BRADSHAW
52" Ceiling Fan Owner's Manual
Model Numbers
CF890BS00
CF890ORB00
Brushed Steel
Oil Rubbed Bronze
CF890SW00
Satin White
??.?
Net Weight:
Lbs.
Questions, problems, missing parts: Before returning to the store call
Emerson Electric Customer Service
8 a.m. - 6 p.m., Eastern, Monday-Friday
1-800-654-3545
Part No. F40BP74810000
Form No. BP7481
www.emersonfans.com
Revision: 131203
ETL Model No.: CF890
Advertisement
Table of Contents
Related Manuals for Emerson BRADSHAW CF890BS00
Summary of Contents for Emerson BRADSHAW CF890BS00
- Page 1 Oil Rubbed Bronze CF890SW00 Satin White ??.? Net Weight: Lbs. Questions, problems, missing parts: Before returning to the store call Emerson Electric Customer Service 8 a.m. - 6 p.m., Eastern, Monday-Friday 1-800-654-3545 Part No. F40BP74810000 Form No. BP7481 www.emersonfans.com Revision: 131203...
-
Page 2: Table Of Contents
Emerson Electric Co. Substitution of parts or accessories not designated for use with this product by Emerson could result in personal injury or property damage. Additional Safety Instructions for Installation WARNING: To reduce the risk of personal injury, do not 1. -
Page 3: Unpacking Instructions
Emerson Electric Co. Substitution of parts or Hanger Bracket accessories not designated for use with this product Hanger Ball/4.5” Downrod Assembly by Emerson Electric Co. could result in personal injury 50-Watt Halogen or property damage. RCFP-190 Receiver SW406 Wall Control... -
Page 4: Electrical Requirements
1. Unpacking Instructions (continued) This Manual Is Designed to Make it as Easy as Possible for You to Assemble, Install, Operate and Maintain Your Ceiling Fan Installed Wire Length Wire Size A.W.G. Tools Needed for Assembly Up to 50 ft. One Phillips head screwdriver One stepladder 50-100 ft. -
Page 5: Ceiling Fan Assembly
3. Ceiling Fan Assembly #10 - 32 x 5/8" OVAL HEAD BLADE SCREWS (3 per blade) Slide the fan blade through the blade slot in the blade BLADE housing assembly.(Figure 1). Mount the fan blade to the fan housing using three #10 - 32 x 5/8”... -
Page 6: Warning
3. Ceiling Fan Assembly (continued) #6 - 32 x 3/8" FLAT HEAD SCREWS LIGHT KIT COVER Remove one of the three #6 - 32 x 3/8” flat head screws LIGHT KIT from the light kit cover (Figure 4). Retain the screw for ASSEMBLY future installation. -
Page 7: Warning
3. Ceiling Fan Assembly (continued) Loosen setscrew in motor coupling if necessary. Separate, untwist and unkink the three 80” motor leads. Route the motor lead wires through the downrod. Align the clevis pin holes in the downrod with the holes in the motor coupling. -
Page 8: How To Hang Your Ceiling Fan
3. Ceiling Fan Assembly (continued) 3.11 DOWNROD Reinstall the hanger ball (Figure 4) on the downrod as HANGER BALL follows. Route the motor leads through the downrod. SETSCREW Position the pin through the two holes in the downrod and align the ball so the pin is captured in the groove in the top of the hanger ball. -
Page 9: Warning
4. How to Hang Your Ceiling Fan (continued) WARNING The outlet box and joist must be securely mounted and capable of supporting at least 50 lbs. Use only a U.L. outlet box listed as “Acceptable for Fan Support of OUTLET 22.7 kg. -
Page 10: How To Wire Your Ceiling Fan
4. How to Hang Your Ceiling Fan (continued) NOTE: CEILING COVER, SUPPL Y WIRES AND FAN WIRES OMITTED Carefully lift the fan and seat the hanger ball/ FOR CLARITY. downrod assembly on the hanger bracket that was just attached to the outlet box (Figure 14). Be sure the OUTLET groove in the ball is lined up with tab on the hanger bracket (Figure 13). - Page 11 Emerson Electric Co. Substitution of parts or operate fan until blades are in place. Noise and fan accessories not designated for use with this product damage could result. by Emerson Electric Co. could result in personal injury or property damage. SUPPLY WHITE WIRE RECEIVER WHITE...
