Summary of Contents for Kenyon B40508
- Page 1 www.CookWithKenyon.com 1, 2, & 3 BURNER KNOB CONTROL - NON UL O W N E R S M A N U A L Part # 145428 Revised: August 2, 2017...
-
Page 2: Table Of Contents
Please read & save Product Specifications these instructions Three Burner Models Two Burner Trimline Models One Burner Models Thank you for choosing Kenyon, the world’s leading manufacturer Cleaning and Care of specialty cooking appliances. Cleaning the Cooktop By following the instructions in this... -
Page 3: Important Safety Instructions
USER SERVICING Do not repair or replace any part of the appliance. If service ever becomes necessary, this appliance should be serviced by AUTHORIZED PERSONNEL ONLY or call KENYON Customer Care at (860)664-4906. - Page 4 DO NOT DISCARD THESE INSTRUCTIONS, KEEP THEM WITH THE KENYON COOKTOP FOR FUTURE REFERENCE.
-
Page 5: Product Specifications
Product Specifications Three Burner Models BURNER DATA - B40508 (120V) VOLTAGE DIAMETER OUTPUT IN WATTS - B40608 (120V) 120V AC Three 6.5” (165mm) 1200 each - B40509 (240V) 240V AC Three 6.5” (165mm) 1200 each - B40609 (240V) PRODUCT DIMENSIONS... -
Page 6: One Burner Models
Product Specifications One Burner Models BURNER DATA - B40517PUPS (120V) VOLTAGE DIAMETER OUTPUT IN WATTS - B40518PUPS (240V) 120V AC One 6.5” (165mm) 1200 240V AC One 6.5” (165mm) 1200 PRODUCT DIMENSIONS WIDTH DEPTH HEIGHT 12 1/2” 12” 3 1/4” 317.5mm 304.8mm 82.6mm... - Page 7 Product Specifications 12" 21 3/4" 20 1/4" 21" 3 1/4" 3 1/4” 20" 10 3/4" 18 1/16" 19 9/16" Two Burner Trimline Models Three Burner Models 12" 12 1/2" 3 1/4" 10 3/4" 11 1/2" One Burner Models...
-
Page 8: Cleaning And Care
Use Good Quality recommended cooktop cleaner (Cerama Bryte Ceramic Cooktop Cleaner). A sample Cookware is included with your Kenyon cooktop. Since cookware plays an important role in Always remove food spills, grease spatters cooking efficiency and convenience, keep in and metal rub-off from cookware. A razor blade... -
Page 9: Operation
The power setting determines how hot the burner will get and is electronically regulated which will cause the burner to switch on and Kenyon PUPS™ (Pop Up Potholder System) off as needed to maintain the selected power keep pots safe and secure using a very level. -
Page 10: Turning On/Off
Operation Turning On/Off Temperature Setting Guide Turning a Burner On SETTING USES Push the knob down and rotate either 1 Bar Melting butter and chocolate clockwise (highest) or counter-clockwise Heating delicate sauces (lowest). When the control is in any position Warming food other than Off, it may be rotated without 2 Bars... -
Page 11: Installation
The following items should be included in the breaker and rated per the specifications for the carton. If any components are missing or various models as shown in the table on damaged, call KENYON immediately. page 12. PARTS INCLUDED Kenyon... - Page 12 KENYON MAX CONNECTED POWER SUPPLY MINIMUM WIRE PART NUMBER LOAD INPUT SIZE B40508 3600 Watts 120V AC 30A 60Hz #10 AWG B40608 3600 Watts 120V AC 30A 60Hz #10 AWG B40515PUPS 2400 Watts...
-
Page 13: Countertop Preparation
Installation Countertop Preparation Please read this section prior to making cutout for cooktop. It is important to plan ahead for installation of the cooktop, keeping the following dimensions in mind. A - 13 inches maximum depth of overhead cabinets B - 36 inches is minimum height of countertop above floor C - The minimum flat countertop surface that the cooktop will rest upon must be equal to... -
Page 14: Installing The Cooktop
OVERTIGHTEN THE SCREWS. When making cut-out of countertop, radius the corner of the cutout (1/4” radius is typical), to help prevent cracking of the KENYON COOKTOP countertop. Follow the countertop manufacturer’s instructions regarding the minimum corner radius and reinforcement. Installing the Cooktop... -
Page 15: Electrical Connection
Installation Electrical Connection Final Preparations Prior to Use Before proceeding further, verify that the power supply is disconnected. Verify that Remove the plastic film from the cooktop. the appropriate electrical supply requirements Clean the cooktop before you use it for the have been met. -
Page 16: Warranty
Warranty Kenyon International, Inc (the “Company”) warrants its products in normal usage to be free of defects in materials and workmanship subject to the conditions and limitations below. Any part, which proves to be defective in normal usage during the warranty period will be repaired or replaced by the Company.
