PLEASE SAVE THESE INSTRUCTIONS
INSTALLATION
& OPERATION
GUIDE
Design - D
Models
SUPER 27
SPECTRUM
SPECTRUM CLASSIC

SAFETY NOTICE

If this stove is not properly installed,
a house fire may result. For your
safety, follow the installation
instructions. Contact local building
or fire officials about restrictions
and
installation
inspection
requirements in you area.
TESTED and LISTED to CAN/ULC S627 AND UL 1482
Meets the Environmental Protection Agency's
July 1990 Particulate Emission Standards
220206-20
SUPER-SD1
5055.201

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SUPER 27 and is the answer not in the manual?

Questions and answers

Related Manuals for Pacific energy SUPER 27

Summary of Contents for Pacific energy SUPER 27

  • Page 1: Safety Notice

    PLEASE SAVE THESE INSTRUCTIONS INSTALLATION & OPERATION GUIDE Design - D Models SUPER 27 SPECTRUM SPECTRUM CLASSIC SAFETY NOTICE If this stove is not properly installed, a house fire may result. For your safety, follow the installation instructions. Contact local building...

  • Page 2: Table Of Contents

    Troubleshooting ..........................13 Replacement Parts - Super 27 ......................14 Replacement Parts - Spectrum and Spectrum Classic ..............15 Understanding & Operating Your Pacific Energy Stove ..............16 Pedestal or Legs Installation Instructions ..................17 Ash System Assembly Instructions ....................18 Label ..............................

  • Page 3: Safety And Maintenance

    Weekly cleaning may be necessary in mild NANCE OR REPLACEMENTS. weather, even though monthly cleaning is usually enough 4. DOOR GASKETS - The gasket used by Pacific Energy in the coldest months when burning rates are higher. (7/8" medium density fiberglass rope) requires only light 11.

  • Page 4: Creosote

    Creosote In Case of a Chimney Fire 1. Prepare to evacuate to ensure everyone's safety. Have a Formation and Need for Removal well understood plan of action for evacuation. Have a place outside where everyone is to meet. When wood is burned slowly, it produces tar and other organic vapours, which combine with expelled moisture to form creo- 2.

  • Page 5: Assembly

    Super 27 - Pedestal Model Spectrum Super 27 - Leg Model Spectrum Classic Assembly - Super 27 only - Crate Removal Pedestal Kit 1) Carefully remove wood top and supports. 2) Remove plastic cover. 1) With the unit on its back and the removable cover facing up, 3) Using a 7/16"...

  • Page 6: Mobile Home Installation

    Mobile Home Installation Procedure: Warning: Under no circumstances is this heater to be installed in a makeshift or "temporary" manner. It may be fired only after the following conditions have been met. CAUTION: THE STRUCTURAL INTEGRITY OF THE MOBILE HOME FLOOR, WALL AND CEILING/ROOF - DO NOT CONNECT THIS UNIT TO A CHIMNEY MUST BE MAINTAINED.

  • Page 7: Listed Chimney And Chimney Connector

    Spark arrestor rain cap FIG. #2 Chimney 3' (914 mm) Storm collar Minimum The chimney may incorpo- Roof flashing rate an offset. To do this safely, all sections of listed Radiation shield connector, offset elbows and chimney section must be screwed together by at least three sheet metal screws per joint.

  • Page 8: Residential Installation

    Residential Installation Single-Wall Connector Warning: Under no circumstances is this heater to be installed in a makeshift or "temporary" manner. It may be fired only after Smoke pipe must be: the following conditions have been met. as short and straight as possible, use six inch diameter, 24 gauge black pipe that is clean and in new condition.

  • Page 9: Floor Protector

    Floor Protector Combustion Air The stove may be installed on a combustible floor provided Intake or combustion air can be supplied to the stove in one of noncombustible ember protection is used. two ways. Consult your local building code or CAN/CSA- This protection must extend as follows: B365, Installation Code for Solid-Fuel-Burning Appliances and Equipment before proceeding.

