Page 1: User Manual
UNO-1140/F Advantech EVA x86 SoC Fanless Box PC with 1 x LAN, 8 x Isolated User Manual... -
Page 2: Copyright Notice
No part of this man- ual may be reproduced, copied, translated or transmitted in any form or by any means without the prior written permission of Advantech Co., Ltd. Information provided in this manual is intended to be accurate and reli- able. - Page 3 Product Warranty (2 years) Advantech warrants to you, the original purchaser, that each of its prod- ucts will be free from defects in materials and workmanship for two years from the date of purchase. This warranty does not apply to any products which have been repaired or...
- Page 4 Step 1. Visit the Advantech web site at www.advantech.com/support where you can find the latest information about the product. Step 2. Contact your distributor or Advantech's customer service center if you need additional assistance. Have the following info ready: - Product name and serial number - Description of your software (OS, version, software, etc.)
- Page 5 Safety Instructions Read these safety instructions carefully. Keep this User's Manual for later reference. Disconnect this equipment from any AC outlet before cleaning. Use a damp cloth. Do not use liquid or spray detergents for clean- ing. For plug-in equipment, the power outlet socket must be located near the equipment and must be easily accessible.
- Page 6 The sound pressure level at the operator's position according to IEC 704- 1:1982 is no more than 70 dB (A). DISCLAIMER: This set of instructions is given according to IEC 704-1. Advantech disclaims all responsibility for the accuracy of any statements contained herein. Safety Precaution - Static Electricity Follow these simple precautions to protect yourself from harm and the products from damage.
-
Page 7: Table Of Contents
Contents Chapter 1 UNO-1140/F Overview........2 Introduction ............... 2 Hardware Specifications ........... 2 Safety Precautions ............. 4 UNO-1140/F Series............4 Chassis Dimensions............5 Chapter 2 Hardware Functionality ......... 8 UNO-1140/F Peripherals........... 8 COM1~COM4: RS-232/485 Interfaces ......9 2.2.1 Automatic Data Flow Control Function for RS-485 ..9 2.2.2... - Page 8 UNO-1140/F User Manual viii...
- Page 9 UNO-1140/F Overview Sections include: • Introduction • Hardware Specifications • Safety Precautions • UNO-1140/F Series • Chassis Dimensions...
-
Page 10: Chapter 1 Uno-1140/F Overview
Chapter 1 UNO-1140/F Overview 1.1 Introduction UNO-1140/F is a DIN-rail mounted Fanless Box PC, which provides several serial communication ports. With a compact size, small foot print and front accessible I/Os, UNO-1140/F is very convenient for wiring and DIN-rail installation in the control cabinet. The wide operation temperature and indus- trial serial port design makes UNO-1140/F a perfect communication gateway even in critical environments. - Page 11 Environment • Ingress Protection IP40 • Operating Temperature IEC 68 2-2 (with 100% CPU/ I/O loading) -20 ~ 75° C (-4 ~ 167° F) • Operating Humidity 20 ~ 95% (non-condensing) • Shock Protection IEC 68 2-27CompactFlash: 50 G @ wall mount, half sine, 11 ms •...
-
Page 12: Safety Precautions
1.4 UNO-1140/F Series There are two products in UNO-1140/F series listed as below: • UNO-1140: EVA SoC Fanless Box PC, 64MB RAM, 4 x COM • UNO-1140F: EVA SoC Fanless Box PC, 64MB RAM, 8 x Iso. COM... -
Page 13: Chassis Dimensions
1.5 Chassis Dimensions Figure 1.1: UNO-1140/F Chassis Dimensions... - Page 14 UNO-1140/F User Manual...
- Page 15 Hardware Functionality Sections include: •UNO-1140/F Peripherals •COM1~COM4: RS-232/485 Interfaces •COM5~COM8: RS-485 Interfaces •LAN: Ethernet Connector •Power Connector •LED Indicators •PS/2 Keyboard and Mouse Connector •Universal Serial Bus Connectors •VGA: VGA Display Connector •RESET: Reset Button...
