Specifications

Type
Scanning Modes
Resolution
Scanning Speed
Scanning Area
Feeder Capacity
Paper Weight
ADF Paper Size
Duty cycle
Rubber Pad Life
Roller Life
Interface
Dimensions (L x W x H)
Weight
Voltage
Power Consumption
Power Supply
(AC/DC adapter)
Environment
48 ArtixScan DI 4020 Plus/ArtixScan DI 2020 Plus User's Manual
Flatbed with ADF scanner
Color, grayscale, and black-and-white in a single
scanning pass
Input:
48-bit color input (Approx. 281 trillion colors)
16-bit grayscale (Approx. 65,536 shades of gray)
Output:
24-bit color (Approx. 16 million colors)
8-bit grayscale (Approx. 256 shades of gray)
Flatbed: 1200 (H) x 1200 (V) dpi
ADF: 600 (H) dpi x 600 (V) dpi
• For ArtixScan DI 4020 Plus
Simplex:
40 ppm, at 200 dpi, A4/line art; grayscale; color
Duplex:
80 ipm, at 200 dpi, A4/line art; grayscale; color
• For ArtixScan DI 2020 Plus
Simplex:
30 ppm, at 200 dpi, A4/line art; grayscale; color
Duplex:
60 ipm, at 200 dpi, A4/line art; grayscale; color
Flatbed: 8.5" x 11.7" (215.9 mm x 297.2 mm)
ADF: 8.5" x 25" (215.9 mm x 635 mm)
100 sheets of copy bond paper (Unfolded)
10 to 30 lbs. (38 to 110 g/m
Min: 4.33" x 4.33" (110 mm x 110 mm)
Max: 8.5" x 25" (215.9 mm x 635 mm)
2000 pages per day
30,000 scans
150,000 scans
Hi-Speed USB (USB 2.0)
18.90" x 11.81" x 6.10"
(480 mm x 300 mm x 155 mm)
13.4 lbs. (6.1 kg)
AC 100V to 240V, 50/60 Hz, 1.5A Max (Input)
15V DC, 2.5A (Output)
38 W (Max)
Voltage Manufacturer
100V to 240V HARD
Operating temperature: 50° to 95°F (10° to 35°C)
Relative humidity: 20% to 85%
)
2
Model No.
HDAD38W101
