Cisco uBR-3x10 RF Switch Hardware
Installation and Cabling Guide
June 6, 2008
Americas Headquarters
Cisco Systems, Inc.
170 West Tasman Drive
San Jose, CA 95134-1706
USA
http://www.cisco.com
Tel: 408 526-4000
800 553-NETS (6387)
Fax: 408 527-0883
Text Part Number: OL-1984-06

Advertisement

Table of Contents
loading

Related Manuals for Cisco uBR-3x10

Summary of Contents for Cisco uBR-3x10

  • Page 1 Cisco uBR-3x10 RF Switch Hardware Installation and Cabling Guide June 6, 2008 Americas Headquarters Cisco Systems, Inc. 170 West Tasman Drive San Jose, CA 95134-1706 http://www.cisco.com Tel: 408 526-4000 800 553-NETS (6387) Fax: 408 527-0883 Text Part Number: OL-1984-06...
  • Page 2 You can determine whether your equipment is causing interference by turning it off. If the interference stops, it was probably caused by the Cisco equipment or one of its peripheral devices. If the equipment causes interference to radio or television reception, try to correct the interference by using one or more of the following measures: •...

  • Page 3: Table Of Contents

    • Obtaining Additional Publications and Information, page 13 Document Objectives Use this document as a guide when installing and cabling the Cisco uBR 3x10 RF Switch at the cable headend or distribution hub. Audience This guide is intended for cable system installers and technicians who physically install and connect the Cisco uBR 3x10 RF Switch and associated equipment at the cable headend or distribution hub.

  • Page 4: Scope

    Regulatory Compliance and Safety Information for the Cisco RF Switch. Scope The guide provides installation and cabling information for the Cisco uBR 3x10 RF Switch. Refer to the “Related Documentation” section on page 10 for related Cisco publications that provide configuration information for the Cisco uBR 3x10 RF Switch.

  • Page 5: Warning Definition

    éviter les accidents. Pour prendre connaissance des traductions des avertissements figurant dans les consignes de sécurité traduites qui accompagnent cet appareil, référez-vous au numéro de l'instruction situé à la fin de chaque avertissement. CONSERVEZ CES INFORMATIONS Cisco uBR-3x10 RF Switch Hardware Installation and Cabling Guide OL-1984-06...
  • Page 6 Al final de cada advertencia encontrará el número que le ayudará a encontrar el texto traducido en el apartado de traducciones que acompaña a este dispositivo. GUARDE ESTAS INSTRUCCIONES Cisco uBR-3x10 RF Switch Hardware Installation and Cabling Guide OL-1984-06...
  • Page 7 Använd det nummer som finns i slutet av varje varning för att hitta dess översättning i de översatta säkerhetsvarningar som medföljer denna anordning. SPARA DESSA ANVISNINGAR Cisco uBR-3x10 RF Switch Hardware Installation and Cabling Guide OL-1984-06...
  • Page 8 Brug erklæringsnummeret efter hver advarsel for at finde oversættelsen i de oversatte advarsler, der fulgte med denne enhed. GEM DISSE ANVISNINGER Cisco uBR-3x10 RF Switch Hardware Installation and Cabling Guide OL-1984-06...
  • Page 9 Preface Document Conventions Cisco uBR-3x10 RF Switch Hardware Installation and Cabling Guide OL-1984-06...

  • Page 10: Related Documentation

    N+1 Feature Updates (N+1/5x20 and N+1/CLI sync) at the following URLs: • http://www.cisco.com/univercd/cc/td/doc/product/cable/cab_rout/cmtsfg/index.htm http://www.cisco.com/en/US/products/hw/cable/ps2217/products_configuration_guide_chapter 09186a008015096c.html “N+1 Redundancy for the Cisco CMTS" chapter of the Cisco Cable Modem Termination System • Feature Guide, at the following URL: http://www.cisco.com/en/US/products/hw/cable/ps2217/products_feature_guide09186a0080150 96c.html For installation information, see: Rack-Mounting the Cisco RF Switch with the Cisco uBR10012 CMTS, at the following URL: •...

  • Page 11: Obtaining Documentation

    For other information, see: Cisco uBR 3x10 Switch Documentation Roadmap, at the following URL: • http://www.cisco.com/univercd/cc/td/doc/product/cable/rfswitch/rdmp310.htm Regulatory Compliance and Safety Information for the Cisco RF Switch, at the following URL: • http://www.cisco.com/univercd/cc/td/doc/product/cable/rfswitch/rfs_rcsi.htm Warranty information, at the following URL: •...

