INSTALLATION and SERVICE INSTRUCTIONS
USE and CARE INSTRUCTIONS
DE 926 GWF
DUAL FUEL COOKER
distributed by
DèLonghi
Pty Ltd

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DE 926 GWF and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for DeLonghi DE 926 GWF

Summary of Contents for DeLonghi DE 926 GWF

  • Page 1 INSTALLATION and SERVICE INSTRUCTIONS USE and CARE INSTRUCTIONS DE 926 GWF DUAL FUEL COOKER distributed by DèLonghi Pty Ltd...

  • Page 2: Product Label

    Dear Customer, Thank you for having purchased and given your preference to our product. The safety precautions and recommendations reported below are for your own safety and that of others. They will also provide a means by which to make full use of the features offered by your appliance.

  • Page 3: Using The Oven For The First Time

    USING THE OVEN FOR THE FIRST TIME You are advised to carry out the following operations: ■ Furnish the interior of the oven. ■ Switch the empty oven ON at maximum temperature for about two hours to eliminate traces of grease and smell from the components. ■...

  • Page 4: Important Precautions And Recommendations

    IMPORTANT PRECAUTIONS AND RECOMMENDATIONS After having unpacked the appliance, check to ensure that it is not damaged. In case of doubt, do not use it and consult your supplier or a professionally qualified technician. Packing elements (i.e. plastic bags, polystyrene foam, nails, packing straps, etc.) should not be left around within easy reach of children, as these may cause serious injuries.

  • Page 5: Installation

    INSTALLATION CAUTION: ■ This appliance must be installed in accordance with these installation instructions. ■ This appliance shall only be serviced by authorized personnel. ■ This appliance is to be installed only by an authorised person. ■ Incorrect installation, for which the manufacturer accepts no responsibility, may cause personal injury of damage.
  • Page 6 CLEARANCES Installation clearances and protection of combustible surfaces shall comply with the current local regulations eg. AG 601 (AS 5601) Gas Installations code. Installation shall comply with the dimension in Fig. 1a bearing in mind that. Overhead Clearances In no case shall the clearances between the highest part of the cooker be less than 600mm or for an overhead exhaust fan 750mm.
  • Page 7 Figure 1a Cooker overall dimensions [mm] • height: min 900 - max 925 • width: 900 • depth: 600 GAS AND ELECTRIC CONNECTION Dotted line showing the Figure 1b position of the cooker when installed Area for GAS and ELECTRIC connection...

  • Page 8: Fitting The Adjustable Feet

    FITTING THE ADJUSTABLE FEET The adjustable feet must be fitted to the base of the cooker before use. Rest the rear of the cooker an a piece of the polystyrene packaging exposing the base for the fitting of the feet. Fit the 4 legs by screwing them tight into the support base as shown in figure 3.

  • Page 9: Moving The Cooker

    MOVING THE COOKER WARNING When raising cooker to upright position always ensure two people carry out this manoeuvre to prevent damage to the adjustable feet (fig. 5). Figure 5 WARNING WARNING Be carefull: do not lift the cooker When moving cooker to its final posi- by the door handle when raising tion DO NOT DRAG (fig.

  • Page 10: Anti-Tilt Bracket

    ANTI-TILT BRACKET Important! To restrain the appliance and prevent it tipping acci- dentally, fit a bracket to its rear to fix it securely to the wall. Make sure you also fit the supplied lock pin to the anti-tilt bracket. To fit the anti-tilt bracket: 1.
  • Page 11 BACKGUARD Before installing the cooker, assemble the backguard “C” (fig. 9). ■ The backguard “C” can be found packed at the rear of the cooker. ■ Before assembling remove any protective film/adhesive tape. ■ Remove the two spacers “A” and the screw “B” from the rear of the cooktop. ■...

