INSTALLATION AND OPERATION MANUAL
FVT11MAC
Single Channel Mini Video Transmitter
24VAC Transformer Isolated
The FVT11MAC video mini-transmitter supports transmission of a fixed video
signal using AM (amplitude modulation) on one multimode fiber optic cable. The
FVT11MAC video transmitter is compatible with the FVR11M, FVR10M, FVR21,
and FVR22 receivers. Installation requires no electrical or optical adjustments.
The transmitter incorporates a bi-color (Red/Green) indicating LED for monitoring
proper system operation.
The unit operates on 24VAC power.
The FVT11MAC mini unit operates as a standalone module only.
See Figures 1 – 3 for complete installation details.
INS_FVT11MAC_REV–
03/08/10
PAGE 1
