PLEASE SAVE THESE INSTRUCTIONS
INSTALLATION
TESTED and LISTED to CAN/ULC
& OPERATION
S627 AND UL 1482
Meets the Environmental Protection
GUIDE
Agency's
July 1990 Particulate Emission
Design - D
Standards
Model
FUSION

SAFETY NOTICE

If this stove is not properly installed,
a house fire may result. For your
safety, follow the installation
instructions. Contact local building
or fire officials about restrictions
and
installation
inspection
requirements in you area.
010604-16
FUSION_D1
5055.516

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Fusion and is the answer not in the manual?

Questions and answers

Related Manuals for Pacific energy Fusion

Summary of Contents for Pacific energy Fusion

  • Page 1: Safety Notice

    GUIDE Agency's July 1990 Particulate Emission Design - D Standards Model FUSION SAFETY NOTICE If this stove is not properly installed, a house fire may result. For your safety, follow the installation instructions. Contact local building or fire officials about restrictions...

  • Page 2: Table Of Contents

    Contents Safety and Maintenance ....................3 Creosote ..........................4 Formation and Need for Removal ..................... 4 Chimney Fires ........................... 4 In Case of a Chimney Fire ......................... 4 Avoiding a Chimney Fire ........................4 Stove Dimensions ......................5 Minimum Clearance to Combustibles ................5 Mobile Home Installation ....................

  • Page 3: Safety And Maintenance

    Weekly cleaning may be necessary in mild NANCE OR REPLACEMENTS. weather, even though monthly cleaning is usually enough 4. DOOR GASKETS - The gasket used by Pacific Energy in the coldest months when burning rates are higher. (7/8" medium density fiberglass rope) requires only light 11.

  • Page 4: Creosote

    Creosote In Case of a Chimney Fire 1. Prepare to evacuate to ensure everyone's safety. Have a Formation and Need for Removal well understood plan of action for evacuation. Have a place outside where everyone is to meet. When wood is burned slowly, it produces tar and other organic vapours, which combine with expelled moisture to form creo- 2.

  • Page 5: Stove Dimensions

    Stove Dimensions 22 1/4" 26 3/4" 23 1/2" 8 3/8" 36 1/4" 33 1/2" FIG. #1 Single Wall Connector - Residential Minimum 11 1/4" 13 1/2" 22" Clearance to 25" Combustibles 30" 19" 11 1/4" Double Wall Connector - Residential 4 1/4"...

  • Page 6: Mobile Home Installation

    Mobile Home Installation Warning: Under no circumstances is this heater to be installed Procedure: in a makeshift or "temporary" manner. It may be fired only after the following conditions have been met. CAUTION: THE STRUCTURAL INTEGRITY OF THE MOBILE HOME FLOOR, WALL AND CEILING/ROOF - DO NOT CONNECT THIS UNIT TO A CHIMNEY MUST BE MAINTAINED.

  • Page 7: Listed Chimney And Chimney Connector

    Spark arrestor rain cap FIG. #2 Chimney 3' (914 mm) Storm collar Minimum The chimney may incorpo- Roof flashing rate an offset. To do this safely, all sections of listed Radiation shield connector, offset elbows and chimney section must be screwed together by at least three sheet metal screws per joint.

  • Page 8: Residential Installation

    Residential Installation Warning: Under no circumstances is this heater to be installed Single-Wall Connector in a makeshift or "temporary" manner. It may be fired only after Smoke pipe must be: the following conditions have been met. as short and straight as possible, use six inch diameter, 24 gauge black pipe that is clean and in new condition.

  • Page 9: Floor Protector

    Floor Protector Combustion Air The stove may be installed on a combustible floor provided Intake or combustion air can be supplied to the stove in one of noncombustible ember protection is used. two ways. Consult your local building code or CAN/CSA- This protection must extend as follows: B365, Installation Code for Solid-Fuel-Burning Appliances and Equipment before proceeding.

  • Page 10: Operation

    4. After the fire has established itself, open the door and add a few small logs. Close door. Your PACIFIC ENERGY heater is designed for maximum 5. Begin normal operation after a good coal base exists and overall efficiency at a moderate firing rate. Overfiring is wood has charred.

  • Page 11: Restarting After Extended Or Overnight Burns

    Tilt baffle sideways to drop down and remove from firebox. Inspect gasket between baffle and supply tube. If necessary, replace with gasket #139.5 available from your Pacific Energy dealer. Re-install baffle assembly in reverse order. The two side pieces of insulation must be tight against the siderails.

  • Page 12: Optional Blower

    Temperature Optional Blower FIG. #6 Switch The optional blower kit (kit #WODC.BLOW) is equipped with a three prong power cord and may be installed at any time. Follow installation instructions supplied with the kit. Route power supply cord away from heater. Electrical rating: 115 volts A.C.-1.02 amps.

  • Page 13: Appendix A

    Appendix A Troubleshooting Problem Cause Cure Glass is Dirty 1. Wood is wet - Use dry wood 2. Turning down air control - Do not turn down until or damper too soon a) there is a good bed of coals b) the wood is charred 3.

  • Page 14: Replacement Parts

    19 ..Baffle Air Control Assembly ......SSER.214 20 ..Ash Dump Assembly ........WODC.2261 21 ..Ash Box ............FSND.4615 All parts may be ordered from your nearest Pacific Energy dealer. Contact Pacific Energy for the location of the dealer nearest you. FUSION_D1...

  • Page 15: Label

    MODEL SS II, METAL FAB MODEL 2100, AMERI-TEC MODEL HS, INDUSTRIAL CHIMNEY MODEL EXCEL 103HT, SIMPSON DURA-VENT MODEL DURA/PLUS AND DURA TECH. USE COMPONENTS SPECIFIED IN PACIFIC ENERGY INSTALLATION INSTRUCTIONS. • OPTIONAL COMPONENTS - WATER COIL (CANADA ONLY), FAN KIT #SSER.BLOW, FAN ELECTRICAL RATING: 115V, 60HZ, 80WATTS.
  • Page 16 PACIFIC ENERGY FIREPLACE PRODUCTS LTD. 2975 Allenby Rd., Duncan, BC V9L 4T8 Phone: 250-748-1184 Web site: http://www.pacificenergy.net...
