SCIFIT PRO2 User's Operation Manual page 9

Step 1:
Pull upward the yellow paddle handle of the seat adjustment lever, then lift and slide the seat post onto
the frame track making sure the roller guide rail is between the top and bottom wheels of the base.
Step 2:
Attach the handlebar plate to the seat post with (Qty. 4) of items #1, #2,
#3 and #4 as shown on the drawing below.
S
SCIFIT • cientific
ASSEMBLY
SWIVEL SEAT ASSEMBLY
#1
#2
#3
#4
Solutions for Fi
tness • SCIFIT •
Tools Required:
3/16 Hex wrench
1/2" Wrench or socket
6
S Solutions for Fi
cientific
Roller guide
Item #1 (x 4)
5/16-18 x 1 Socket Flat Head Screw
Item #2 (x 4)
5/16 Flat Washer
Item #3 (x 4)
5/16 Split Washer
Item #4 (x 4)
5/16 Nut
SCIFIT
tness •
