LED Behavior

Function LED Behavior
Power Continuous Illumination
Power Unlit
Status Continuous Illumination
Status
Unlit
Status
Blinking
Internet
Continuous Illumination
Internet Unlit
Blinking
WPS
Continuous Illumination
WPS
Firmware Blinking
Upgrade
Firmware Continuous Illumination
Upgrade
Description
Normal Operation
Powered off
1. Connected to switch by
Ethernet or WiFi.
1. Powered off
2. No connection
1. Data Transmission via
WiFi or Ethernet
Connected to Internet
1. Powered off
2. No connection
WPS in progress
WPS success
Under FW upgrade
Process
Firmware successfully
upgraded
- 5 -
Remark
Top
(Blue)
Top
(Blue)
Second (Blue)
Second (Blue)
Second (Blue)
Third (Blue)
Third (Blue)
WMB SERIES
Fourth (Blue)
WMB SERIES
Fourth (Blue)
MB SERIES
Fourth (Blue)
MB SERIES
Fourth (Blue)