-
Page 16: Chapter 2 Hardware Functionality
2.1 UNO-1140/F Peripherals The following figures show the connectors on UNO-1140 and UNO- 1140F. The following sections give you detailed information about func- tion of each peripheral. Figure 2.1: UNO-1140/F Front Views Figure 2.2: UNO-1140 Top View UNO-1140/F User Manual... -
Page 17: Com1~Com4: Rs-232/485 Interfaces
A.2 for pin assignments. The default setting of each port are RS-232. 2.2.1 Automatic Data Flow Control Function for RS-485 In RS-485 mode, UNO-1140/F automatically senses the direction of incoming data and switches its transmission direction accordingly. There- fore no handshaking signal (e.g. RTS signal) is necessary. This feature lets you simply and quickly build an RS-485 network with just two wires. -
Page 18: Rs-232/485 Selection
Serial Port Corresponding Jumper to Select RS-232/485 COM1 JSETCOM1 COM2 JSETCOM2 COM3 JSETCOM3 COM4 JSETCOM4 Jumper Setting for RS-232 Interface: (Default Setting) Figure 2.4: RS-232 Jumper Settings Jumper Setting for RS-485 Interfaces: Figure 2.5: RS-485 Jumper Settings UNO-1140/F User Manual... -
Page 19: Terminal Resistor Setup For Rs-485
2.2.3 Terminal Resistor Setup for RS-485 The onboard termination resistor (120 Ohm) for each COM port can be used for long distance transmission or device matching. (Default Open.) Each terminal resistor responds to different channels for RS-422/485. Usually, these resistors are needed for both ends of the communication wires and the value of the resistors should match the characteristic imped- ance of the wires used. -
Page 20: Lan: Ethernet Connector
The UNO-1140/F provides a PS/2 keyboard and PS/2 mouse connector. A 6-pin mini-DIN connector is located on the rear panel of the UNO- 1140/F. The UNO-1140/F comes with an adapter to convert from the 6- pin mini-DIN connector to two 6-pin mini-DIN connectors for PS/2 key- board and mouse connections. -
Page 21: Vga: Vga Display Connector
BIOS setup. Please refer to Appendix A.7 for its pin assignments. 2.9 VGA: VGA Display Connector The UNO-1140/F provides a VGA controller for a high resolution VGA interface. It supports VGA and VESA, up to 1280 x 1024 @ 256 color and 1024 x 768 @ 24bpp resolution and up to 16 MB share memory. - Page 22 UNO-1140/F User Manual...
- Page 23 Initial Setup Sections include: • CompactFlash Installation • Chassis Grounding • Power Connection • BIOS Setup and System Assignments • DIN-rail Mounting Setup • Wallmounting Setup...
-
Page 24: Chapter 3 Initial Setup
3.2 Chassis Grounding Figure 3.1: Chassis Grounding Connection 3.3 Power Connection Connect the UNO-1140/F to a 9 ~ 36 VDC power source. The power source can either be from a power adapter or an in-house power source. UNO-1140/F User Manual... -
Page 25: Bios Setup And System Assignments
3.5 DIN-rail Mounting Setup Please follow these steps to mount the UNO-1140/F on a DIN-rail. Screw the provided DIN-rail Kit on the rear side of UNO-1140/F as the diagram shown below. Hang the UNO-1140/F to the DIN-rail with angle of inclination about 30 degree. -
Page 26: Wallmounting Setup
3.6 Wallmounting Setup Please follow the below steps to mount the UNO-1140/F on the wall. Screw the provided Wall Mounting Kit on the rear side of UNO- 1140/F as the diagram shown below. -
Page 27: Pin Assignments
Pin Assignments This appendix shows the UNO-1140/F pin assignments •Board Connectors and Jumpers •RS-232/485 Serial Port (COM1~COM4) •RS-485 Serial Port (COM5~COM8) •Ethernet RJ-45 Connector •Power Screw Terminal •PS/2 Keyboard and Mouse Connector •USB Connector •VGA Display Connector •Clear CMOS (CMOS1) -
Page 28: Appendix A Pin Assignments
Appendix A Pin Assignments A.1 Board Connectors and Jumpers There are connectors and jumpers on the UNO-1140/F board. The follow- ing sections tell you how to configure the UNO-1140/F hardware setting. Figure A-1 and figure A-2 show the locations of UNO-1140/F connectors and jumpers. -
Page 29: Rs-232/485 Serial Port (Com1~Com4)
A.2 RS-232/485 Serial Port (COM1~COM4) Table A.2: RS-232/485 Serial Port Pin Assignments RS/232 RS-485 DATA- DATA+... -
Page 30: Rs-485 Serial Port (Com5~Com8, Uno-1140F)
Table A.3: Ethernet RJ-45 Connector Pin Assigns 10/100Base-T Signal Name XMT+ XMT- RCV+ RCV- A.5 Power Screw Terminal (CN8) Table A.4: Phoenix Power Connector Pin Assigns Signal Name VIN ( 10 ~ 36 VDC ) Field Ground UNO-1140/F User Manual... -
Page 31: Ps/2 Keyboard And Mouse Connector (Cn10)
A.6 PS/2 Keyboard and Mouse Connector (CN10) Table A.5: Table A.6: Keyboard & Mouse Connector Pin Assigns Signal Name KB DATA MS DATA KB CLOCK MS CLOCK A.7 USB Connector Table A.7: USB Connector Pin Assignments Signal Name Cable Color DATA- White DATA+... -
Page 32: Vga Display Connector
Close jumper CMOS1 (2-3) to clear CMOS. Remove jumper CMOS1 (2-3) Turn on the system. The CMOS is now cleared and BIOS is reset to its default setting. Table A.9: CMOS1 setting for Clear CMOS Configuration Function Normal ( Default) Clear CMOS UNO-1140/F User Manual...
