SECTION 2
INSTALLING THE PRINTER
IMPORTANT!
The two Outer Transport Belts should be adjusted so they ride over the bottom lip of the Media Side
Guides and are positioned very close the Media Side Guides, but not rubbing against them, as shown in
Figure 17.
4. Position the Media Hold-Down Strap [2] so that it helps hold the media down, as shown in
5. If needed; turn on the vacuum assist fans.
The center belt has a vacuum assist feature that can be turned on with the Vacuum Switch located above the
motor circuit breaker, as shown in
materials.
16
Figure 17
Figure 18
Figure 19. The vacuum assist is useful when feeding smaller and lighter
Figure 19
Envelope Imager XT3.0/XT4.0 Operations Rev. 6/15/2007
Figure
2
18.
