Summary of Contents for Atlona AT-SAV14
- Page 1 User Manual 1x4 S-Video Distribution Amplifier With Stereo Audio AT-SAV14 Toll free: 1-877-536-3976 www.atlona.com Local: 1-408-962-0515...
-
Page 2: Table Of Contents
5. Panel Descriptions ..........3 5.1 Front Panel ..........3 5.2 Rear Panel ..........3 6. Connection and Installation ..........3 7. Safety Information ..........4 8. Warranty ..........5 9. Atlona Product Registration ..........6 Toll free: 1-877-536-3976 www.atlona.com Local: 1-408-962-0515... -
Page 3: Introduction
S-Video/Stereo Audio application. With 1 x S-Video and Stereo Audio Input and 4 x S-Video Ste- reo Audio Outputs, the AT-SAV14 is capable of splitting signal from one source to four separate devices with compatible inputs. With a built in amplifier, this unit has the ability to boost this signal great distances, while preventing both signal loss and picture degrada¬tion. -
Page 4: Panel Descriptions
5. Power on the monitors. 2. Connect Desired source to the S-Video/Stereo Audio Input 6. Power on the source. 3. Connect S-Video/Stereo Audio Outputs to desired Displays 7. Power on AT-SAV14 4. Plug in 12V DC power supply. Toll free: 1-877-536-3976 www.atlona.com... -
Page 5: Safety Information
It may also cause damage to your AT-SAV14. Opening the product will void the warranty. Do not attempt to service the unit. Disconnect the product and contact your authorized Atlona reseller or contact Atlona directly. -
Page 6: Warranty
Atlona Technologies’ decision, either return of the price paid for the product, repair, or replacement of the product that does not meet this Limited Warranty and which is returned to Atlona Technologies with a copy of the Customer’s receipt. This Limited Warranty is void if failure of the product has resulted from accident, abuse, misapplication, or natural occurrence. -
Page 7: Atlona Product Registration
ATLONA PRODUCT REGISTRATION Thank you for purchasing this Atlona product. - We hope you enjoy it and will take an extra few moments to register your new purchase. Registration creates an ownership record if your product is lost or stolen and helps ensure you’ll receive notification of performance issues and firmware updates.