  • Page 12: Gas Supply

    GAS SUPPLY: ■ The connection must be performed by an authorised person according to the rele- vant standards. ■ Before connecting the appliance to the gas main, mount the brass conical adaptor onto the gas inlet pipe, upon which the gasket has been placed (figures 10-11). Conical adaptor and gasket are supplied with the appliance (packed with conver- sion kit for use with Natural gas or ULPG).
  • Page 13 Customer Service Centre should be called to obtain the nearest authorized Delonghi Service Agent. WARNING, This appliance IS NOT SUITABLE for installation with a hose assembly.
  • Page 14 CONVERSION PROCEDURE (to convert to Natural gas or to ULPG) REPLACING THE INJECTORS This appliance is suitable for use with Natural gas or ULPG (check the “gas type” sticker attached to the appliance). A label stating the type of gas used after replacing the injectors must be attached at the rear of the appliance, in proximity of the gas inlet connection.
  • Page 15 MINIMUM BURNER SETTING ADJUSTMENT Check whether the flame spreads to all burner ports when the burner is lit with the gas tap set to the minimum position. If some ports do not light, increase the minimum gas rate setting. Check whether the burner remains lit even when the gas tap is turned quickly from the maximum to the minimum position.

  • Page 16: Lubrication Of The Gas Taps

    TABLE FOR THE CHOICE OF THE INJECTORS Natural gas ULPG 2.75 Test Point Pressure [kPa] Injector Injector Orifice Dia. Consumption Orifice Dia. Consumption BURNER [mm] [MJ/h] [mm] [MJ/h] Auxiliary (A) 0.85 3.60 0.53 3.60 Semi-rapid (SR) 1.12 6.30 0.70 6.30 Triple ring (TC) 1.65 13.30...

  • Page 17: Use And Care

    USE and CARE CAUTION: ■ This appliance must be used only for the task it has explicitly been designed for, that is for domestic cooking of foodstuffs. Any other form of usage is to be con- sidered as inappropriate and therefore dangerous. ■...
  • Page 18 SLIDING SHELVES (LEFT MAIN OVEN ONLY) ■ They facilitate the insertion and removal shelves during cooking. These shelves support all accessories and the dishwarmer safe. ■ The shelves block when pulled to the maximum position. ■ The sliding shelves can be removed easily by lifting slightly and detaching them from the oven walls.

  • Page 19: Grease Filter

    GREASE FILTER ■ A special screen is provided at the back of the multifunction main oven to catch grease particles, mainly when meat is being roasted (fig. 21). ■ When baking pastry etc. this filter should be removed. ■ Always clean the filter after cooking as any solid residues on it might adversely affect the oven performance.

  • Page 20: Gas Burners

    GAS HOB Figure 22 GAS BURNERS Natural Gas ULPG MJ/h MJ/h 1. Auxiliary burner (A) 2. Semi-rapid burner (SR) 3. Fish burner (FB) 10.6 10.6 4. Triple ring burner (TC) 13.3 11.9...
  • Page 21 ■ If the flame is still not correct, turn the burner off and call our Customer Service center for your nearest Authorized Delonghi Service Agent. ■ In the case of a mains failure light the burner with a match or lighted taper.
  • Page 22 CHOICE OF BURNER The burner must be chosen according to the diameter of the pans and energy required. For optimum efficiency uso a wok or pan no smaller than 230 mm diameter. Figure 24 do not use pans with concave or convex bases Burners Pan diameter Auxiliary...
  • Page 23 CORRECT USE OF TRIPLE-RING BURNER ■ The flat-bottomed pans are to be placed directly onto the pan-support. ■ To use the WOK, you must place the wok stand in the CORRECT position as shown in Fig. 25a-25b. IMPORTANT: The special grille for wok pans (fig. 25b) MUST BE PLACED ONLY over the pan-rest for the triple-ring burner.

