Installing Handset Batteries - Samsung SP-R5200 User Manual

Installing Handset Batteries

The handset uses the two AA size rechargeable Ni-MH
batteries supplied.
1. Slide the battery cover in the direction of the arrow, then lift it
off.
2. Remove old batteries if any, then insert new batteries observing
correct polarity ( + , - ). Reversing the orientation may
damage the handset.
12
Digital Cordless Telephone
3. Replace the battery cover. Make sure that the cover is hooked
in place.
4. Slide the cover up until it snaps shut.
Notes:
• The batteries need to be replaced if they do not recover their
full storage capacity after recharging.
• When replacing batteries, always use good quality Ni-MH
rechargeable AA size batteries. For details, see 'Specifications'
on page 50. Never use other batteries or conventional alkaline
batteries.
Digital Cordless Telephone
13
