Replacing the Feed-Roller Assembly
1. Press the button at the top of the ADF, then move the cover of the feeder up
to see the feed-roller assembly, as indicated in the graphic below.
Feed-Roller Assembly
2. With the cover fully opened, loosen the screw on the cover with a
screwdriver, and pull out the feed-roller assembly carefully.
3. Insert and push down the new feed-roller assembly into its compartment,
making sure the feed-roller assembly snaps into place. Tighten the screw
back on the cover.
4. Make sure the feed-roller assembly is attached to the feed cover properly, then
close the feed cover.
Note: The recommended replacement point for your feed-roller assembly is after
scanning approximately 150,000 sheets through the ADF.
ArtixScan DI 4020 Plus/ArtixScan DI 2020 Plus User's Manual
45
