LIST OF MATERIALS

Parts included in your hood
4 - 0.45 x 1.3 cm mounting screws
2 - .35 x .65 cm rectangular vent transition
mounting screws
2 - .29 x .65 cm round metal mounting plate
mounting screws
3¼" x 10" (8.3 x 25.4 cm) rectangular metal vent
system.
7" (17.8 cm) round metal mounting plate.
Parts Needed
2 - UL listed wire connectors
Wall or roof cap with damper to match vent system
Vent clamps/duct tape as required
UL listed or CSA approved ½" strain relief
Tools/Materials required
Drill
1¼" (3.0 cm) drill bit
⅛" (0.3 cm) drill bit for pilot holes
Pencil
Wire stripper or utility knife
Tape measure or ruler
Caulking gun and weatherproof
caulking compound
Flat-blade screwdriver
Phillips screwdriver
Saber or keyhole saw
For cabinets with recessed bottoms:
Two - 2" (5.1 cm) wide filler strips. Length and
thickness determined by recess dimensions.
Four flat head wood screws or machine screws
with washers and nuts (to attach filler strips).
LIST OF MATERIALS

ELECTRICAL REQUIREMENTS

Observe all governing codes and ordinances.
Ensure that the electrical installation is adequate and in
conformance with National Electrical Code, ANSI/NFPA
70 (latest edition), or CSA Standards C22.1-94, Canadian
Electrical Code, Part 1 and C22.2 No. 0-M91 (latest edi-
tion) and all local codes and ordinances.
If codes permit and a separate ground wire is used, it is
recommended that a qualified electrician determine that
the ground path is adequate.
A copy of the above code standards can be obtained
from:
National Fire Protection Association
One Batterymarch Park
Quincy, MA 02269
CSA International
8501 East Pleasant Valley Road
Cleveland, OH 44131-5575
A 120 volt, 60 Hz., AC only, 15-amp, fused electrical
circuit is required.
If the house has aluminum wiring, follow the
procedure below:
1.
Connect a section of solid copper wire to the
pigtail leads.
.
Connect the aluminum wiring to the added
section of copper wire using special co
nectors and/or tools designed and UL listed
for joining copper to aluminum.
Follow the electrical connector manufacturer's recom-
mended procedure. Aluminum/copper connection must
conform with local codes and industry accepted wiring
practices.
Wire sizes and connections must conform with
the rating of the appliance as specified on the
model/serial rating plate.
The model/serial plate is located on the left side of
the range hood.
Wire sizes must conform to the requirements of
the National Electrical Code, ANSI/NFPA 70 (la
est edition), or CSA Standards C22. 1-94, Canad
an Electrical Code, Part 1 and C22.2 No. 0-M91
(latest edition) and all local codes and ordinances.
