- Page 1 D E’ LO N G HI C OO KIN G INSTALLATION and SERVICE INSTRUCTIONS USE and CARE INSTRUCTIONS D EF9 05E C E R A M I C CO O K ER distributed by DeLonghi Australia Pty Ltd DeLonghi New Zealand Ltd...
-
Page 2: Product Label
Dear Customer, Thank you for having purchased and given your preferen- ce to our product. The safety precautions and recommendations reported below are for your own safety and that of others. They will also provide a means by which to make full use of the fea- tures offered by your appliance. - Page 3 Important: This appliance is designed and manufactured solely for the coo- king of domestic (household) food and is not suitable for any non domestic application and therefore should not be used in a com- mercial environment. The appliance guarantee will be void if the appliance is used within a non domestic environment i.e.
-
Page 4: Important Precautions And Recommendations
IMPORTANT PRECAUTIONS AND RECOMMENDATIONS After having unpacked the appliance, check to ensure that it is not damaged and that the oven door closes correctly. In case of doubt, do not use it and consult your supplier or a professionally qualified technician. - Page 5 ■ Do not scratch the hob with sharp objects. Don’t use the hob as a work surface. ■ WARNING: When correctly installed, your product meets all sa- fety requirements laid down for this type of product category. However special care should be taken around the rear or the underneath of the appliance as these areas are not designed or intended to be touched and may contain sharp or rough edges, that may cause injury.
-
Page 6: Installation
INSTALLATION CAUTION: ■ This appliance must be installed in accordance with these installation instructions. ■ This appliance shall only be serviced by authorised personnel. ■ This appliance is to be installed only by an authorised person in compliance with the current electrical regulations and in observation of the instructions supplied by the manufacturer. - Page 7 Cooker overall dimensions [mm] ■ height: min 900 - max 925 Figure 1 ■ width: 900 ■ depth: 600...
-
Page 8: Fitting The Adjustable Feet
FITTING THE ADJUSTABLE FEET The adjustable feet must be fitted to the base of the cooker before use (fig. 2). Rest the rear of the cooker on a piece of the polystyrene packaging exposing the base for the fitting of the feet. Fit the no. - Page 9 ANTI-TILT BRACKET Figure 8 Important! To restrain the appliance and prevent it 900 mm 900 mm tipping accidentally, fit a bracket to its rear to fix it securely to the wall. Make 4 5 0 sure you also fit the supplied lock pin to 4 5 0 4 5 0 the anti-tilt bracket.
-
Page 10: Electrical Requirements
ELECTRICAL REQUIREMENTS ■ The appliance must be connected to the mains checking that the voltage correspon- ds to the value given in the rating plate and that the electrical cable sections can withstand the load specified on the plate. ■ A suitable disconnection switch must be incorporated in the permanent wiring, mounted and positioned to comply with the local wiring rules and regulations. -
Page 11: Locating The Area For Electrical Connection
LOCATING THE AREA FOR ELECTRICAL CONNECTION ELECTRIC CONNECTION Dotted line showing the position of the cooker when installed Area for ELECTRIC connection Figure 11... -
Page 12: Connection Of The Power Supply Cable
CONNECTION OF THE POWER SUPPLY CABLE Important! This cooker must be connected to the electricity supply only by an au- thorised person. To connect the feeder cable to the cooker it is necessary to: • Remove the two screws that hold shield “A” behind the cooker (fig. 12). •... - Page 13 Figure 12 Figure 13 230 V~ 230 V~, 240 V~ 1 2 3 4 5 N (L 230 V 3~ 230 V 3~, 240 V 3~ 1 2 3 4 5 230 V~ 230 V 3~ 230 V~, 240 V~ 230 V 3~, 240 V 3~ 400 V 3N~ 400 V 3N~, 415 V 3N~...