-
Page 12: Final Assembly
6. Final Assembly Lift the ceiling cover up to the threaded studs and turn until studs protrude through the holes in the ceiling cover (Figure 17). CEILING COVER Secure the ceiling cover in place by sliding lockwashers THREADED STUDS (2) over the threaded studs and installing the two knurled knobs (supplied). -
Page 13: Wall Control Procedures
7. Wall Control Procedures Preset Memory Feature: Your Emerson receiver is Your Emerson Ceiling Fan/Light Control consists of wall equipped with a preset memory feature. If the AC mounted transmitter and a receiver which is mounted supply to the receiver is powered through a wall switch, under the fan ceiling cover. -
Page 14: Turning
..LIGHT Disconnect electrical power to the branch circuit at the FAN OFF BLACK ® EMERSON circuit breaker or fuse box before attempting to install the ceiling fan wall control into the outlet box. NEUTRAL GROUND RECEIVER LOCATED ON Remove faceplate and screws from existing wall control. - Page 15 7. Wall Control Procedures (continued) FAN/LIGHT WALL SCREWS (2) Before installing wall control, place wall control in “OFF” CONTROL WALL BOX mode by pushing “ON/OFF” switch to the “OFF” position..Connect one black wire of wall control to the “hot” wire. OF F Securely connect wires with wire connectors supplied (Figure 23).
- Page 16 7. Wall Control Procedures (continued) 3-WAY INSTALLATION (One fan controlled by two different wall controls) FAN/LIGHT ..(See Figures 24 and 25.) WALL CONTROL WARNING BLACK LOAD Turning off wall switch is not sufficient. To avoid TRAVELER possible electrical shock, be sure electricity is turned BLACK WIRE NEUTRAL...
- Page 17 Leave wall control in “OFF” mode until fan installation is completed..LIGHT LIGHT 7.20 FAN OFF FAN OFF EMERSON ® EMERSON ® The wall control is supplied with a white, ivory, and almond color switch covers. Choose the finish that best FAN/LIGHT FAN/LIGHT TRAVELER...
- Page 18 7. Wall Control Procedures (continued) IMPORTANT: Do not interrupt the conditioning until PROGRAMMING THE RECEIVER the fan comes to a complete stop in approximately 5 OPERATING FREQUENCY & HIGH SPEED minutes. All functions of the control will be rejected CONDITIONING OF FAN CONTROL during conditioning.
-
Page 19: Maintenance
Emerson Electric Co. Substitution of parts or accessories not designated for use with this product The use of any other control not specifically approved by Emerson Electric Co. could result in personal injury for this fan could result in fire, shock and personal or property damage. -
Page 20: Repair Parts
10. Repair Parts ETL Model No.: CF890... - Page 21 10. Repair Parts Listing Model Numbers Description CF890BS00 CF890ORB00 CF890SW00 Hanger Ball Assembly, Consisting of: 761655-17 761655-32 761655-92 Hanger Bracket — — — Hanger Ball — — — Downrod (4.5”) — — — Parts Bag Containing: 764474-1 764474 764474-1 Pin, Clevis (1) —...
-
Page 22: Trouble Shooting
11. Trouble Shooting WARNING: FOR YOUR OWN SAFETY TURN OFF POWER AT FUSE BOX OR CIRCUIT BREAKER BEFORE TROUBLE SHOOTING YOUR FAN. TROUBLE PROBABLE CAUSE SUGGESTED REMEDY 1. Fuse or circuit breaker blown. 1. Check main and branch circuit fuses or circuit 1. -
Page 23: Ceiling Fan Limited Warranty
What We Will Do To Correct Problems: If during the one (1) year warranty period the motor or any component or accessory of your Emerson Ceiling Fan is defective in materials or workmanship, or if during the expected lifetime of the Emerson Ceiling Fan (when used in accordance with the User Manual or other instructions) the motor is defective in materials or workmanship, you must contact Emerson during the applicable warranty period. - Page 24 Air Comfort Products DIVISION OF EMERSON ELECTRIC CO. 8100 W. Florissant • St. Louis, MO 63136 Questions, problems, missing parts: Before returning to the store call Emerson Electric Customer Service 8 a.m. - 6 p.m., Eastern, Monday-Friday 1-800-654-3545 www.emersonfans.com Retain this manual for future use.
