Connections

INPUT/OUTPUT Terminals and Connectable Main Equipment

INPUT 1, 2 terminal
Connecting the computer. (See
page 23.)
Connecting video equipment with
component output terminal (DVD
player, DTV decoder, DVD recorder
with hard disc, etc.). (See page 25.)
INPUT 4 terminal
Connecting video equipment with S-video
output terminal (VCR, DVD player, etc.).
(See page 26.)
INPUT 3 terminal
Connecting video equipment without
S-video output terminal. (See page 26.)
OUTPUT (INPUT 1, 2) terminal
Connecting the monitor when you want to
simultaneously watch the projection
image on the monitor. (See page 28.)
AUDIO INPUT 1, 2 terminal
Connecting an audio cable. (Shared
audio input terminal for INPUT 1 and
2.) (See pages 23 and 25.)
AUDIO INPUT 3, 4 terminal
Connecting an audio cable. (Shared
audio input terminal for INPUT 3 and
4.) (See page 26.)
AUDIO OUTPUT terminal
Connecting an audio cable. (Shared
audio output terminal for INPUT 1, 2 ,
3 and 4.) (See pages 28.)
RS-232C terminal
Connecting the computer
to control the projector.
(See page 27.)
USB terminal
Connecting the computer using
a USB cable. (See page 23.)
