Dynamix HP-30 Coax User Manual

Dynamix HP-30 Coax User Manual

128 mbps hpna 3.0 over coax ethernet bridge

Table Of Contents

Table of Contents

Advertisement

Quick Links

Download this manual

D

Y

N

A

D

Y

N

A

H

P

N

A

H

P

N

A

M

I

X

H

M

I

X

H

1

2

8

1

2

8

3

.

0

o

v

e

r

C

o

3

.

0

o

v

e

r

C

o

U

s

e

r

'

s

U

s

e

r

'

s

P

-

3

0

P

-

3

0

M

b

p

s

M

b

p

s

a

x

E

t

h

e

r

n

e

a

x

E

t

h

e

r

n

e

G

u

i

d

e

G

u

i

d

e

C

O

A

X

C

O

A

X

t

B

r

i

d

g

e

t

B

r

i

d

g

e

Table of Contents

Advertisement

Table of Contents

Need help?

Need help?

Do you have a question about the Dynamix HP-30 Coax and is the answer not in the manual?

Questions and answers

Summary of Contents for Dynamix Dynamix HP-30 Coax

Page 1 ’ ’...
Page 2 It is designed to operate on the coaxial TV cable installed in homes. Dynamix HP-30 Coax enables You to set-up your Private Network at Home with your Existing Coaxial Cable. No additional Network wiring is necessary. You may just Find a Coax Connector in the wall, put the coaxial plug into the connector, you can then be ready to access the broadband Internet.
Page 3: Hardware Installation
HARDWARE INSTALLATION Parts Names and Functions LED Indicators on the Front Panel...
Page 4 Ports on the Rear Panel Essential Hardwares...
Page 5 Hardware Connections 1. Select a convenient location for the bridge near the PC or Ethernet device to which it will be connected. The bridge should be kept away from excessive heat. 2. Using one coaxial cable to connect the HCNA port to F-Type connector on the wall. Using another coaxial cable to connect the other F-type TV port to TV set.
Page 6 The figure above shows how to connect an xDSL modem to a home coaxial cable network. Follow the same steps to connect any Ethernet device such as a HUB or printer, to a coaxial cable network. Now you should have connected the LAN port, HCNA port and the DC5V port to the appropriate devices or lines.
Page 7: Specifications
SPECIFICATIONS Standards IEEE 802.3 10BaseT Ethernet compliant IEEE 802.3u 100BaseT Fast Ethernet compliant HomePNA 3.0 over Coax (HCNA) compliant Data Rates HCNA: 128 Mbps Ethernet: 10/100 Mbps Distances HCNA : 1200 meter maximum between the two farthest nodes on LAN Ethernet: 100 meter maximum Power Consumption: 5V DC IN, Less than 4 watt...

This manual is also suitable for:

Hp-30 coax
