GeoVision GV-VD120D Specifications page 5

Model No.
GV‐Mount410
GV‐Mount702
GV‐Mount900
GV‐Mount901
GV‐PA191
GV‐Relay V2
Power Adapter
GV-VD120D/121D/122D/123D
Name
Pole Mount Bracket Kit
(Ø 6" ~ 7.5")
Extension Tube
Wall Mount Bracket
GV‐VD Series Dome Housing
Power over Ethernet (PoE) Adapter
GV‐Relay V2
Power adapters are available in 4 regions: U.S.A., Australia, U.K and Europe.
- 5 -
Details
Dimensions
Bracket: 241 x 161 mm / 9.5 x 6.3 in
Weight: 1.70 Kg / 3.75 lbs
Steel Strap Diameter: Ø 6" ~ 7.5"
Four options are available.
Dimensions: Ø 5.4 x 10 or 20 or 30 or
50 cm /
Ø 2.1 x 3.9 or 7.9 or 11.8 or 19.7 in
Weight: 180 g or 390 g or 550 g or
800 g /
0.4 lbs or 0.86 lbs or 1.21lbs or 1.76
lbs
Dimensions: 154 x 108 x 50 mm / 6.1
x 4.3 x 2 in
Dimensions: Ø 186 x 97.5 mm / Ø 7.3
x 3.8 in
Weight: 600 g / 1.32 lb
The GV‐PA191 is a Power over
Ethernet (PoE) adapter designed to
provide power to the IP device
through a single Ethernet cable.
The GV‐Relay V2 is designed to
expand the voltage load of GV IP
devices. It provides 4 relay outputs,
and each can be set as normally
open (NO) or normally closed (NC)
independently as per your
requirement.
February 4, 2013