  • Page 12: Documentation Feedback

    URL: http://www.cisco.com/techsupport/servicerequest For S1 or S2 service requests or if you do not have Internet access, contact the Cisco TAC by telephone. (S1 or S2 service requests are those in which your production network is down or severely degraded.) Cisco TAC engineers are assigned immediately to S1 and S2 service requests to help keep your business operations running smoothly.

  • Page 13: Definitions Of Service Request Severity

    Definitions of Service Request Severity To ensure that all service requests are reported in a standard format, Cisco has established severity definitions. Severity 1 (S1)—Your network is “down,” or there is a critical impact to your business operations. You and Cisco will commit all necessary resources around the clock to resolve the situation.
  • Page 14 Preface Obtaining Additional Publications and Information iQ Magazine is the quarterly publication from Cisco Systems designed to help growing companies • learn how they can use technology to increase revenue, streamline their business, and expand services. The publication identifies the challenges facing these companies and the technologies to help solve them, using real-world case studies and business strategies to help readers make sound technology investment decisions.
  • Page 15 About the Cisco uBR 3x10 RF Switch The Cisco uBR 3x10 RF Switch is designed to work with the Cisco uBR10012 CMTS or the Cisco uBR7246VXR CMTS in a cable headend or hub to provide N+1 redundancy for applications such as Voice over IP (VoIP).
  • Page 16 10BASE-T Ethernet interface over which you can control the configuration and operation of the • Cisco uBR 3x10 RF Switch by means of SNMP from a Cisco universal broadband router. • Upstream and downstream assembly online insertion and removal (OIR) or “hot swapping”...

  • Page 17: Obtaining Documentation

    The following sections describe interface numbering, and MAC address assignments. Interface Numbering In all of the Cisco RF switches, the slot number is the chassis slot in which an Ethernet controller or an upstream switch module or downstream switch module is installed, and the logical interface number is the physical location of the interface port on an Ethernet controller.

  • Page 18: Power Supply Module

    To allow OIR, an address allocator with a unique MAC address is stored in an EEPROM on the Cisco RF switch midplane. Each address is reserved for a specific port and slot in the switch, regardless of whether an Ethernet controller or an upstream or downstream switch module resides in that slot.
  • Page 19 • Connecting a console terminal to the Cisco uBR 3x10 RF Switch. You can use a rollover cable to connect the console terminal to the RF switch Ethernet controller’s EIA/TIA-232 receptacle.This connection allows you to configure the Cisco uBR 3x10 RF Switch for N+1 redundancy.
  • Page 20 Indicates that the Ethernet port has established a valid link with the network. This LED flashes as the Ethernet controller transmits data via the EIA/TIA-232 console port. This LED flashes as the Ethernet controller receives data via the EIA/TIA-232 console port. Cisco uBR-3x10 RF Switch Hardware Installation and Cabling Guide OL-1984-06...
  • Page 21 Figure 1-5.) There are 10 upstream switch modules used in the Cisco uBR 3x10 RF Switch. The module operates over the from 5 to 70 MHz. Each module has ten 75-ohm inputs accessed through the MCX connectors on the backpanel of the RF switch (see Figure 1-2 on page 1-3).
  • Page 22 Figure 1-6 on page 1-8) Three downstream (high-frequency) switch modules are used in the Cisco uBR 3x10 RF Switch. The module operates from 54 to 860 MHz. Each downstream switch module has ten 75-ohm inputs accessed through the CABLE PLANT MCX connectors on the backpanel of the RF switch. During normal system operation, the downstream switch module switches all direct traffic to their respective default termination interfaces.
  • Page 23 Ethernet card assemblies. This card distributes +12V power, ground, and the I control signals to the 14 switch card positions available. This assembly is not a field-replaceable unit (FRU). Note Cisco uBR-3x10 RF Switch Hardware Installation and Cabling Guide OL-1984-06...

  • Page 24: Cable Kits

    Cable Kits Cable Kits The cables approved for use in the Cisco N+1 redundancy solution, are Mini Precision RG59 (95 percent) tinned copper braid with (100 percent) foil shield. This cable is serial digital interface (SDI) rated with a 1 MHz to 3 GHz rating.

  • Page 25: Preparing For Installation

    C H A P T E R Preparing for Installation This chapter describes the site requirements for installing the Cisco uBR 3x10 RF Switch. The chapter contains the following sections: Safety, page 2-2 • Site Requirements, page 2-5 • Provisioning the Headend, page 2-7 •...

  • Page 26: Preparing For Installation

    A fully configured Cisco uBR 3x10 RF Switch weighs approximately 36.6 lb (16.6 kg). This chassis is not intended to be moved frequently. Before you install the Cisco uBR 3x10 RF Switch, ensure that your site is properly prepared so that you can avoid having to move a chassis later to accommodate power sources and network connections.

