SECTION 2
INSTALLING THE PRINTER

Print Area

Note: The RED tape, shown in Figure 24, provides a visual indicator of the print area for each Print Unit.
Print Area
Print Area
Indicators
Indicators
Figure 24
Envelope Imager XT 4.0 Envelope Imager XT 3.0
Print Area Indicators Print Area Indicators
Figure 25
Envelope Imager XT 4.0 Print Area Shown Above
19
Envelope Imager XT3.0/XT4.0 Operations Rev. 6/15/2007
