Summary of Contents for Advantech AIMB-C300
- Page 1 AIMB-C300 Multifunction Chassis for EmbATX motherboard User Manual...
- Page 2 Copyright Advantech Co., Ltd copyrights this documentation and the software included with this product in 2005. All rights are reserved. Advantech Co., Ltd. reserves the right to make improvements in the products described in this manual at any time without notice.
- Page 3 This device complies with the requirements in part 15of the FCC rule:Operation is subject to be following two conditions: (1)this device may not cause harmful interference (2)this device must accept any interference received, including interference that may cause undesired operation.
- Page 4 AIMB-C300 User Manual...
-
Page 5: Table Of Contents
Contents Chapter 1 General Information ........2 Introduction ............... 2 Specification..............2 Power Supply ............. 3 Table 1.1: Power Supply ............3 Dimension Diagram ............4 Figure 1.1:Dimension Diagram ........4 Chapter 2 System Setup.............6 Removing the top cover ............ 6 Figure 2.1: Remove the top cover........6 Chassis Front and Rear Sections ........ - Page 6 AIMB-C300 User Manual...
- Page 7 General Information...
-
Page 8: Chapter 1 General Information
Chapter 1 General Information 1.1 Introduction The AIMB-C300 is a industrial computer chassis designed for space-con- scious applications. Customers can expand their business without having to worry about space efficiency because the AIMB-C300 supports for Embedded ATX series industrial motherboards. Fast-growing Internet service providers and corporate enterprise customers can use the AIMB- C300 as computing platforms for their mission critical applications. -
Page 9: Power Supply
• Shock resistance: 30 G acceleration, peak to peak, 11 ms (non-operat- ing) 10 G acceleration peak to peak, 11 ms acceleration peak to peak (operating) • Vibration: 5 ~ 500 Hz, 0.5 G sine wave, and 5 ~ 500 Hz, 1 G (rms.) ran- •... -
Page 10: Dimension Diagram
1.4 Dimension Diagram Figure 1.1: Dimension Diagram AIMB-C300 User Manual... - Page 11 System Setup...
-
Page 12: Chapter 2 System Setup
PS: We assume the board has already been placed inside. Figure 2.1: Remove the top cover 2.2 Chassis Front and Rear Sections The AIMB-C300 comes in two sections: the front section and rear sec- tion. The front section includes: AIMB-C300 User Manual... -
Page 13: The Hdd Drive Bay
2.Power supply with two fans. 3.Bracket for COM port 2.3 The HDD Drive Bay The HDD drive bay of the AIMB-C300 can hold up to two hard disk. Installing disk drives 1.Remove the top cover. 2.Detach the two screws holding the HDD bay. -
Page 14: Figure 2.3:Install The Standard Drive Bay
Figure 2.3: Install the standard drive bay 2.4 The Standard Drive Bay The standard drive bay of the AIMB-C300 can hold one 3.5" FDD or Card reader (optional) and one Slim CD ROM. 1.Remove the top cover. 2.Detach the two screws holding the standard drive bay.(You could remove the power supply first, it will easier to insert drive bay). -
Page 15: Figure 2.5:Install The Standard Drive Bay
Figure 2.5: Install the standard drive bay 2.5 PCI Riser card Please follow the below installation guide to install PCI riser card into AIMB-C300. 1. 32 bit PCI riser card Install the PCI riser card to the proper location with the provided two screws.(please refer to figure 2-6) -
Page 16: System Status Indicator
Replace the failed cooling fan with a good one. Please refer to figure2-7. Figure 2.7: Cooling fans Please refer the figure 2-8 to change the filter if you find the filter is blocked with dust or other particles AIMB-C300 User Manual... -
Page 17: Figure 2.8:System Filter
Figure 2.8: System Filter 2.8 Front Panel Switches The front panel switches are used for system power and system reset. Power On/Off switch is used for switching the system on or off. The Sys- tem Reset switch re-initializes the system. This switch is similar to the hardware reset button. - Page 18 AIMB-C300 User Manual...
- Page 19 Safety Instructions...
-
Page 20: A.1 Safety Instructions
The equipment has been exposed to moisture. d. The equipment does not work well, or you cannot get it to work according to the user manual. e. The equipment has been dropped and damaged. f. The equipment has obvious signs of breakage. AIMB-C300 User Manual... - Page 21 The sound pressure level at the operator’s position according to IEC 704- 1:1982 is no more than 70dB(A). DISCLAIMER: This set of instructions is given according to IEC 704-1. Advantech disclaims all responsibility for the accuracy of any statements contained herein. 16. Any insulation on conductors inside EQUIPMENT which are con-...
- Page 22 AIMB-C300 User Manual...