  • Page 27: Statement

    In addition, use the guidelines that follow when working with any equipment that is disconnected from a power source, but still connected to telephone wiring or other network cabling: Never install telephone wiring during a lightning storm. • Cisco uBR-3x10 RF Switch Hardware Installation and Cabling Guide OL-1984-06...

  • Page 28: Preparing For Installation

    When handling Ethernet controllers, power supplies, and upstream and downstream assemblies that have been removed from the Cisco uBR 3x10 RF Switch chassis, make sure that the equipment end of your ESD strap is attached to an unfinished chassis surface of the router; do not touch the printed circuit board, and avoid contact between the printed circuit board and your clothing.

  • Page 29: Ol-1984-06

    AC Power The AC input of the power supply module uses a power factor corrector that allows the Cisco uBR 3x10 RF Switch to operate on input voltage and frequency within the ranges of 100 to 240 VAC and 50 to 60 Hz.

  • Page 30: Chapter

    149°F (65°C) Site Configuration: Maintaining Normal Operation Planning a proper location for the Cisco uBR 3x10 RF Switch and the layout of your equipment rack or wiring closet is essential for successful system operation. Equipment placed too close together or inadequately ventilated can cause system overtemperature conditions.

  • Page 31: Safety

    Strong EMI, especially when caused by lightning or radio transmitters, can destroy the signal drivers • and receivers in the Cisco RF switch, and can even create an electrical hazard by conducting power surges through lines and into equipment. (Review the safety warnings in the “Safety with...

  • Page 32: Preparing For Installation

    Review the precautions for avoiding overtemperature conditions in the “Site Environment” section on page 2-6. To properly install the Cisco uBR 3x10 RF Switch chassis in a rack, refer to the instructions in the • “Rack-Mounting the RF Switch with the Cisco uBR10012 CMTS” section on page 3-3.

  • Page 33: Preparing For Installation

    Preparing for Installation Tools for Installation To prevent the chassis from overheating, never install the Cisco uBR 3x10 RF Switch in an enclosed rack Caution or room that is not properly ventilated or air conditioned. The Cisco uBR 3x10 RF Switch overheats if the input air temperature reaches 105°F (41°C).

  • Page 34: Preparing For Installation

    Four M5 x 8-mm Phillips countersunk screws to secure the rack-mount brackets to the chassis • To verify your plant’s RF setup, you need the following: Cisco uBR 3x10 RF Switch cabling bundles supplied by Cisco Systems, Inc. or WhiteSands • Engineering, complete with header blocks and MCX connectors. For more detailed information, refer to the “RF Cable Assemblies”...

  • Page 35: Preparing For Installation

    • Verifying the Shipping Container Contents When you receive your Cisco uBR 3x10 RF Switch, use the following procedure to check the contents of the shipping container. Use the installation checklist and the component list to ensure that you received all the components you ordered.
  • Page 36 Cisco Information Packet – 1. Titles and quantities of documents will vary depending on the configuration that you choose. You must order Cisco IOS and other documentation that isn’t automatically shipped with the product when you order the hardware. Cisco uBR-3x10 RF Switch Hardware Installation and Cabling Guide...

  • Page 37: Installation Checklist

    “Equipment Racks” section on page 2-8. If you do not plan to install your Cisco uBR 3x10 RF Switch in an equipment rack, proceed to the “Installing the Cisco uBR 3x10 RF Switch on a Workbench or Tabletop Environment” section on page 3-13.
  • Page 38 Types and numbers of interfaces verified Brackets installed Cisco uBR 3x10 RF Switch mounted in rack (optional) Cisco uBR 3x10 RF Switch chassis grounding lug installed and grounding wire connected Optional cable management bracket installed on the Cisco uBR10012 CMTS AC power cable or DC power leads connected to power source and Cisco uBR 3x10 RF Switch;...