  • Page 10: Operation

    4. After the fire has established itself, open the door and add a few small logs. Close door. Your PACIFIC ENERGY heater is designed for maximum 5. Begin normal operation after a good coal base exists and overall efficiency at a moderate firing rate. Overfiring is wood has charred.

  • Page 11: Restarting After Extended Or Overnight Burns

    Tilt baffle sideways to drop down and remove from firebox. Inspect gasket between baffle and supply tube. If necessary, replace with gasket #139.5 available from your Pacific Energy dealer. Re-install baffle assembly in reverse order. The two side pieces of insulation must be tight against the siderails.

  • Page 12: Optional Blower

    Optional Blower The optional blower kit (kit #WODC.BLOW) is equipped with Manual: To manually operate the blower, set the rocker switch a three prong power cord and may be installed at any time. to "Man" and set the speed control to desired setting. This will Follow installation instructions supplied with the kit.

  • Page 13: Appendix A

    Appendix A Troubleshooting Problem Cause Cure Glass is Dirty 1. Wood is wet - Use dry wood 2. Turning down air control - Do not turn down until or damper too soon a) there is a good bed of coals b) the wood is charred 3.

  • Page 14: Replacement Parts - Super 27

    12c ..Firebrick - 4" x 4 1/2" x 1 1/4" (1 pc.) ....246 All parts may be ordered from your nearest Pacific Energy dealer. 12d ..Firebrick - 7 1/4" x 4 1/2" x 1 1/4" (1 pc.) .... 245 Contact Pacific Energy for the location of the dealer nearest you.

  • Page 15: Replacement Parts - Spectrum And Spectrum Classic

    14d ..Firebrick - 7 1/4" x 4 1/2" x 1 1/4" (1 pc.) .... 245 14e ..Firebrick - 9" x 4 1/2" x 1 1/4" (17 pc.) ..5096.99 All parts may be ordered from your nearest Pacific Energy dealer. Contact Pacific Energy for the location of the dealer nearest you.

  • Page 16: Understanding & Operating Your Pacific Energy Stove

    Understanding & Operating Your Pacific Energy Stove The Pacific Energy SUPER SERIES line of Active flaming takes place during the first part of the woodstoves is a culmination of years of research and burn. During this stage, heat is stored in the mass of development.

  • Page 17: Pedestal Or Legs Installation Instructions

    Super 27 and Pacific Summit Pedestal or Legs Installation Instructions Required: Pedestal Kit Leg Adapter Pedestal base Ash drawer enclosure Front cover (attached) Front cover (attached) 1/2" washers with Leg Set Legs NOTE: Optional ash dump kit should be installed prior to pedestal or leg kit assembly.

  • Page 18: Ash System Assembly Instructions

    Ash System Assembly Instructions Super 27 - Leg Model ....... (SUPR.ASHLEG) ... (SUPD.ASHLEG) Super 27 - Pedestal Model ....(SUPR.ASHPED) ..(SUPD.ASHPED) Vista - Leg Model ......(VIST.ASHLEG) Vista - Pedestal Model...... (VIST.ASHPED) Summit - Pedestal Model ....(SUMM.ASHPED) Summit - Leg Model ......(SUMM.ASHLEG)

  • Page 19: Label

    MODEL SS II, METAL FAB MODEL 2100, AMERI-TEC MODEL HS, INDUSTRIAL CHIMNEY MODEL EXCEL 103HT, SIMPSON DURA-VENT MODEL DURA/PLUS AND DURA TECH. USE COMPONENTS SPECIFIED IN PACIFIC ENERGY INSTALLATION INSTRUCTIONS. • OPTIONAL COMPONENTS - WATER COIL (CANADA ONLY), FAN KIT #SSER.BLOW, FAN ELECTRICAL RATING: 115V, 60HZ, 80WATTS.
