5 Troubleshooting

Q: The installed software does not seem to establish any connections
with NAVI-B-H. How do I make it work?
A: Make sure that your Pocked PC has found the "FALCOM NAVI-B-H"
Bluetooth™ device. Follow the instructions in the Connection section
to make sure that your Pocked PC has recognized the Bluetooth™ GPS
receiver properly. If so, you will need to connect with the device by
going to the Bluetooth™ Manager and tab on the on Actions button and
then "Connect to GPS_NMEA ..".
Q: I have established a Bluetooth™ connection but the NAVI-B-H
does not seem to have any GPS fix, what should I do?
A: Disconnect the NAVI-B-H from the external power supply and connect
it again. Change the location of NAVI-B-H (maybe poor signals are
being received), but in accordance with the capability of Bluetooth™
communication.
Q: The FALCOM NAVI-B-H seems to have a GPS fix, but unable to
establish a connection between the NAVI-B-H and my Pocked PC.
How can I perform a connection?
A: Go to the Bluetooth™ Manager → All devices on your Pocked PC. Tap
Actions menu and then "Remove this Device".
Next, shutdown your FALCOM NAVI-B-H by pressing the On/Off
button approx. 2 second. Then perform a soft reset on your Pocked PC.
Once your Pocked PC has finished resetting itself, go back to the
Bluetooth™ Manager screen and perform the typical setup and
connection procedures for your Bluetooth™ receiver (for help with
connection, please review the Connection section).
Finally, run the installed GPS Mapping software, select the assigned
COM Port from Bluetooth™ connectivity, set the baud rate up to
115200 bps (you may or may not need to modify the COM port setting,
it depends on your using Bluetooth™ device), and click Open Port. The
current position will appear on the GPS Mapping software.
Q: Where can I find the data-logging functionality description?
A: The data-logger functionality, can be found in a separated
documentation named "JP7-T_family_datalogger_functionality.pdf",
which is available on the Falcom website:
Downloads
This confidential document is the property of FALCOM GmbH and may not be copied or circulated without permission.
then select the JP7-T
www.falcom.de
item from the selection box.
