frame Assembly attach one of the wheels (B) by pressing the wheel’s pin and Place the handle assembly (C) flat inserting the wheel shaft into the onto the main frame (A). - Page 13 Assembly Instructions 13 Hose Hook Assembly Attach the hose hook (H) to the back of the panel until it slides into place. Frame Assembly Rotate handle assembly (C) upright and screw the knob (F) tightly. Repeat this procedure for the opposite side.
- Page 14 Assembly Instructions Gun & Wand Assembly Assemble the spray gun with the Gun & Hose Connections metal wand. Pull back the rubber Take out air shield from pump piece to expose the threaded fitting. outlet. Connect one end of the high Then, screw the two pieces pressure hose to pump outlet, and together and move the rubber piece...
-
Page 15: Operating Instructions
Operating Instructions 15 5.3 Adjusting Water Pressure 5. O PERATING NSTRUCTIONS •The water pressure can be adjusted using the 3 in 1 switch (5) 5.1 Using Spray Nozzle • Move the switch to FAST position to increase the This pressure washer comes with five different engine speed, thus increasing the water pressure. -
Page 16: Cleaning With Detergents
Avoid working on hot use powdered soaps, which clog the injection surfaces or under direct sunlight. system. Follow the detergent manufacturer’s directions or call the Simoniz toll-free number at 1-866-4SIMONIZ (1-866-474-6664) if you have any 5.6 Shutting Down and Cleaning questions or concerns. -
Page 17: Engine Operation
Engine Operation 17 6.2 Adding Fuel 6. E NGINE PERATION WARNING 6.1 Adding/Checking Oil •Make sure there is enough fuel in the fuel tank before operating the pressure washer. IMPORTANT • Use only clean, fresh, unleaded fuel. Use a Oil has been drained for shipping. Failure to fill minimum of 87octane/87 AKI (91 RON). -
Page 18: Starting Engine
Engine Operation/Cleaning and Maintenance 6.3 Starting Engine IMPORTANT If you have problems starting the pressure washer. Call the Simoniz toll-free number at 1-866-4SIMONIZ (1-866-474-6664) and one of our customer service representatives will be glad to assist you. IMPORTANT Before each use: •... -
Page 19: Cleaning And Maintenance
Cleaning and Maintenance 19 IMPORTANT Used oil is a hazardous waste product and must be disposed of properly. Do not discard with household waste. Check with your local authorities, service centre, or Canadian Tire for safe disposal/recycling facilities. Checking Air Filter IMPORTANT Clean air filter (6) element after every 50 hours of use (every 10 hours under dusty conditions). -
Page 20: Cleaning Carburetor
Cleaning and Maintenance fuel has been completely drained. 7.3 Cleaning the Carburetor 1. Screw down the bolt on the bottom of carburetor with wrench. 2. Push the float up four to five times, then clean sediment cup with gas. NOTE: Put the sediment cup back. Be careful not to miss the O ring. -
Page 21: Winterizing Procedures
Technical Specifications 21 Cleaning and Maintenance 8. T ECHNICAL PECIFICATIONS 7.6 Winterizing Procedure • Pressure washer might be damaged if subjected to Maximum Pressure 3000 PSI freezing temperatures. This type of damage is not Rated Water Pressure 2200 PSI covered by the limited warranty. To avoid possible 9 litres per minute damages, use a small amount of antifreeze. -
Page 22: Troubleshooting
9. T OUBLESHOOTING NOTE: If your unit still is not functioning properly once you have used this guide please call the SIMONIZ toll-free service number at 1-866-4SIMONIZ (1-866-474-6664). Please do NOT bring the unit back to the store until you have called this number. -
Page 23: Trouble Shooting
Trouble Shooting 23 PROBLEM POSSIBLE CAUSE SOLUTION Nozzle tip not attached Attach required nozzle tip Turn on faucet. Ensure there are no Water supply faucet closed kinks or blockage in hose Ensure faucet is fully opened. Check Water supply pressure is to make sure water supply is a minimum 30 psi, 4 GPM No pressure, low pressure... -
Page 24: Limited Warranty
The warranty is void if the equipment is used for commercial, rental, or industrial purposes. If you have further questions, please visit our website (www.simoniz.ca) or call 1-866-4SIMONIZ (1-866-474-6664). Imported by Trileaf Distribution Trifeuil, Toronto, Canada M4S 2B8... -
Page 25: Exploded Parts Diagram 25
Exploded Parts Diagram 25 11. E XPLODED ARTS IAGRAM... - Page 26 Exploded Parts Diagram Ref. Description Qty. Ref. Description Qty. Handle foam Spring lock Handle 1-37 Injection hose (short) Front panel 2-37 Injection hose (long) Detergent tank holder Cross Pan Head Tapping Screw ST4×25 Back panel Spring gasket 5 Locknut M5 Cross Pan Head Screw M5×16 Pressure hose Washer 5...
