IMPORTANT:
THESE INSTRUCTIONS ARE TO
REMAIN WITH THE HOMEOWNER
SAVE THESE INSTRUCTIONS
SAFETY NOTICE: If this stove is not
properly installed, a house fi re may result.
For your safety, follow the installation
instructions. Contact local building or fi re
officials about restrictions and installation
inspection requirements in your area.
TESTED and LISTED to CAN/ULC S627
AND UL 1482
Meets the Environmental Protection
Agency's July 1990 Particulate Emission
Standards
081112-20
INSTALLATION
AND OPERATING
INSTRUCTIONS
MODEL: FUSION
SERIES: D
PRODUCT CODES:
FSND.MBKC
FSND.SSC
FUSION_D1
SERIAL #
5055.5161

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Fusion and is the answer not in the manual?

Questions and answers

Related Manuals for Pacific energy Fusion

Summary of Contents for Pacific energy Fusion

  • Page 1 For your safety, follow the installation instructions. Contact local building or fi re officials about restrictions and installation inspection requirements in your area. MODEL: FUSION SERIES: D TESTED and LISTED to CAN/ULC S627 AND UL 1482 Meets the Environmental Protection...

  • Page 2: Table Of Contents

    Contents Safety and Maintenance ..................3 Maintenance Checks ................... 4 Creosote ....................... 5 Formation and Need for Removal ..................5 Chimney Fires ........................5 In Case of a Chimney Fire ....................5 Avoiding a Chimney Fire ..................... 5 Stove Dimensions ....................6 Minimum Clearance to Combustibles ..............

  • Page 3: Safety And Maintenance

    Safety and CAUTION: - do not overtighten, tighten screws very carefully - do not clean glass when hot Maintenance - do not use abrasive cleaners on glass 6. The area where boost combustion air enters the fi rebox must be kept clear of excessive ash buildup which will block Burn wood only, dry and well seasoned.

  • Page 4: Maintenance Checks

    Maintenance Checks Check the following parts for damage such as cracks, excessive corrosion, burned out sections and excessive warping: (See website for descriptions and more detail) Weekly: - Firebrick - Visual, for cracking. - Door Gasket - sagging, placement, damage. Monthly - Brick rail tabs and brick rails.

  • Page 5: Creosote

    Creosote In Case of a Chimney Fire Prepare to evacuate to ensure everyone's safety. Have a Formation and Need for Removal well understood plan of action for evacuation. Have a place outside where everyone is to meet. When wood is burned slowly, it produces tar and other organic vapours, which combine with expelled moisture to form creosote.

  • Page 6: Stove Dimensions

    Stove Dimensions FIG. #1 27 9/16" 23 1/4" 23 3/4" 8 11/16" 36 1/2" 32 3/4" FIG. #2 SINGLE WALL CONNECTOR - RESIDENTIAL Minimum 25 3/8” 11 1/4” 13 1/2” 30 5/8” 22 3/16” 25 3/8” Clearance to 19” 11 1/4” Combustibles DOUBLE WALL CONNECTOR - RESIDENTIAL 11 1/2”...

  • Page 7: Mobile Home Installation

    Mobile Home Procedure: CAUTION: THE STRUCTURAL INTEGRITY OF THE MO- Installation BILE HOME FLOOR, WALL AND CEILING/ROOF MUST BE MAINTAINED. Warning: Under no circumstances is this heater to be installed Note: See "Combustion Air" section on page 9. in a makeshift or "temporary" manner. It may be fi red only after the following conditions have been met.

  • Page 8: Listed Chimney And Chimney Connector

    Spark arres- tor rain cap FIG. #3 Chimney 3' (914 mm) Storm collar Minimum The chimney may incorpo- Roof fl ashing rate an offset. To do this safely, all sections of listed Radiation shield connector, offset elbows and chimney section must be screwed together by at least three sheet metal screws per joint.

  • Page 9: Residential Installation

    Residential Smoke pipe must be: as short and straight as possible, use six inch diameter, 24 gauge black pipe that is clean and in new condition. Installation secured at every joint and collar with 3 sheet metal screws. installed with the crimped or male ends pointing down. This Warning: Under no circumstances is this heater to be installed will carry any liquid creosote or condensation back into the in a makeshift or "temporary"...

  • Page 10: Floor Protector

    Floor Protector Combustion Air The stove may be installed on a combustible fl oor provided Intake or combustion air can be supplied to the stove in one of noncombustible ember protection is used. two ways. Consult your local building code or CAN/CSA-B365, This protection must extend as follows: Installation Code for Solid-Fuel-Burning Appliances and Equip- ment before proceeding.

  • Page 11: Operation

    3. Ignite the paper and close the door. 4. After the fi re has established itself, open the door and add Your PACIFIC ENERGY heater is designed for maximum overall a few small logs. Close door. efficiency at a moderate fi ring rate. Overfi ring is hazardous and 5.

  • Page 12: Restarting After Extended Or Overnight Burns

    Restarting After Extended or Ash Removal Overnight Burns Caution: Ashes are to be removed only when the heater is cold. Open door and rake hot embers towards the front of the Whenever ashes get 3 to 4 inches deep in your fi rebox, and heater.

  • Page 13: Optional Blower

    Optional Blower Temperature FIG. #8 Switch The optional blower kit (kit #WODC.BLOW) is equipped with a three prong power cord and may be installed at any time. Fol- low installation instructions supplied with the kit. Route power supply cord away from heater. Electrical rating: 115 volts A.C.-1.02 amps.

  • Page 14: Troubleshooting

    Appendix A Troubleshooting Problem Cause Cure Glass is Dirty 1. Wood is wet - Use dry wood 2. Turning down air control - Do not turn down until or damper too soon a) there is a good bed of coals b) the wood is charred 3.

  • Page 15: Firebrick Installation Instructions

    Firebrick Installation Instructions/ Instructions d’Installation de Briques Réfractaires Super 27, Spectrum, Spectrum Classic, and Fusion This package contains 18 full-size fi rebricks, as well as Cet emballage contient 17 briques réfractaires, à 3 various cut-size bricks. pleine grandeur, ainsi que 4 briques coupées de diffé- If your heater came with an ash cleanout system, or rentes grandeurs.

  • Page 16: Replacement Parts

    Replacement Parts (WHEN ORDERING, INCLUDE PART NUMBER WITH DESCRIPTION) ITEM DESCRIPTION PART NO. ITEM DESCRIPTION PART NO. 1a..Side Shield, Left, Black ......FSND.4640 12a ..Brick Rail Set ........SSER.RAILSET ....Stainless Steel ..........4657 13 ..Replacement Baffle Kit ..... SSER.DBAKIT 1b..
  • Page 17 FUSION_D1 081112-20...
  • Page 18 FUSION_D1 081112-20...

  • Page 19: Label

    Label LABEL LOCATION MUR ADJACENT MUR COTE SIDE WALL ADJACENT WALL COTE SIDE FUSION_D1 081112-20...
  • Page 20 PACIFIC ENERGY FIREPLACE PRODUCTS LTD. 2975 Allenby Rd., Duncan, BC V9L 4T8 Phone: 250-748-1184 Web site: http://www.pacifi cenergy.net...
