- Page 1 Quick Start Guide BEC 7000 R26-W Gigabit LTE Outdoor Router with Hotspot...
- Page 3 STEPS CAREFULLY. THIS QUICK START GUIDE WILL HELP YOU INSTALL THE DEVICE PROPERLY AND AVOID IMPROPER USAGE. IF YOU NEED MORE INFORMATION ON THIS SOFTWARE CONFIGURATION, PLEASE REFER TO THE USER MANUAL. INDUSTRIAL SIM IS RECOMMEND! (BEC 7000 R26-W) Package Contents ...
- Page 4 Insert the mini SIM card (2FF) with the gold contact facing down. SIM Card Slot Push the mini SIM card (2FF) inwards to eject it * Power off the BEC 7000 R26-W before inserting or removing the SIM card(s) Green Wireless connection established 2.4GHz WIFI LED...
- Page 5 7000 R26-W Gigabit LTE Outdoor Router with Hotspot PORT & LED MEANING Green RSSI greater than -69 dBm. Excellent signal condition Green Flashing Quickly RSSI from -81 to -69 dBm. Good signal condition LTE LED Orange Flashing Quickly RSSI from -99 to -81 dBm. Fair signal condition (Received Signal Strength Orange Flashing Slowly...
-
Page 6: Mounting Kit Installation
Quick Start Guide Mounting Kit Installation Mounting Kit includes: 1. Articulation Pole x 1 M8 Nut x 1 2. T-formed Bracket x 1 3. M8x40 Screw Bolt x 1 Articulation Pole x 1 4. M8 Nut x 1 M8 Washer x 1 M6 Washer x 4 5. - Page 7 7000 R26-W Gigabit LTE Outdoor Router with Hotspot Attach the Articulation Pole to the Enclosure Attach the articulation pole to the back of the BEC 7000 R26-W ODU enclosure using the supplied M6 screws, M6 spring washers and M6x16 screws which are included in the mounting kit.
- Page 8 Quick Start Guide Note: The flexible mounting kit can be adjusted in multiple angles to align with the base station for higher efficiency. ∘ 45∘ ∘ 45∘...
- Page 9 7000 R26-W Gigabit LTE Outdoor Router with Hotspot Wall or Pole Mount Installation Mounting on Wall Fix the T-formed Bracket to the wall by using wood screws and Gyprock plugs. Wood / Gyprock Plug T-formed Bracket Wood Screw Mounting on a Pole between 1.5” to 2” (38.1~50.8mm) Attach the T-formed Bracket and the W-bar to the pole then use M6x60 bolts, M6 spring washers and M6 washers to fix the mounting kit onto the pole.
- Page 10 Attach the BEC 7000 R26-W Enclosure to the Pole Attach the articulation pole (the BEC 7000 R26-W ODU enclosure) to the T-formed bracket using the supplied M8 nut, M8 spring washer, M8 washer and M8x40 screw bolts.
- Page 11 Attach the grounding wire to the BEC 7000 R26-W and tighten the screw. Position Adjustment Adjust the BEC 7000 R26-W ODU until it reaches the desire elevation and depression angle, then tight the M8 nut (see Attach the BEC 7000 R26-W Enclosure to the Pole for more information) Max. upward angle: 47∘...
- Page 12 Quick Start Guide Power Up and Initial Configuration of Your 7000 R26-W This section will instruct you on how to power up your BEC 7000 R26-W and perform setup configuration to get an internet connection. 1. Power up your BEC 7000 R26-W router...
- Page 13 7000 R26-W Gigabit LTE Outdoor Router with Hotspot Gland Rubber Body Ring Claw Sealing Step 3: 3.1: Slide ○ ○ B , and ○ C (sealing nut, claw, and rubber ring) over the Ethernet cable first 3.2. Slide and clip ○...
- Page 14 IMPORTANT: It is recommended to put the Gigabit PoE Injector on an UPS or Surge Protector. Use the supplied grounding wire to ground your BEC 7000 R26-W ODU is REQUIRED! Powering via a PoE Switch: To connect the other of RJ-45 cable from the 7000 R26-W PoE IN port to a PoE switch.
- Page 15 7000 R26-W Gigabit LTE Outdoor Router with Hotspot Step 2: Slide the SIM card with the mental contacts (gold plate) facing down to the SIM slot then push it all the way in until you hear the clicking sound. It is recommended to use an industrial-grade SIM card. Step 3: Screw the cap back tightly.
- Page 16 Quick Start Guide Step 4: Login to your BEC 7000 R26-W the 4G/LTE Wireless Outdoor Router The default IP of modem is 192.168.1.254 with subnet 255.255.255.0. Make sure the attached PC to this router is in the same subnet and has an IP address in the range between 192.168.1.1 ~ 192.168.1.253.
-
Page 17: Troubleshooting
7000 R26-W Gigabit LTE Outdoor Router with Hotspot Troubleshooting 1. None of the LEDs are on when you turn on the BEC Device. Check the connection between the adapter and the router. If the error persists, you may have a hardware problem. In this case you should contact technical support. -
Page 18: Fcc Statement
Quick Start Guide FCC Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
