SMD 101 • Setup Guide (Continued)

Connecting to Streams Without SAP Announcements

For a source that is not configured for SAP announcements (such as IP cameras), the RTSP (pull) stream URI is entered directly

in the Source: field of the SMD 101 player controls. The URI prefix (

method.

To connect the SMD 101 to a stream using the destination port of the encoder, use the following template:

udp://@:<destination port>

For example, to connect to the SME 100 stream in figure 6, enter the following URI in the SMD 101 Source field (see

udp://@:60000

The SMD 101 also supports the URI formats:

ts/rtp://192.168.254.254@192.168.254.254:60000

and

ts/rtp://@192.168.254.254:60000

HTTP Connection to an SME 100

To connect to RTSP streams over HTTP, use the following templates.

For unicast streams, the URI format is:

http://<sme_ip_adr>/web/output1.sdp.

For multicast RTP over UDP RTSP (pull) streams, the URI format is:

http://<sme_ip_adr>/web/output1/multicast.sdp.

If the encoder has an active admin password, it challenges the connection. An admin or user password is required for connection.

To play the stream, the user name and password must be embedded in the URI entered in the Source field.

For unicast streams requiring credentials, the URI format is:

http://user:password@<sme_ip_adr>/web/output1.sdp.

For multicast RTP over UDP RTSP (pull) streams requiring credentials, the URI format is:

http://user:password@<sme_ip_adr>/web/output1/multicast.sdp.

udp

in the example below) corresponds to the streaming

figure

5):
