READ AND SAVE THESE INSTRUCTIONS
Ceiling Fan Owner's Manual
52" Model Numbers
CF805SBS02 -
CF805SORB02 -
CF805SWW02 -
Net Weight:
Part No. F40BP71920010
Revision: 200318
SNUGGER
Brushed Steel
Oil Rubbed Bronze
Appliance White
13.9
Lbs.
Questions, problems, missing parts: Before returning to the store
call Customer Service 8 a.m. - 6 p.m., Eastern, Monday-Friday
1-800-654-3545
www.emersonfans.com
42" Model Numbers
CF804SBS02 -
CF804SORB02 -
CF804SWW02 -
Net Weight:
Brushed Steel
Oil Rubbed Bronze
Appliance White
11.2
Lbs.
Form No. BP7192-10
U.L. Model No.: 52-CL
Advertisement
Table of Contents
Related Manuals for Emerson SNUGGER CF805SBS02
Summary of Contents for Emerson SNUGGER CF805SBS02
- Page 1 READ AND SAVE THESE INSTRUCTIONS SNUGGER Ceiling Fan Owner’s Manual 52” Model Numbers 42” Model Numbers CF805SBS02 - CF804SBS02 - Brushed Steel Brushed Steel CF805SORB02 - CF804SORB02 - Oil Rubbed Bronze Oil Rubbed Bronze CF805SWW02 - CF804SWW02 - Appliance White Appliance White 13.9 11.2...
-
Page 2: Table Of Contents
Substitution of parts or accessories not designated 2. All wiring must be in accordance with the National for use with this product by Emerson could result in Electrical Code “ANSI/NFPA 70-2017” and Local personal injury or property damage. -
Page 3: Unpacking Instructions
Mounting Plate Substitution of parts or accessories not designated Fan Housing for use with this product by Emerson could result in personal injury or property damage. Flange Sets Blade Sets Check to see that you have received the following parts: NOTE: If you are uncertain of part description, refer to exploded view illustration. -
Page 4: Electrical Requirements
1. Unpacking Instructions (Continued) This Manual Is Designed to Make it as Easy as Possible for You to Assemble, Install, Operate and Maintain Your Ceiling Fan Tools Needed for Assembly WARNING One Phillips Head Screwdriver One Stepladder Before assembling your ceiling fan, refer to section One 1/4”... -
Page 5: How To Hang Your Ceiling Fan
3. How to Hang Your Ceiling Fan CAUTION CEILING To reduce the risk of injury, install the fan so that the blades are at least 7 ft. (2.1m) above the floor (Figure 1). WARNING The outlet box and joist must be securely mounted and capable of supporting at least 50 lbs. -
Page 6: How To Wire Your Ceiling Fan
4. How to Wire Your Ceiling Fan If you feel that you do not have enough electrical WARNING wiring knowledge or experience, have your fan installed by a licensed electrician. To avoid risk of fire or shock, check to see that all connections are tight, including ground, and that no bare wire is visible at the wire connectors, except for WARNING... -
Page 7: Ceiling Fan Assembly
5. Ceiling Fan Assembly MOTOR BRACKET Once wiring is completed, lift the Motor Bracket so SLOTS (4) that the Four Threaded Studs on the Mounting Plate protrude through the Four Slots in the Motor Bracket (See Figure 7). MOUNTING Securely tighten the Four 1/4” Hex Locknuts (supplied) PLATE onto the Threaded Studs, then try to shake the Motor THREADED... -
Page 8: Using Your Ceiling Fan
6. Using Your Ceiling Fan WARNING To reduce the risk of fire or electrical shock, do NOT use this fan with any solid-state speed control device. Restore Electrical Power to the Outlet Box by turning the Electricity on at the Main Fuse Box. 3-SPEED SWITCH Connect the Wood Pendant with Chain to the 3-Speed PULL CHAIN... -
Page 9: Accessories
LED Light Fixtures Substitution of parts or accessories not designated for use with this product by Emerson could result in WARNING personal injury or property damage. The use of any other control not specifically approved for this fan could result in fire, shock and personal injury. -
Page 10: Repair Parts
10. Repair Parts 52” Part Numbers Model Number Model Number Model Number Description CF805SBS02 CF805SORB02 CF805SWW02 Switch Housing Assembly 762577-3 762577-9 762577-2 Flange Sets (set of 5) 762573-3 762573-6 762573 Blade Sets (set of 5) 765172-DC/MH 765172-DC/MO 765172-WW/BO Loose Parts Bag Containing: 762567-3 762567-1 762567-2... -
Page 11: Ceiling Fan Limited Warranty
What We Will Do To Correct Problems: If the defect is covered by this limited warranty, Emerson will repair or replace the applicable Emerson Ceiling Fan Product at no charge to You. If repair of the Emerson Ceiling Fan Product is not practical or possible within a reasonable time and no replacement Emerson Ceiling Fan Product can be provided, Emerson will refund You the actual purchase price of Your Emerson Ceiling Fan Product. - Page 12 SERIAL NUMBER: DATE CODE: The serial number of this fan can be found on the nameplate on top of the fan housing. The date code can be found on the carton and on top of the fan housing, stamped in ink on a white label. You should record this data above and keep it in a safe place for future use.
