High power dual-band wireless 900n low profile access point
Hide thumbs Also See for XAP-1500:

Advertisement

High Power Dual-Band Wireless 900N
Use the XAP-1500 to:
Deliver Broader Wi-Fi Coverage and Eliminate Client
Device Roaming Issues with Fewer APs
Maximize Data Rates with Concurrent Dual-Band
(2.4GHz and 5GHz) Technology
Optimize VoIP, Streaming Media and Other
Demanding Applications
Create a Secure Guest Network
Simplify Wi-Fi Installation while Minimizing
Setup Time and Costs
Minimize Unsightly Cables and Equipment
Low Profi le Access Point
Simply Connected

User Guide

XAP-1500

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the XAP-1500 and is the answer not in the manual?

Questions and answers

Summary of Contents for Luxul XAP-1500

  • Page 1: User Guide

    Simply Connected User Guide XAP-1500 High Power Dual-Band Wireless 900N Low Profi le Access Point Use the XAP-1500 to: Deliver Broader Wi-Fi Coverage and Eliminate Client „ Device Roaming Issues with Fewer APs Maximize Data Rates with Concurrent Dual-Band „...
  • Page 2: Document Conventions

    No part of this publication may be modified or adapted in any way, for any purposes without permission in writing from Luxul. The material in this manual is subject to change without notice. Luxul reserves the right to make changes to any product to improve reliability, function, or design.
  • Page 3: Table Of Contents

    4.4 Hardware Installation 5 CONFIGURATION 5.1 Login 5.2 Quick Setup 5.3 Wireless 5.4 Network 5.5 Administration 5.6 Status 5.6.2 Connections 6 REGULATORY COMPLIANCE © 2014 Luxul. All Rights Reserved. Other trademarks and registered trademarks are the property of their respective owners...
  • Page 4: Introduction

    1 INTRODUCTION Congratulations on your purchase of the Luxul XAP-1500 - High Power Dual-Band Wireless Low Profile Access Point. The XAP-1500 is designed for use in residential and commercial Wi-Fi installations—delivering optimal wireless network performance. With this high powered, concurrent dual-band wireless access point, wireless devices that are compatible with 802.11a/b/g/n can sustain high data rates and improved overall...
  • Page 5: Site Preparation

    Support for Setup on iOS and „ Android Devices QoS Support „ Up to 12 SSIDs „ Firmware Upgradeable via Browser „ Certifications CE, FCC, RoHS © 2014 Luxul. All Rights Reserved. Other trademarks and registered trademarks are the property of their respective owners...
  • Page 6: Getting Started

    3.3 Safety Information To maintain the safety of users and property, follow these safety instructions: The XAP-1500 wireless access point is designed for indoor use only. DO NOT place „ this access point outdoors. If you require an outdoor access point, please consider the Luxul XAP-1040.
  • Page 7: Hardware Features And Installation

    4 HARDWARE FEATURES AND INSTALLATION 4.1 Front View The XAP-1500 has three LEDs, positioned on the side of the access point 1) Power, 2) 2.4GHz wireless activity and 3) 5GHz wireless activity. NOTE: The LEDs may be enabled or disabled through the user interface.
  • Page 8: Rear View

    XAP-1500 4.2 Rear View The back of the XAP-1500 provides two RJ-45 connections. The fi rst port is used to deliver both power and data to the access point and is labeled PoE. The second port is optional and may be used as a switch port to connect any other device to the network.
  • Page 9: Hardware Installation

    4.4.2 Mounting the Access Point on a Wall or Ceiling The XAP-1500 may be installed on a wall, ceiling or desktop (fl at surface). A separate mounting ring is included for ease of installation. The Quick Install Guide (QIG) has a mounting template to assist in positioning the AP correctly.
  • Page 10 XAP-1500 4.4.3 Connecting to the Power Source The XAP-1500 is PoE ready. Please ensure you ONLY use the PoE injector that is included in the product box. To apply power, simply connect an Ethernet cable to the PoE injec- tor (Power/Data port) and the opposite end of the Ethernet cable to the PoE port of the AP.
  • Page 11: Configuration

    5 CONFIGURATION 5.1 Login To confi gure the XAP-1500 enter the IP address of the AP into a browser. For your computer to fi nd the AP, it must be on the same subnet as the AP. The default address for the XAP-1500 is 192.168.0.16.
  • Page 12: Quick Setup

    IP Addresses to a device on the network. If DHCP is enabled on the Access Point, it will no longer use the static address set by Luxul at time of manufacturing and will request a Dynamic IP Address from the Router (sometimes referred to as the Gateway).
  • Page 13 User Guide IP Address. This field shows the IP address that is assigned to the XAP-1500. To ensure „ plug and play capability with other Luxul networking products, the IP Address is set to 192.168.0.16. If desired, the user can set this to a different static IP address. To change...
  • Page 14 To change the WPA Passphrase, simply type in the desired passphrase, click Save, then Reboot for the change to take effect. NOTE: It is recommended to use a strong Passphrase Containing: a: 14203 Minuteman Drive, Suite 201, Draper, UT 84020-1685 | luxul.com | 801-822-5450 LUX-UG-XAP-1500 Vers: 07314...
  • Page 15: Wireless