  • Page 39: Rack-Mounting The Rf Switch With The Cisco Ubr10012 Cmts

    The inlet and exhaust ports for cooling air are located on the right and left of the chassis, respectively, so multiple Cisco uBR 3x10 RF Switches can be stacked in a rack with little or no vertical clearance. For information on the Vecima HD4040 series If-to-RF upconverters, go to the following URL: Note http://www.vecima.com...
  • Page 40 Cisco uBR10012 CMTS, Cisco uBR10-MC5X20S/U/H Cable Interface Line Cards, and Two Cisco uBR 3x10 RF Switches This sample configuration shows the Cisco uBR10012 router with Cisco uBR10-MC5X20S/U/H cable interface line cards installed, and two Cisco uBR 3x10 RF Switches mounted flush front. See Figure 3-1.
  • Page 41 Cisco uBR 3x10 RF Switch mounted flush front, and one Vecima HD4040 series upconverter. See Figure 3-2. An upconverter is required when you are using either the Cisco uBR-MC16C, E, S, line card or the Note Cisco uBR-MC28C line Card in this configuration. Figure 3-2...
  • Page 42 Rack-Mounting the RF Switch with the Cisco uBR10012 CMTS Attaching the Brackets for the Cisco uBR10012 CMTS This section explains how to attach the rack-mount brackets to a Cisco uBR 3x10 RF Switch for flush-front installations as shown in Figure 3-1 Figure 3-2.
  • Page 43 Cisco uBR 3x10 RF Switch in a rack. For this configuration, the Cisco uBR 3x10 RF Switch is placed so that the MCX connection side of the Note switch is facing in the same direction as the cable interface line cards.
  • Page 44 Locate the threaded holes in the top-right-rear and top-left-rear side of the Cisco uBR10012 chassis (spanning the width of the cable interface line cards on the chassis). Align the cable-management bracket with one set of threaded holes at the top of the Cisco uBR10012 Step 2 chassis.

  • Page 45: Rack-Mounting The Rf Switch With The Cisco Ubr7246Vxr Cmts

    The inlet and exhaust ports for cooling air are located on the right and left of the chassis, respectively, so multiple Cisco uBR 3x10 RF Switches can be stacked in a rack with little or no vertical clearance. For information on the Vecima HD4040 series If-to-RF upconverters, go to the following URL: Note http://www.vecima.com...
  • Page 46 Cisco uBR 3x10 RF Switch and the Cisco uBR7246VXR router. Sample 1 shows the Cisco uBR7246VXR with Cisco uBR-MC16C, E, S, or X cable interface line cards installed. Sample 2 shows the Cisco uBR7246VXR with Cisco uBR-MC28C cable interface line cards installed.
  • Page 47 Rack-Mounting the RF Switch with the Cisco uBR7246VXR CMTS Installing the Brackets on the Cisco uBR 3x10 RF Switch Chassis This section explains how to install the rack-mount brackets on a Cisco uBR 3x10 RF Switch for flush-rear installations as shown in Figure 3-5 on page 3-10.

  • Page 48: Installing The Chassis In The Rack

    Step 4 chassis) meet the mounting strips or posts on both sides of the equipment rack. Remember to leave 1 RU between the Cisco uBR7246VXR router and the Cisco uBR 3x10 RF Switch. This space is used for cable management.

  • Page 49: Installing The Cisco Ubr 3X10 Rf Switch On A Workbench Or Tabletop Environment

    AC power source. DC power leads required to deliver power to the chassis can suffer undue strain if installed in a workbench on tabletop environment. The Cisco uBR 3x10 RF Switch requires at least 3 in. (7.72 cm) of clearance at the inlet and exhaust •...

  • Page 50: Connecting Power

    Cisco uBR 3x10 RF Switch,” for a description of the tools you need to connect the required grounding wire to the RF switch. Then, if you intend to connect AC power to the Cisco uBR 3x10 RF Switch power supply, proceed to the “Connecting AC Power to the Power Supply”...
  • Page 51 Cisco Systems. You must obtain them from an electrical-connector vendor. To connect the grounding wire to the Cisco uBR 3x10 RF Switch: Ensure that the Cisco uBR 3x10 RF Switch is powered off and that you have disconnected the AC power Step 1 cord or DC power leads from the power supply.

  • Page 52: Statement

    Wait until the system has been cabled before turning on the power supply. See the “Powering On the RF Switch” section on page 5-26 Figure 3-8 Connecting AC Power Cisco uBR-3x10 RF Switch Hardware Installation and Cabling Guide 3-16 OL-1984-06...
  • Page 53 If any exposed wire at the stripped end of a lead is visible after inserting the lead into its receptacle, Caution remove the lead from the receptacle, use the wire stripper to cut the stripped end of the lead, and repeat Step 4 Step 5, if necessary. Cisco uBR-3x10 RF Switch Hardware Installation and Cabling Guide 3-17 OL-1984-06...
  • Page 54 Wait until the system has been cabled before turning on the power supply. See the “Powering On the RF Note Switch” section on page 5-26. Figure 3-9 Connecting DC Power Strain relief Cisco uBR-3x10 RF Switch Hardware Installation and Cabling Guide 3-18 OL-1984-06...
  • Page 55 The N+1 redundancy protection scheme you select for your system depends largely on the number and type of cable interface line cards you have installed in your Cisco uBR10012 router. The 7+1 eight-card redundancy scheme supports redundancy among the cable interface line cards installed in a fully populated Cisco uBR10012 router.

