To wire through top:
.
Mark a line distance (A) from the right of the
centerline on the underside of the cabinet. Mark the
point on this line that is
Drill a 1¼" (3.2 cm) diameter hole (B) through the
cabinet at this point.
hood
Dim
model
A
8³⁄
"
30" & 36"
8
(21.3 cm)
models
To wire through wall:
1.
Mark a line distance (A) from the right of the
centerline on the underside of the wall. Mark the point
on this line that is
" (2.2 cm) from the underside of
7
8
the cabinet. Drill a 1¼" (3.2 cm) diameter hole (B)
through the rear wall at this point.
A
A Centerline
VENTING
Choose venting exhaust discharge from the various
options listed - Style 1 - 4 that follows:
Style 1 - Recirculating Hood version
For this installation, go to "Install Range Hood
(recirculating version)" on page 13.
" (2.2 cm) from back wall.
7
8
A
B
7
from wall,
not cabinet frame
Centerline
hood
model
B
30" & 36"
models
"
7
8
(2.2 cm)
Style 2 - Cut Openings for 3¼" x 10" (8.3 cm x
.4 cm) Rectangular Vent System
Roof Venting
To make a 4" x 10½" (10.16 cm x 26.7 cm) rectangular
cutout on the underside of cabinet top and bottom:
1.
Mark lines ½" (1.3 cm) and 4¾" (12.1 cm) from the
back wall on the centerline of the underside of cabinet.
.
Mark lines 5¼" (13.3 cm) to the right and left of the
centerline on the underside of cabinet.
.
Use saber or keyhole saw to cut a rectangular opening
for vent.
4.
Repeat steps 1-3 for the underside of the top of the
" (2.2 cm)
8
cabinet.
Centerline
Dim
A
Wall Venting
8³⁄
"
8
To make a 3½" x 10½" (8.9 cm x 26.7 cm) rectangle in
(21.3 cm)
the wall:
1.
Make 2 lines by measuring ⅜" (0.9 cm) and 3⅞"
(9.8 cm) down from underside of cabinet and mark on
the centerline on the back wall.
.
Mark lines 5¼" (13.3 cm) to the right and left of the
centerline on the wall.
.
Use saber or keyhole saw to cut a rectangular opening
in the wall for the vent.
PREPARE THE LOCATION
Cabinet cutouts
*4
3
/
4
(12.1 cm)
5
1
(13.3 cm)
*From wall, not cabinet frame
Cabinet
front
"
3
8
(0.9 cm)
3
"
7
8
(9.8 cm)
5
/
"
1
4
(13.3 cm)
*
/
(1.3 cm)
1
2
5
/
1
4
(13.3 cm)
/
4
Centerline
5
/
"
1
4
(13.3 cm)
9