    To Disable the Wireless Radio, click the dropdown menu, select Disabled, then click Save and then Reboot for the change to take effect. © 2014 Luxul. All Rights Reserved. Other trademarks and registered trademarks are the property of their respective owners...
  • Page 16 Save and then Reboot for the change to take effect. NOTE: 11g+n 40MHZ mode will use two channels. For example, if radio is using channel 6, it would also use channel 10. a: 14203 Minuteman Drive, Suite 201, Draper, UT 84020-1685 | luxul.com | 801-822-5450 LUX-UG-XAP-1500 Vers: 07314...
  • Page 17 WEP Key: This fi eld only shows while in WEP mode. Allows the input of a 64 bit „ or 128 bit WEP key. WPA Passphrase: Sets the passphrase for WPA or WPA2 protected wireless „ network access. © 2014 Luxul. All Rights Reserved. Other trademarks and registered trademarks are the property of their respective owners...
  • Page 18: Network

    VLAN Trunking switch. All current Luxul routers (except the XBR-2300) and managed switches (except the XMS-1008P) support VLAN Trunking. a: 14203 Minuteman Drive, Suite 201, Draper, UT 84020-1685 | luxul.com | 801-822-5450 LUX-UG-XAP-1500 Vers: 07314...
  • Page 19: Administration

    Access Point. To change the password, simply enter the new password, confi rm the password, then click Save, and then Reboot for the change to take effect. © 2014 Luxul. All Rights Reserved. Other trademarks and registered trademarks are the property of their respective owners...
  • Page 20 XAP-1500 Upgrade: This page allows for the upgrade of the fi rmware on the XAP-1500. To check „ for fi rmware updates, visit www.luxul.com/support. 1. Go to the Luxul website and download the new version of fi rmware 2. Click Browse to locate and select the fi rmware fi le on your computer 3.
  • Page 21 User Guide Backup/Restore: This page is used to create a backup of the XAP-1500 confi gura- „ tion and Restore the confi guration at a later time if desired. The backup fi le can also be used to set up multiple Luxul Access Points using the same confi guration. Click Backup to save the current confi guration settings as a fi le.
  • Page 22 You can save the latest entries in the log fi le and view them through a standard viewing tool. NOTE: When the AP is rebooted all previous log messages are lost.. a: 14203 Minuteman Drive, Suite 201, Draper, UT 84020-1685 | luxul.com | 801-822-5450 LUX-UG-XAP-1500 Vers: 07314...
  • Page 23 LED Control: This page allows you to turn the LEDs on the Access Point on or off. „ Simply select enable or disable. The change will take effect immediately – no need to reboot the Access Point. © 2014 Luxul. All Rights Reserved. Other trademarks and registered trademarks are the property of their respective owners...
  • Page 24 (from 1, 2 or 3 hours) for the service to be enabled. Simply enable or disable the service. The change will take effect immediately – no need to reboot the Access Point. a: 14203 Minuteman Drive, Suite 201, Draper, UT 84020-1685 | luxul.com | 801-822-5450 LUX-UG-XAP-1500 Vers: 07314...
  • Page 25: Status

    AP including: Firmware Version, Hardware Model, Uptime, IP Address, Subnet Mask, Default Gateway, LAN MAC Address, Wireless Mode, Wireless MAC Address, Network Name (SSID), Channel Width, Channel, and type of Security © 2014 Luxul. All Rights Reserved. Other trademarks and registered trademarks are the property of their respective owners...
  • Page 26: Connections

    Safety in Hospitals: Wireless devices transmit radio frequency energy and may affect medical electrical equipment. When installed adjacent to other equipment, it is advised to verify that the adjacent equip- ment is not adversely affected. a: 14203 Minuteman Drive, Suite 201, Draper, UT 84020-1685 | luxul.com | 801-822-5450 LUX-UG-XAP-1500 Vers: 07314...
  • Page 27: Rf Exposure Guidelines

    Reorient or relocate the receiving antenna „ Increase the separation between the equipment and receiver „ © 2014 Luxul. All Rights Reserved. Other trademarks and registered trademarks are the property of their respective owners...
  • Page 28 Hereby, Luxul, 14203 Minuteman Drive, Suite 201, Draper, Utah, 84020, declares that this Luxul device is in compliance with the essential requirements and other relevant provisions of Directive 1999/5/EC. For a copy of this report send a self addressed stamped envelope to: Luxul CE, 14203 Minuteman Drive, Suite 201, Draper, Utah, 84020.