  • Page 56: Protection Scheme For The Cisco Ubr10012 Cmts

    16 downstream and 64 upstream interfaces in the chassis. A single Cisco uBR 3x10 RF Switch is connected to the Cisco uBR10012 router, allowing you to employ a redundancy scheme in which one protect cable interface line card supports from one to seven working line cards in the same chassis.
  • Page 57 160 upstream interfaces in the chassis. For this installation, two Cisco uBR 3x10 RF Switches are required to deploy a redundancy scheme in which one protect cable interface line card supports from one to seven working cable interface line cards in the same chassis.

  • Page 58: Rf Cable Assemblies

    Coaxial Cables The cables approved for use in the Cisco N+1 redundancy solution, are Mini Precision RG59 95% tinned copper braid with 100% foil shield. This cable is SDI rated with a 1 MHz to 3 GHz rating. CAB-RFSW-3X10-10T (bundled cable kit: 10-m, RFS to HUB, MCX to F) •...
  • Page 59 The header block holds the MCX connectors that are connected to the individual coaxial cables. These are Cisco MCX header blocks that mate to the Cisco uBR 3x10 RF Switch. Input cable kits have two extra header blocks. Output cable kits do not have header blocks.

  • Page 60: Rf Cable Assemblies For Cisco Ubr10-Mc5X20S/U/H Line Cards

    Note In Europe only, the Cisco uBR10-MC5X20H card must use quad-shielded cables to connect to the RF Switch (Cisco part numbers CAB-RFSW520TIMM and CAB-RFSW520TPMF for pre-assembled, terminated cable bundles). In all other regions, the Cisco uBR10-MC5X20H card can use dual-shielded or quad-shielded cables.
  • Page 61 (1-800-JUMPERS). Coaxial Cables The cables approved for use in the Cisco N+1 redundancy solution, are Mini Precision RG59 95% tinned copper braid with 100% foil shield. This cable is SDI rated with a 1 MHz to 3 GHz rating. CAB-RFSW520TIMM (dual-shielded cable kit: 1-m cable, MC5X20S/U to RFS, two 10-bundle, •...
  • Page 62 See the “Header Blocks” section on page 4-5. An extraction tool ships with the Cisco uBR 3x10 RF Switch to remove MCX connectors from the header blocks and UCH, if necessary. Cisco uBR-3x10 RF Switch Hardware Installation and Cabling Guide OL-1984-06...

  • Page 63: Installing The Header Blocks On The Cisco Ubr 3X10 Rf Switch

    Step 3 header block to prevent accidental disconnections. Tighten the header blocks to the Cisco uBR 3x10 RF Switch only after installing and gently Note pulling on the cables to be sure that they are firmly seated in the header block.
  • Page 64 Cabling the RF Switch With the Cisco uBR10012 CMTS Cable Interface Line Cards Mapping the RF Cables from the Working and Protect Line Cards (MC16x, MC28C) to the Cisco uBR 3x10 RF Switch Mapping the RF Cables from the Working and Protect Line Cards...

  • Page 65: Mapping The Rf Cables From The Working And Protect Line Cards (Mc16X, Mc28C) To The Cisco Ubr 3X10 Rf Switch

    Cabling the RF Switch With the Cisco uBR10012 CMTS Cable Interface Line Cards Mapping the RF Cables from the Working and Protect Line Cards (MC16x, MC28C) to the Cisco uBR 3x10 RF Switch Mapping the Cisco uBR10-LCP2-MC16x (C,E,S) Cable Interface Line Cards to the...
  • Page 66 Chapter 4 Cabling the RF Switch With the Cisco uBR10012 CMTS Cable Interface Line Cards Mapping the RF Cables from the Working and Protect Line Cards (MC16x, MC28C) to the Cisco uBR 3x10 RF Switch Figure 4-8 Mapping a Cisco uBR10012 CMTS Populated with Cisco uBR10-LCP2-MC16x Line Cards to the RF Switch...