-
Page 14: Electric Diagram
ELECTRIC DIAGRAM Figure 15... -
Page 15: Electric Diagram Key
ELECTRIC DIAGRAM KEY P1/2/5 Hob single zones elements Hob double zone (oval) element Hob double zone element F2/3/6 Energy regulators (single zones) F4/5 Energy regulators (double zones) Oven switch Oven thermostat Oven lamp Oven programmer Cooling fan motor Oven fan motor Oven top element Oven grill element Oven bottom element... -
Page 16: Using The Oven For The First Time
USE AND CARE CAUTION: ■ This appliance must be used only for the task it has explicitly been designed for, that is for domestic cooking of foodstuffs. Any other form of usage is to be considered as inappropriate and therefore dangerous. ■... -
Page 17: Grease Filter
GREASE FILTER ■ A special screen is provided at the back of the oven to catch grease particles, mainly when meat is being roasted. ■ Clean the filter after any cooking! The grease filter can be removed for cleaning and should be washed regularly in hot soapy water (fig. -
Page 18: Control Panel
CONTROL PANEL Figure 20 Controls description Front right cooking zone control knob Rear right cooking zone control knob Central cooking zone control knob Rear left cooking zone control knob Front left cooking zone control knob Oven temperature control knob Oven function selector control knob Electronic programmer Pilot lamps: Cooking zone/s ON indicator light... - Page 19 VITROCERAMIC HOB Figure 21 VITROCERAMIC COOKING HOB “Hi-Light” single zone, Ø 180 mm 1800 W “Hi-Light” single zone, Ø 145 mm 1200 W “Hi-Light” double zone (oval), Ø 145 x 250 mm 2000/1100 W “Hi-Light” double zone, Ø 210/120 mm 2200/750 W “Hi-Light”...
-
Page 20: How To Use The Vitroceramic Hob
HOW TO USE THE VITROCERAMIC HOB The ceramic surface of the hob allows a fast transmission of heat in the vertical direction, from the heating elements underneath the ceramic glass to the pans set on it. The heat does not spread in a horizontal direction, so that the glass stays “cool” at only a few centimeters from the cooking plate. -
Page 21: Double Zone
“HI-LIGHT” DOUBLE ZONES (figs. 25, 26) ■ The heating element is formed of 2 coils of resistant material which reaches the wor- king temperature quickly. ■ This zone is controlled by a continuous energy regulator switch (fig. 24). The heat intensity can be regulated continuously from “0”... -
Page 22: Safety Hints
SAFETY HINTS Never put cooking foil or plastic materials on the ceramic surface when the hob is hot. Make sure that the hob is clean before you use it. Always ensure that the base of your saucepan is clean and dry before placing on the hob. - Page 23 RESIDUAL HEAT INDICATORS Figure 29 The hob also features no. 6 (six) warning lights which are connected to the corre- sponding plates. When the temperature of a cooking plate is above 60°C, the relevant warning light will also light up to warn of heat on the surface of the hob.
-
Page 24: Cooking Hints
Elements usage table Figure 30 Knob TYPE OF COOKING setting COOKING HINTS: Switched OFF Temperature control knob For melting operations (but- ter, chocolate). To maintain food hot and to heat small quantities of liquid (sauces, eggs). To heat bigger quantities; to whip creams and sauces (vegetables, fruits, soups). - Page 25 COOKWARE: It is very important that the pans used on the hobs are made of a suitable material and have the correct base as follows: ■ The base should be flat and smooth. ■ Any rough part on the pan base could scratch the hob surface. ■...
-
Page 26: General Features
COOKING WITH FAN ASSISTED OVEN OPERATING PRINCIPLES Attention: The oven door becomes Heating and cooking in the fan assisted very hot during operation. oven are obtained in the following ways: Keep children away. a. by normal convection The heat is produced by the upper and GENERAL FEATURES lower heating elements. -
Page 27: Thermostat Knob
Figure 31 THERMOSTAT KNOB To turn on the heating elements of the oven, set function selector knob to the required po- sition and the thermostat knob to the desired temperature. To set the temperature, turn the thermostat control knob indicator mark to the required temperature. - Page 28 CONVECTION COOKING WITH VENTILATION The upper and lower heating elements and the fan turn on. The heat coming from the top and bottom is diffused by forced convection. The temperature must be regulated between 50°C and the maximum position with the ther- mostat knob.
