xStack DGS-3120 Series Layer 2 Managed Stackable Gigabit Switch Hardware Installation Guide

Web Pages

When connecting to the management mode of the Switch with a Web browser, a login screen is displayed. There is no
default user name or password necessary to access the Switch's management mode.
NOTE: Be sure to configure the user name and password in the User Accounts window before
connecting the Switch to the greater network.
Below is a list of the main folders available in the Web interface:
•
System Configuration - In this section the user will be able to configure features regarding the Switch's
configuration.
•
Management - In this section the user will be able to configure features regarding the Switch's management.
•
L2 Features - In this section the user will be able to configure features regarding the Layer 2 functionality of
the Switch.
•
L3 Features - In this section the user will be able to configure features regarding the Layer 3 functionality of
the Switch.
•
QoS - In this section the user will be able to configure features regarding the Quality of Service functionality of
the Switch.
•
ACL - In this section the user will be able to configure features regarding the Access Control List functionality
of the Switch.
•
Security - In this section the user will be able to configure features regarding the Switch's security.
•
Network Application - In this section the user will be able to configure features regarding network
applications handled by the Switch.
•
OAM - In this section the user will be able to configure features regarding the Switch's operations,
administration and maintenance (OAM).
•
Monitoring - In this section the user will be able to monitor the Switch's configuration and statistics.
31