  • Page 67: Switch

    Cabling the RF Switch With the Cisco uBR10012 CMTS Cable Interface Line Cards Mapping the RF Cables from the Working and Protect Line Cards (MC16x, MC28C) to the Cisco uBR 3x10 RF Switch Mapping the Cisco uBR10-LCP2-MC28C Cable Interface Line Cards to the RF...
  • Page 68 Chapter 4 Cabling the RF Switch With the Cisco uBR10012 CMTS Cable Interface Line Cards Mapping the RF Cables from the Working and Protect Line Cards (MC16x, MC28C) to the Cisco uBR 3x10 RF Switch Figure 4-9 Mapping a Cisco uBR10012 CMTS Populated with Cisco-uBR10-LCP2-MC28C Line Cards to the RF Switch...
  • Page 69 Cisco uBR10-LCP2-MC28C line cards, and the CMTS and PROTECT portions of the Cisco uBR 3x10 RF Switch in bundles of RF cables. The cables terminate at header blocks that connect to the RF switch at one of the following locations: CMTS—These groups of RF cables connect to cable interface line cards designated as the working...
  • Page 70 Chapter 4 Cabling the RF Switch With the Cisco uBR10012 CMTS Cable Interface Line Cards Connecting the RF Cables (MC16x, MC28C Line Cards) Table 4-2 on page 4-13 Table 4-1 on page 4-11 for cable interface and CMTS connection locations. Note that the gray and brown cables have F-connectors instead of MCX connectors.
  • Page 71 Chapter 4 Cabling the RF Switch With the Cisco uBR10012 CMTS Cable Interface Line Cards Connecting the RF Cables (MC16x, MC28C Line Cards) Cabling the Downstream Ports to the Input Ports on the Upconverter This section describes cabling the Cisco uBR10-LCP2-MC16x and Cisco uBR10-LCP2-MC28C line card downstream (DS) ports to the upconverter.
  • Page 72 Chapter 4 Cabling the RF Switch With the Cisco uBR10012 CMTS Cable Interface Line Cards Connecting the RF Cables (MC16x, MC28C Line Cards) Figure 4-12 Cabling the Input Ports on the Upconverter (MC28C) Input Table 4-4 Cisco uBR10-LCP2-MC28C Cabling (DS Ports to the Upconverter)
  • Page 73 Chapter 4 Cabling the RF Switch With the Cisco uBR10012 CMTS Cable Interface Line Cards Connecting the RF Cables (MC16x, MC28C Line Cards) Table 4-5 Upconverter Output Cables to the Working Plant on the RF Switch (for MC16x Line Cards) Color UPx Output RFS–CMTS...
  • Page 74 Chapter 4 Cabling the RF Switch With the Cisco uBR10012 CMTS Cable Interface Line Cards Connecting the RF Cables (MC16x, MC28C Line Cards) For shorter cables (3m) use cable kit CAB-RFSW520TPMF (dual-shielded) or CAB-RFSW520QTPMF (quad-shielded). To cable the output connections, complete the following steps.
  • Page 75 (switch side) or protect group of slots on the Cisco uBR 3x10 RF Switch and by the configuration you specify. Refer to the “N+1 Redundancy for the Cisco CMTS” chapter of the Cisco Cable Modem Termination System Feature Guide.
  • Page 76 Chapter 4 Cabling the RF Switch With the Cisco uBR10012 CMTS Cable Interface Line Cards Mapping the Working and Protect Cisco uBR10-MC5X20S/U/H Line Cards RF Cables to the RF Switch Table 4-7 RF Switch Ports and Line Card Ports for Line Card Slots 8/0 and 8/1...
  • Page 77 Chapter 4 Cabling the RF Switch With the Cisco uBR10012 CMTS Cable Interface Line Cards Mapping the Working and Protect Cisco uBR10-MC5X20S/U/H Line Cards RF Cables to the RF Switch Table 4-8 RF Switch Ports and Line Card Ports for Line Card Slots 7/0 and 7/1...
  • Page 78 Chapter 4 Cabling the RF Switch With the Cisco uBR10012 CMTS Cable Interface Line Cards Mapping the Working and Protect Cisco uBR10-MC5X20S/U/H Line Cards RF Cables to the RF Switch Table 4-9 RF Switch Ports and Line Card Ports for Line Card Slots 6/0 and 6/1...
  • Page 79 Chapter 4 Cabling the RF Switch With the Cisco uBR10012 CMTS Cable Interface Line Cards Mapping the Working and Protect Cisco uBR10-MC5X20S/U/H Line Cards RF Cables to the RF Switch Table 4-10 RF Switch Ports and Line Card Ports for Line Card Slots 5/0 and 5/1...
  • Page 80 This procedure assumes that the RF cables are already installed in the universal cable holder (UCH) and mounted on the Cisco uBR-MC5X20S/U/H cable interface line card. If the cables have not been installed in the UCH and mounted on the line card, refer to the Cisco uBR-MC5X20S/U/H Cable Interface Line Card documentation at the following URL: http://www.cisco.com/univercd/cc/td/doc/product/cable/ubr10k/ubr10012/frus/ubrmc520.htm...
