- Page 1 Hardware User’s Manual Day & Night Mini Dome Network Camera...
-
Page 2: Table Of Contents
Table of Contents Before You Use This Product ................1 Regulatory Information ..................2 Chapter 1 - Package Contents ................3 Chapter 2 - Mini Dome Network Camera Overview ..........4 Chapter 3 - Device Appearance Description ............5 Chapter 4 - LED Behavior .................. 7 Chapter 5 - Installation .................. -
Page 3: Before You Use This Product
Before You Use This Product In many countries, there are laws prohibiting or restricting the use of surveillance devices. This Network Camera is a high-performance, web-ready camera which can be part of a flexible surveillance system. It is the user’s responsibility to ensure that the operation of this camera is legal before installing this unit for its intended use. -
Page 4: Regulatory Information
Regulatory Information Federal Communication Commission Interference Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. -
Page 5: Chapter 1 - Package Contents
Chapter 1 - Package Contents Please check to make sure that the product package contains all the accessories listed below. a. MD-H600Np-360 DN Series b. Product CD c. Allen Key d. Warranty Card f. Dry Bag / Double-Sided Tape e. Screw Bags(2pcs) g. -
Page 6: Chapter 2 - Mini Dome Network Camera Overview
Chapter 2 - Mini Dome Network Camera Overview The Brickcom Mini Dome Network Camera designed for outdoor use. MD series has a compact and stylish design, also provides Full HDTV video (1080p @ 30fps). IP67 certified, and IK10 vandal-proof. It is perfect for outdoor surveillance, and surveillance in buses, trains, subway cars and emergency vehicles. -
Page 7: Chapter 3 - Device Appearance Description
Chapter 3 - Device Appearance Description Micro SD/SDHC/ Reset Button SDXC Card slot TV out Connector PAL/NTSC Switch Indicator Light Sensor Screw Micro phone Hole IR LED Please refer to the Product List for the full list of optional features that are available for this product. - Page 8 < Hardware Reset > Reset Button SD Card Slot The Reset Button can be used to reboot the camera or restore it to factory default settings. If the camera experiences a problem, rebooting the camera may correct the problem. If the problem remains, please restore the camera to factory default settings and reinstall the software.
-
Page 9: Chapter 4 - Led Behavior
Chapter 4 - LED Behavior Function LED Behavior Description Remark Status Steady On Normal Operation Blue 1. Power off Status Unlit 2. Power on till System Blue setup Status Upgrading F/W Blue Internet Blinking Blinking while network Blue connection in progress Internet Unlit No connection... -
Page 10: Chapter 5 - Installation
Chapter 5 - Installation 5.1 Hardware Installation WARNING: Do not mount the camera on a soft material. The camera may fall and be damaged. 1. Use the enclosed Allen key to detach the dome cover from the camera device. As remove the cover, please be aware of the Microphone Line. 2. - Page 11 4. Drill four holes through the center of the four location holes on the sticker. 5. Hammer the four plastic anchors which are provided in the product package into the four location holes. 6. Please use the “Waterproof Tape” to wrap around the RJ45 connector, DC12V connector, USB connector (*), in order to prevent water to seep in to the connectors.
-
Page 12: Camera Connection
5.2 Camera Connection The New Mini Dome Series is DC12V and PoE compliant, so there are two options for connecting the camera to a power and Ethernet source. The camera can either be connected to a PoE-enabled switch or a non-PoE switch. a. - Page 13 c. If using the DC12V for the power Supply. The RJ45 cable will be data transmission. Complete the Installation Place the dome cover back on the camera device using the Allen Key. - 11 -...
-
Page 14: System Requirements
5.3 System Requirements Operating System: Microsoft Windows 8.1/8/7/Vista/XP/2000 Computer: IBM PC/AT Compatible CPU: Pentium 3GHz or faster Memory: 1024 MB or more Monitor: 1024 x 768 pixels or more, 24-bit True color or better Network Interface: 10/100Mbps Network interface card must be installed Web Browser: Microsoft Internet Explorer 6.0 SP2 or higher Adobe Reader:... -
Page 15: Software Installation
A. Insert the Installation CD into the CD-ROM driver. Run Auto-Run Tool directly from the CD-ROM to start the installation. When installing the Brickcom software kit for the first time, select a desired language for the interface. The available languages are listed in the scroll box. - Page 16 B. In the Install Shield Wizard dialog box, click <Next> to continue. C. Read the End-User License Agreement and check the option “I accept the terms of the license agreement”. Click <Next> to continue. - 14 -...
- Page 17 D. Select either “Complete” setup or “Custom” setup to install the system. If COMPLETE SETUP is selected: All program features will be installed into the default directory. Check the option “Complete” and then click <Next>. ii. Click <Change> to change the appointed folder where installation and program files will be stored.
- Page 18 iii. Select to create shortcuts. Click <Next> to continue. iv. The installation information will be displayed. Click <Next> to continue. - 16 -...
- Page 19 v. To launch EasyConfig or PC-NVR Standard, select the application and click <Finish>. When launching the PC-NVR program, please refer to the PC-NVR user manual. If CUSTOM SETUP is selected: This option is recommended for advanced users. It can be used to install the system to a preferred directory or to select specific program feature(s).
- Page 20 Select the features to install. Click <Next> to continue. iii. Click <Change> to change the appointed folder where installation and program files will be stored. Click <Next> to continue. - 18 -...
- Page 21 iv. Select programs to create shortcuts. Click <Next> to continue. v. The installation information will be displayed. Click <Next> to continue. - 19 -...
- Page 22 To launch EasyConfig or PC-NVR Standard, select the application and click <Finish>. When launching the PC-NVR program, please refer to the PC-NVR user manual. - 20 -...
-
Page 23: Easyconfig
C:\Program Files\Brickcom\EasyConfig unless the program was saved to a preferred directory. A. Click <Start> to continue. The program will automatically search for the camera in the intranet. NOTE - Check “Skip the hardware installation guide” to skip checking the hardware connection. - Page 24 - 22 -...
- Page 25 B. Select either “Simple Mode” or “Professional Mode” to obtain the camera’s IP settings. If “Simple Mode” is selected, EasyConfig will set up the connection automatically. If “Professional Mode” is selected, the user will need to configure the IP settings manually. C.
- Page 26 D. Enter the username and password of the camera. For first time use, the default username and password are “admin/admin.” E. For configuring the IP address settings, select either <Settings remain the same>, <Automatically obtain an IP Address (DHCP)> or <Set IP Address configuration manually>.
- Page 27 If <Set IP Address configuration manually> is selected, the following pages will be displayed. - 25 -...
- Page 28 F. When the IP address settings have been configured, the screen will either display a successful or failed connection message. If the connection failed, either try again or quit the installation. If “DHCP IP address settings” was selected, the failure page will be displayed as below: b.
- Page 29 c. If the connection was successful, the user will see the message: “Congratulations. The installation of the camera is complete.” When this window is displayed, click <PC-NVR> to start the PC-NVR program, <Live View> to view the live video from the connected IP camera, or <X> in the top right corner of the screen to close the installation window.
- Page 30 Once installation is complete, the Administrator should proceed to the next section "Accessing the Network Camera" for necessary changes and configurations. - 28 -...
