- Page 1 PCIUSB3S2 Instruction Manual PCI USB 3.0 Adapter Card 2-Port PCI SuperSpeed USB 3.0 Adapter Card Manual Revision:12/20/2010 For the most up-to-date information, please visit www.startech.com...
-
Page 2: Fcc Compliance Statement
StarTech.com. Where they occur these references are for illustrative purposes only and do not represent an endorsement of a product or service by StarTech. com, or an endorsement of the product(s) to which this manual applies by the third-party company in question. -
Page 3: Table Of Contents
Table of Contents Introduction ....................1 Packaging Contents....................1 System Requirements ....................1 Installation ....................2 Hardware Installation ....................2 Driver Installation ...................... 2 Specifications ................... 4 Technical Support ..................5 Warranty Information ................5... -
Page 4: Introduction
Introduction The PCIUSB3S2 2-Port PCI SuperSpeed USB 3.0 Adapter Card allows for legacy PCI slots to support the USB 3.0 standard, which is capable of data transfer rates up to 5 Gbps (10x faster than USB 2.0 at 480 Mbps). This allows for full use of the PCI bus at 1.3 Gbps, allowing older systems double the performance with USB 3.0 versus using... -
Page 5: Installation
WARNING! PCI cards, like all computer equipment, can be severely damaged by static electricity. Be sure that you are properly grounded before opening your computer case or touching your PCI card. StarTech.com recommends that you wear an anti-static strap when installing any computer component. If an anti-static strap is unavailable, discharge yourself of any static electricity build-up by touching a large grounded metal surface (such as the computer case) for several seconds. - Page 6 2. AutoPlay should automatically launch and provide the option to browse the disk. If not, open “My Computer” and double-click on the CD/DVD drive the disk is inserted into and navigate to the USB 3.0 Host / NEC folder and open the setup.exe file. 3.
-
Page 7: Specifications
Specifications PCI specification 3.0 (33MHz, 3.3V/5V) Bus Interface USB 3.0 specification 1.0 Form Factor Full/Low Profile Chipset ID NEC uPD720200 External Connectors 2 x USB 3.0 type A female Internal Connectors 1 x 4-pin LP4 Power male USB 3.0: 5 Gbps Maximum Data Transfer Rate PCI: 1.33 Gbps Operating Temperature... -
Page 8: Technical Support
Limitation of Liability In no event shall the liability of StarTech.com Ltd. and StarTech.com USA LLP (or their officers, directors, employees or agents) for any damages (whether direct or indirect, special, punitive, incidental, consequential, or otherwise), loss of profits, loss of business, or any pecuniary loss, arising out of or related to the use of the product exceed the actual price paid for the product. - Page 9 StarTech.com has been making “hard-to-find easy” since 1985, providing high quality solutions to a diverse IT and A/V customer base that spans many channels, including government, education and industrial facilities to name just a few. We offer an unmatched selection of...