-
Page 29: Cooking Advice
COOKING ADVICE The external parts of the appliance become hot during operation. Keep children well out of reach. OVEN COOKING To cook, before introducing the food, preheat the oven to the desired temperature. When the oven has reached the desired temperature, introduce the food, control the cooking time and tum off the oven 5 minutes before the theoretical time to recuperate the stored heat. -
Page 30: Use Of The Grill
USE OF THE GRILL Preheat the oven for about 5 minutes. Introduce the food to be cooked, positioning the rack as close to the grill as possible. The dripping pan should be placed under the rack to catch the cooking juices and fats. Grilling with the oven door closed. - Page 31 RECOMMENDED COOKING TEMPERATURE Shelf Cooking Food °C °F Mark Position* Time (approx) CAKES Victoria sandwich 2 or 3 20-25 mins Small cakes/buns 1 and 2 15-20 mins Maidera cake 2 or 3 20 mins Fruit cake hours Rich fruit cake 3 or 4 hours Scones...
- Page 32 DIGITAL ELECTRONIC PROGRAMMER The electronic programmer is a device which groups together the following functions: ■ 24 hours clock with illuminated display. ■ Timer (up to 23 hours and 59 minutes). ■ Program for automatic oven cooking. ■ Program for semi-automatic oven cooking. Description illuminated Description of the buttons:...
-
Page 33: Electronic Clock
ELECTRONIC CLOCK ELECTRONIC TIMER (fig. 33) The programmer is equipped with an elec- The timer program consists only of a buz- tronic clock with illuminated numbers which zer which may be set for a maximum period indicates hours and minutes. of 23 hours and 59 minutes. -
Page 34: Automatic Oven Cooking
AUTOMATIC OVEN COOKING Set the temperature and the cooking program by using the switch and ther- To cook food automatically in the oven, it is mostat knobs of the oven (see specific necessary to: chapters). Set the length of the cooking period. oven programmed Set the end of the cooking time. -
Page 35: Semi-Automatic Cooking
SEMI-AUTOMATIC COOKING At the end of the cooking time the oven will turn off automatically, the symbol will This is used to automatically switch off the turn off, AUTO will flash and a buzzer will oven after the desired cooking time has sound, which can be turned off by pushing elapsed. -
Page 36: Cleaning And Maintenance
CLEANING AND MAINTENANCE GENERAL ADVICE ■ Before you begin cleaning, you must ensure that the appliance is switched off and disconnected from the electrical power supply. ■ It is advisable to clean when the appliance is cold and especially when cleaning the enamelled parts. -
Page 37: Cleaning The Ceramic Hob
CLEANING THE CERAMIC HOB Figure 40 ■ Remove spillages and other types of incrustations. ■ Dust or food particles can be removed with a damp cloth. ■ If you use a detergent, please make sure that it is not abrasive or scouring. Abrasive or scouring powders can da- mage the glass surface of the hob. -
Page 38: Storage Compartment
GRILL HEATING ELEMENT ■ The heating element is self-cleaning and does not require maintenance. GREASE FILTER Clean the filter after any cooking! The grease filter can be removed for cleaning and should be washed regularly in hot soapy water (fig. 19 at page 17). Always dry the filter properly before fitting it back into the oven. Figure 41 OVEN FLOOR The oven floor “F”... - Page 39 REMOVING AND REPLACING THE INNER DOOR GLASS PANE FOR CLEANING If you wish to clean the inner glass of the door, make sure you follow the precautions and instructions very carefully. Replacing the glass pane and the door incorrectly may result in damage to the appliance and may void your warranty.
-
Page 40: Removing The Oven Door
REMOVING THE OVEN DOOR The oven door can easily be removed as follows: ■ Open the door to the full extent (fig. 45a). ■ Attach the retaining rings to the hooks on the left and right hinges (fig. 45b). ■ Hold the door as shown in fig. -
Page 41: Service And Maintenance
Oven only: none semi-automatic or automatic cooking program has been selected. Both the fuse and the mains fuse are intact. Should you still require assistance please contact our Customer Service Centre for your nearest Authorised Delonghi Service Agent. - Page 44 .au ww w.de lo nghi.co .nz...