  • Page 81 Chapter 4 Cabling the RF Switch With the Cisco uBR10012 CMTS Cable Interface Line Cards Connecting the RF Cables (Cisco uBR10-MC5X20S/U/H) For cabling locations, refer to: Table 4-7 on page 4-22 for slot 8/0 and 8/1 working line card RF switch connections.
  • Page 82 RF switch before gently pulling on the cables to be sure that they are firmly seated. Cisco cables are color-coded for easy reference and installation. The cable color corresponds to a specific port on the card. The tables include a column for users to define ports and color definitions.
  • Page 83 “Connecting the RF Cables Step 2 (Cisco uBR10-MC5X20S/U/H)” section on page 4-26 for MCX connector installation instructions. The output cables (CABLE PLANT) on the Cisco uBR 3x10 RF Switches are cabled in the reverse order Note of the input cables (CMTS). Step 3 Run the output cables (H–A) from header blocks to splitters, US laser receivers, or the low side of the...
  • Page 84 Chapter 4 Cabling the RF Switch With the Cisco uBR10012 CMTS Cable Interface Line Cards Connecting the RF Cables (Cisco uBR10-MC5X20S/U/H) Figure 4-17 Wiring the Cable Plant Cable Headers (CMTS/Protect Headers Shown for Comparison) Yellow Yellow Yellow Yellow White Violet...
  • Page 85 To power on the RF switch, complete the following steps. Step 1 Check that the cables connecting the cable interface line cards in the Cisco uBR10012 CMTS to the Cisco uBR 3x10 RF Switch are in place. Verify that the power cables are properly connected and secured.
  • Page 86 Chapter 4 Cabling the RF Switch With the Cisco uBR10012 CMTS Cable Interface Line Cards Powering On the RF Switch Cisco uBR-3x10 RF Switch Hardware Installation and Cabling Guide 4-32 OL-1984-06...
  • Page 87 Cisco uBR-MC16x cable interface line cards (16 downstream ports and 96 upstream ports) installed in the four Cisco uBR7246VXR routers. The fifth router in the rack (also with MC16x cards) serves as the protect router. The same configuration scenario is true for the Cisco uBR-MC28C cable interface line card;...
  • Page 88 Cisco uBR7246VXR Universal Broadband Router Configurations A single Cisco uBR7246VXR router contains up to four Cisco uBR-MC16x (C, E, S, U, or X) line cards or Cisco uBR-MC28x (C, U, or X) line cards. This configuration uses a redundancy scheme where one protect card supports from one to four working line cards.
  • Page 89 Protection Scheme for the Cisco uBR7246VXR CMTS Figure 5-2 shows a chassis configuration using Cisco MC28C cards, two RF switches, and three upconverters. Three upconverters are required for this configuration. The Cisco uBR-MC28U cable interface line cards have onboard upconverters. Upconverters are not Note required in a configuration using this line card.
  • Page 90 Coaxial Cables (Single and Bundle) The cables approved for use in the Cisco N+1 redundancy solution, are Mini Precision RG59 (95 percent) tinned copper braid with (100 percent) foil shield. This cable is serial digital interface (SDI) rated with a 1 MHz to 3 GHz rating.
  • Page 91 20 cable bundles (multicolor) CABLE PLANT Header Blocks The header blocks are installed on the Cisco uBR 3x10 RF Switch. Individual cables are attached to the MCX connectors in the header blocks (see Figure 5-4). The header blocks used in this cabling solution are slightly beveled at the top for easy identification.
  • Page 92 If you are using colored cables, connect the same colored cable to the same port on each of the cable interface line cards in each of the Cisco uBR7246VXR routers. Example: The red cable in each bundle goes to the US0 port on each card.
  • Page 93 This section describes attaching the header blocks to the RF switch. The RF cables are connected to the CMTS, PROTECT, and CABLE PLANT portions of the Cisco uBR 3x10 RF Switch using the header blocks. Header blocks are installed on the RF switch at the following locations: •...