  • Page 24: Control Panel

    CONTROL PANEL Figure 26 Controls description 1. Multifunction main oven thermostat knob 2. Multifunction main oven switch knob 3. Front left burner control knob 4. Rear left burner control knob 5. Fish burner control knob 6. Rear right burner control knob 7.

  • Page 25: General Features

    LEFT MULTIFUNCTION MAIN OVEN GENERAL FEATURES With your new Multi-Function oven it is possible to cook a variety of food using the 6 different cooking functions. These 6 functions are obtained using a combination of the 4 different heating elements plus a defrost function using the fan only.

  • Page 26: Thermostat Knob

    Figure 27 THERMOSTAT KNOB This only sets the cooking temperature and does not switch the oven on. Rotate clockwise until the required temperature is reached (from 50 °C to 250 °C). FUNCTION SELECTOR KNOB Rotate the knob clockwise to set the oven for one of the following functions. OVEN LIGHT By setting the knob to this position, only the oven light comes on.

  • Page 27: Fan Grill

    GRILLING The infrared grill element at the top of the oven comes on. The heat is dispersed by radiation. Use with the oven door closed and the thermostat knob to position 225 °C for max 15 minutes, then to position 175 °C. For cooking hints, see the chapter “USE OF THE GRILL”.

  • Page 28: Multi-Function

    MAINTAINING TEMPERATURE AFTER COOKING OR SLOWLY HEATING FOODS The upper element, the circular element and the fan come on. The heat is circulated by forced convection with greater intensity in the upper part. The temperature can be set to between 50 °C and 140 °C via the thermostat knob. Ideal for: Keeping food warm after any type of cooking.

  • Page 29: Grilling And Cooking Au Gratin

    SIMULTANEOUS COOKING OF DIFFERENT FOODS The oven set on position can cook several different foods together. Foods as diverse as fish and cakes can be cooked together without the cross transference of flavours. This is because the fats and cooking smell that would normally be deposited on the different foods are oxidised and are not absorbed by the foods.
  • Page 30 RIGHT CONVENTIONAL OVEN GENERAL FEATURES This is a conventional oven with 4 cooking positions, thermostatically controlled, obtained by 3 heating elements (top, bottom and grill). This oven is equipped with a special dish rack for use with the special function “ ”.
  • Page 31 THERMOSTAT KNOB This only sets the cooking temperature and does not switch the oven on. Rotate clockwise until the required temperature is reached (from 50 °C to 250 °C). FUNCTION SELECTOR KNOB Rotate the knob clockwise to set the oven for one of the following functions. OVEN LIGHT By setting the knob to this position, only the oven light comes on.

  • Page 32: Oven Cooking

    GRILLING The infrared grill element at the top of the oven comes on. The heat is dispersed by radiation. Use with the oven door closed and the thermostat knob to position 225 °C for max 15 minutes, then to position 175 °C. In the position the rotisserie motor come on for cooking with the rotisserie.
  • Page 33 ROASTING To obtain classical roasting, it is necessary to remember: ■ that it is advisable to maintain a temperature between 180 °C and 200 °C. ■ that the cooking time depends on the quantity and the type of foods. ROTISSERIE This is used for spit roasting under the grill and comprises: ■...
  • Page 34 USE OF SPECIAL DISH RACK This special shelf can be used as dish rack or turning over, as normal shelf for oven cooking. It must be inserted between the guides of the lateral racks. USING THE SPECIAL SHELF AS A DISH RACK Slide in the shelf on the guides, on the lower level of the lateral raks.
  • Page 35 RECOMMENDED COOKING TEMPERATURE Food °C °F Shelf Cooking Mark Position Time (approx) CAKES Victoria sandwich 2 or 3 20-25 mins Small cakes/buns 1 and 2 15-20 mins Maidera cake 2 or 3 20 mins 3 /4 Fruit cake hours 1 /2 Rich fruit cake 3 or 4 hours...

