Page 1: User Manual
K R A ME R E LE CT R O N IC S L TD . USER MANUAL MODEL: WP-120 XGA Line Receiver P/N: 2900-000335 Rev 2... -
Page 3: Table Of Contents
Defining the WP-120 XGA Line Receiver Connecting the WP-120 Wiring the TP LINE IN / LINE OUT RJ-45 Connectors Technical Specifications Figures Figure 1: WP-120 XGA Line Receiver Front Figure 2: WP-120 XGA Line Receiver Sides and Rear Figure 3: TP PINOUT WP-120 – Contents... -
Page 4: Introduction
Scan Converters and Scalers; GROUP 8: Cables and Connectors; GROUP 9: Room Connectivity; GROUP 10: Accessories and Rack Adapters and GROUP 11: Sierra Products. Congratulations on purchasing your Kramer WP-120 XGA Line Receiver, which is ideal for the following typical applications: ... -
Page 5: Getting Started
Avoid interference from neighboring electrical appliances that may adversely influence signal quality Position your Kramer WP-120 away from moisture, excessive sunlight and dust This equipment is to be used only inside a building. It may only be connected to other equipment that is installed inside a building. -
Page 6: Safety Instructions
Kramer Electronics has made arrangements with the European Advanced Recycling Network (EARN) and will cover any costs of treatment, recycling and recovery of waste Kramer Electronics branded equipment on arrival at the EARN facility. For details of Kramer’s recycling arrangements in your particular country go to our recycling pages at http://www.kramerelectronics.com/support/recycling/. -
Page 7: Overview
Overview The Kramer WP-120 wall plate is an XGA line receiver that receives an encoded CAT5 signal transmitted by a transmitter (for example, the Kramer WP-110 or PT-110), decodes it and converts it to an XGA output. In particular, the WP-120 features: ... -
Page 8: Defining The Wp-120 Xga Line Receiver
Defining the WP-120 XGA Line Receiver This section defines the WP-120. Figure 1: WP-120 XGA Line Receiver Front Feature Function XGA OUT 15-pin HD Connector Connect to the XGA acceptor... -
Page 9: Figure 2: Wp-120 Xga Line Receiver Sides And Rear
Figure 2: WP-120 XGA Line Receiver Sides and Rear Feature Function HS Switch (sync) Slide the switch down (by default, both switches are set to NORMAL) to invert the HS polarity (downgoing syncs) Slide the switch up (to NORMAL) to retain the polarity... -
Page 10: Connecting The Wp-120
Connect the wire labeled “+” to the +12V pin, and the wire labeled “–” to the GND pin. 3. Insert the WP-120 directly into the wall box opening, and then mount the front panel securely using the screws. -
Page 11: Wiring The Tp Line In / Line Out Rj-45 Connectors
This section defines the TP pinout, using a straight pin-to-pin cable with RJ-45 connectors. Figure 3: TP PINOUT EIA /TIA 568B Wire Color Orange / White Orange Green / White Blue Blue / White Green Brown / White Brown WP-120 - Connecting the WP-120... -
Page 12: Technical Specifications
UK and most of Europe: 8.6cm x 3.8cm x 8.6cm (3.39" x 1.5" x 3.39", W, D, H) WEIGHT: 0.14kg (0.31lbs) approx. ACCESSORIES: Power supply RK−121WP 19" rack adapter OPTION: Specifications are subject to change without notice at http://www.kramerelectronics.com WP-120 - Technical Specifications... - Page 14 For the latest information on our products and a list of Kramer distributors, visit our Web site where updates to this user manual may be found. We welcome your questions, comments, and feedback. Web site: www.kramerelectronics.com E-mail: info@kramerel.com SAFETY WARNING...
