Extron electronics XPA 2002 User Manual page 27

XPA 2004 ........................... 29.0 watts (99 BTU/hr)
1/8 power
XPA 2002 ........................... 4 ohms (x2): 35.6 watts (122 BTU/hr)
XPA 2002-70V ................... 70 V (x2): 35.6 watts (122 BTU/hr)
XPA 2002-100V ................. 100 V (x2): 40.4 watts (138 BTU/hr)
XPA 2003C-70V ................. 4 ohms (x2) + 70 V: 47.4 watts (162 BTU/hr)
XPA 2003C-100V ............... 4 ohms (x2) + 100 V: 48.3 watts (165 BTU/hr)
XPA 2004 ........................... 4 ohms (x4): 46.2 watts (158 BTU/hr)
Protection ...................................... Clip limiting, thermal, short circuit, DC output
Indication ....................................... Limiter/Protect LED indicates the onset of clip limiting, thermal
Mounting
Rack mount ............................. Yes, with included mounting brackets
Enclosure type ................................ Metal
Enclosure dimensions ..................... 1.7" H x 17.4" W* x 12.0" D (1U high, full rack wide)
Product weight ............................... 9.2 lbs (4.2 kg)
Shipping weight ............................. 12 lbs (6 kg)
Vibration ........................................ ISTA 1A in carton (International Safe Transit Association)
Regulatory compliance
Safety ...................................... CE, c-UL, UL
EMI/EMC ................................. CE, CISPR 22 Class B, CISPR 24, C-tick, EN55103-1,
Environmental
XPA 2002 ........................... Complies with the appropriate requirements of CEC, EU code
All other models................. Complies with the appropriate requirements of CEC,
MTBF ............................................. 200,000 hours
Warranty ........................................ 3 years parts and labor
NOTE:
All nominal levels are at ±10%.
NOTE:
Specifications are subject to change without notice.
XTRA Full Rack Power Amplifier Series • Reference Information
8 ohms (x2): 29.4 watts (100 BTU/hr)
8 ohms (x2) + 70 V: 42.9 watts (146 BTU/hr)
8 ohms (x2) + 100 V: 45.3 watts (155 BTU/hr)
8 ohms (x4): 39.9 watts (136 BTU/hr)
cycling, short circuit, or DC output protection
(4.3 cm H x 44.2 cm W* x 30.5 cm D)
*Width excludes rack ears. 19.0" (48.3 cm) W with rack
ears.
Meets UL 60065, IEC 60065, and BSEN 60065 for A/V
equipment.
EN55103-2, FCC Class B, ICES, VCCI Class B
of conduct, RoHS, WEEE
ENERGY STAR (ENERGY STAR qualified amplifier), EU code
®
of conduct, RoHS, WEEE
22
