NAVI-S
5 How to Install & Operate NAVI-S –1(-2)
5.1 Getting Started
Step1:
Before starting the installation, please refer to the previous
chapter
Step 2:
Extend the cable and connect it to the controlled device and
power supply, the pin-out of NAVI-S is described in the table 1.
Pin
Name
1
NC
2
GND
3
RX
4
TX
5
VCC
6
NC
Table 1:
The NAVI-S supports a full duplex serial channel. All supported
variables (baud rates, data .. etc.) can be controlled and
configured by the appropriate screens in SiRFdemo software (See
chapter
directly communicate with a PC serial port.
RX
TX
This confidential document is the property of FALCOM GmbH and may not be copied or circulated without permission.
"Installation
instruction".
I/O
Colour
-
-
-
Green
I
White
O
Red
I
Yellow
-
-
Pin assignment of the interface connector
"Related
documents") or by another software. You can
This is the main receiving channel and is used to
receive software commands on the board from the
used software.
This is the main transmitting channel and is used to
output navigation and measurement data to
VERSION 1.04
Description
Not connected
Ground
Receive Data
RS232, V24
Transmit Data
RS232, V24
Power supply
Not connected
Level
-
-
+ 5 V DC
-
Page 12