  • Page 36: Electronic Programmer

    ELECTRONIC PROGRAMMER (Main left oven only) The electronic programmer is a device which groups together the following functions: ■ 24 hours clock with illuminated display ■ Timer (up to 23 hours and 59 minutes) ■ Program for automatic oven cooking (main oven only) ■...

  • Page 37: Electronic Clock

    ELECTRONIC CLOCK ELECTRONIC TIMER (fig. 33) The programmer is equipped with an The timer programme consists only of a electronic clock with lighted numbers buzzer which may be set for a which indicate hours and minutes. maximum period of 23 hours and 59 Upon immediate connection of the minutes.

  • Page 38: Automatic Oven Cooking

    AUTOMATIC OVEN 3.Set the temperature and the cooking programme by using the switch and COOKING thermostat knobs of the oven (see To cook food automatically in the oven, specific chapters). it is necessary to: 1.Set the length of the cooking time Now the oven is programmed and 2.Set the end of the cooking time everything will work automatically, that...

  • Page 39: Semi-Automatic Cooking

    At the end of cooking, the oven and SEMI-AUTOMATIC symbol will turn off, the AUTO COOKING will flash and a buzzer will sound; that can be stopped by pushing any of the This is used to automatically switch off buttons. the oven after the desired cooking time has elapsed.

  • Page 40: Cleaning And Maintenance

    Cleaning and Maintenance Maintenance Description Period Daily • Clean gas cooktop as per instructions below • Remove burner caps, burner rings & base and clean using non abrasive detergent & rinse in cold water & dry thoroughly Monthly before replacing back on hob •...

  • Page 41: Replacing The Oven Light Bulb

    GAS TAPS If the gas taps are not working properly, call our Customer Service Centre to obtain the nearest Authorized Delonghi Service Agent. GRILL HEATING ELEMENT The heating element is self-cleaning and does not require maintenance.
  • Page 42 BURNERS Figure 40 They can be removed and washed only with soapy water. Detergents can be used but must not be abrasive or corrosive. Do not use abrasive sponges or pads. Do not put in dishwasher. After each cleaning, make sure that the burner-caps, as well as the burners, have been well wiped off and CORRECTLY POSITIONED.
  • Page 43 CORRECT POSITION OF THE FISH BURNER This burner must be correctly positioned as shown in the figure 43. Both the probe and ignition plug must be very carefully cleaned. Figure 43...

  • Page 44: Storage Compartment

    REMOVAL OF THE INNER GLASS DOOR PANEL ■ The inner glass door panel can easily be removed for cleaning by unscrew- ing the two screws (fig. 44). ■ When re-assembly ensure that the inner glass is correctly positioned and do not over tighten the screws.

  • Page 45: Dismantling The Door

    Figure 46a DISMANTLING THE DOOR Please operate as follows: ■ Open the door completely. ■ The swivel retainers of the rh and lh hinges (fig. 46a) are hooked onto the metal bar above them (fig. 46b). ■ Lift the oven door slightly. The notch on the bottom of the hinge will disengage (fig.

  • Page 46: Service And Maintenance

    Service and Maintenance If the ignition spark fails to ignite or does not light the gas, check the following items before calling our Customer Service Centre to obtain the nearest Authorised Service Agent: ■ Burner is reassembled and located correctly. ■...

  • Page 47: Wiring Diagram

    WIRING DIAGRAM OVEN 1 ( LEFT ) OVEN 2 ( RIGHT ) 1a 1a 2a 2a 3a 3a 4a 4a 5a 5a ELECTRIC DIAGRAM KEY Ignition coil Ignition switches TL1/2 Cooling fan with thermolimitators Cooling fan Terminal block Hearth plant LEFT OVEN RIGHT OVEN Oven switch...
  • Page 48 Descriptions and illustrations in this booklet are given as simply indicative. The manufacturer reserves the right, considering the characteristics of the models described here, at any time and without notice, to make eventual necessary modifications for their construction or for commercial needs. cod.
