GeoVision GV-VD120D Specifications page 4

Accessories
Model No.
GV‐Mount100
GV‐Mount101
GV‐Mount200
GV‐Mount203
GV‐Mount300
GV‐Mount310
GV‐Mount400
GV-VD120D/121D/122D/123D
Name
Straight Tube and Junction Box Kit
Straight Tube Kit
Wall Pendant Tube
Wall Pendant Tube and Junction Box
Kit
Convex Corner Adapter Kit
Concave Corner Adapter Kit
Pole Mount Bracket Kit
(Ø 4" ~ 6")
- 4 -
Details
Dimensions: 200 x 170 x 257.5 mm /
7.9 x 6.7 x 10.1 in
Weight: 3.17 Kg / 6.99 lbs
Dimensions: 219 x 125 x 332 mm /
8.6 x 4.9 x 13.1 in
Weight: 1.8 Kg / 3.97 lbs
Dimensions: 225 x 140 x 250 mm /
8.9 x 5.5 x 9.8 in
Weight: 900 g / 1.98 lb
Dimensions: 315 x 195.5 x 225 mm /
12.4 x 7.7 x 8.9 in
Weight: 2.95 Kg / 6.5 lbs
Dimensions: 238.6 x 409.5 mm / 9.4
x 16.1 in
Weight: 4.27 Kg / 9.41 lbs
Dimensions: 238.6 x 409.5 mm / 9.4
x 16.1 in
Weight: 4.27 Kg / 9.41 lbs
Dimensions
Bracket: 241 x 161 mm / 9.5 x 6.3 in
Weight: 1.70 Kg / 3.75 lbs
Steel Strap Diameter: Ø 4" ~ 6"
February 4, 2013
