- Page 1 PECTRADYNAMICS, ERFORMANCE ISTRIBUTION MPLIFIER HPDA100-RM-A PERATING ANUAL PECTRADYNAMICS, NC • 1849 Cherry St. Unit 2 • Louisville, CO 80027 Phone: (303) 665-1852 • Fax: (303) 604-6088 www.spectradynamics.com...
- Page 2 HPDA100-RM-A Description The HPDA100-RM-A is a high performance distribution and isolation amplifier. It contains 1 module that provides five unity gain outputs. Typical cross channel isolation and reverse isolation is typically greater than 100 dB. The phase noise of the modules is exceptionally low, typically –145 dBc/Hz @ Fourier frequency of 1 Hz and –173 dBc/Hz...
-
Page 3: Safety And Preparation For Use
Service Do not attempt to service or adjust the instrument unless another person, capable of providing first aid or resuscitation, is present. Contact SDI for any questions or repairs. Operation To operate the unit, locate the AC power entry connector on the rear panel and connect the power cable. -
Page 4: The Front Panel
The Front Panel Power LED The LED is on when power is applied to unit and the unit is operating properly. Monitor LED The LED will turn on if the signal to the corresponding channel is greater than +7 dBm. SMA INPUTS There is one amplifier module that has one input and five outputs. -
Page 5: The Back Panel
The Back Panel AC POWER ENTRY MODULE The HPDA100-RM-A is configured to operate on 100 to 120 VAC. Copyright © SpectraDynamics, Inc. 2005... -
Page 6: Operation
This unit is designed to operate only with a 100 to 120 VAC power source. For conversion to a different voltage of operation contact SDI. To operate the unit, locate the power entry module on the rear of the enclosure and connect the power cord. -
Page 7: Specifications
Specifications HPDA100 Module Specifications PARAMETER CONDITIONS UNITS Max. Input Power 1 dB compression Bandwidth +/- 1 dB 80 - 120 Gain @ 100 MHz +/- 0.5 Impedance input Ohms output Return Loss input(S11) 5MHz output(S22) 5MHz Distortion +13 dBm Isolation output to output output to input Phase Noise... -
Page 8: Warranty
SpectraDynamics, Inc (SDI). SDI’s obligation and liability under this warranty is expressly limited to repairing or replacing, at SDI’s option, any product not meeting the said specifications. This warranty shall be in effect for one (1) year from the date an HPDA-100RM-A is sold by SDI.
