xStack DGS-3120 Series Layer 2 Managed Stackable Gigabit Switch Hardware Installation Guide
0
1
2
3
4
•
For 802.3at capable devices, provide power allocation of 0.1 watt granularity using
LLDP method.
Class
0
1
2
3
4
Class
0
1
2
3
4
•
Follow the PSE pin out standard of Alternative A, sending out power over pins 1, 2,
3, 6 and 8 of CAT3~6A UTP cables for 802.3af devices; or CAT5e~6A UTP cables
for 802.3at devices.
•
The DGS-3120-24PC and DGS-3120-48PC works with all D-Link 802.3af and
802.3at capable devices They also works with all non-802.3af and non-802.3at
capable D-Link Access Points, IP Cameras and IP phones using the DWL-P50 PoE
adapter.
Default
Optional
Optional
Optional
Reserved
Usage Minimum power levels of output of PSE
Default 15.4W
Optional 4.0W
Optional 7.0W
Optional 15.4W
Reserved 31W
Usage Max power received by PD
Default 13.0W
Optional 3.84W
Optional 6.49W
Optional 13.0W
Reserved 25.5W
37
12.95W
3.84W
6.49W
12.95W
12.95W