  • Page 94 (in the upstream direction) and IF-to-RF upconverters (in the downstream direction) at the cable headend or HUB. Cabling the Working Line Card (VXR1–VXR4) This section describes cabling the working line cards from the Cisco uBR7246VXR routers to the RF switch. Equipment 16 cable bundles—4 per router (F-connector to MCX connector—multicolor)
  • Page 95 LC4 to RFS–1 RFS-2—2A RFS-2—6A RFS-1—2A RFS-1—6A White RFS-2—2B RFS-2—6B RFS-1—2B RFS-1—6B Blue RFS-2—2C RFS-2—6C RFS-1—2C RFS-1—6C Green RFS-2—2D RFS-2—6D RFS-1—2D RFS-1—6D Yellow RFS-2—2H RFS-2—6H RFS-1—2H RFS-1—6H Violet RFS-2—2I RFS-2—6I RFS-1—2I RFS-1—6I Cisco uBR-3x10 RF Switch Hardware Installation and Cabling Guide OL-1984-06...
  • Page 96 Cabling the Working Line Cards to the RF Switch RFS-2 RFS-1 P2A-P2H P1A-P1H 2A-2H 4A-4H 6A-6H 8A-8H 7H-7A 5H-5A 3H-3A 1H-1A 1A-1H 3A-3H 5A-5H 7A-7H 8H-8A 6H-6A 4H-4A 2H-2A Working CMTS Protect Cisco uBR-3x10 RF Switch Hardware Installation and Cabling Guide 5-10 OL-1984-06...
  • Page 97 RFS-1 Slot 7 (7A–7I) LC4(US0–US5) RFS-1 Slot 8 (8A–8I) Cabling the Protect Line Cards (VXR5) This section describes cabling the protect cable interface line cards from the Cisco uBR7246VXR router to the RF switch. Equipment 4 cable bundles (F-connector to MCX connector—multicolor) •...
  • Page 98 Cabling DS Ports to the Input Ports on the Upconverter This section describes cabling from the Cisco uBR7246VXR line cards DS ports to the upconverter. The Cisco uBR-MC16U cable interface line cards have onboard upconverters and are cabled directly to Note the DS ports (F) on the RF switch.
  • Page 99 Run the cable under the RF switch to the rear of the chassis. Step 2 Connect the cable to the 1F port on RFS-2. Step 3 Repeat Step 1 through Step 3 for the remaining cables. Step 4 Cisco uBR-3x10 RF Switch Hardware Installation and Cabling Guide 5-13 OL-1984-06...
  • Page 100 • 16 header blocks (installed) • Two more cable bundles may be required if you intend to route the upstream cables and the Note downstream cables to different locations. Cisco uBR-3x10 RF Switch Hardware Installation and Cabling Guide 5-14 OL-1984-06...
  • Page 101 5-11. Install the output cables in the header blocks. Step 1 The output cables (CABLE PLANT) on the Cisco uBR 3x10 RF Switch are cabled in the reverse order Note of the input cables (CMTS). Run the output cables (H–A) from header blocks to splitters, US laser receivers, or the low side of the...
  • Page 102 A connection group is a MAC domain which includes a downstream and it’s associated Note upstreams. Cabling the Working Line Card (VXR1–VXR4) This section describes cabling the working line cards from the Cisco uBR7246VXR routers to the RF switch. Equipment 16 cable bundles—4 per router, one per card (F-connector to MCX connector—multicolor) •...
  • Page 103 Cabling the Cisco uBR-MC28C Line Card in VXR1 to the RF Switches 1A-1H 5A-5H RFS-2 RFS-1 1A-1H 5A-5H Table 5-11 Cable Bundle Colors Used for Cisco uBR-MC28C US Ports to RFS MCX Connections Cable Color US Ports LC1–RFS LC2–RFS LC3–RFS LC4–RFS –...
  • Page 104 Cabling the RF Switch With the Cisco uBR7246VXR CMTS Connecting the Cables (Cisco uBR-MC28x Line Card) RF Switch 2 Table 5-12 Cable Bundle Sequence for the Cisco uBR 3x10 RF Switch 2 VXR1–LC US Ports 2 Slot (Header Block) VXR3–LC...
  • Page 105 4H-4A 2H-2A Working CMTS Protect Cabling the Protect Line Cards (VXR 5) This section describes cabling the protect line cards from the Cisco uBR7246VXR router to the RF switch. Equipment 4 cable bundles—1 per router (F-connector to MCX connector—multicolor) •...
  • Page 106 Step 4 Connect the cables to the input ports (top) on the upconverter. Step 5 Repeat Step 1 through Step 4 for each DS0 and DS1 port on the Cisco uBR7246VXR routers (VXR2 through VXR5). Figure 5-15 on page 5-21 shows cabling for the upconverter.
  • Page 107 VXR1 UPx1 Input VXR2 UPx1 Input LC1—DS0 LC1—DS0 White LC1—DS1 LC1—DS1 Blue LC2—DS0 LC2—DS0 Green LC2—DS1 LC2—DS1 Yellow LC3—DS0 LC3—DS0 Violet LC3—DS1 LC3—DS1 Orange LC4—DS0 LC4—DS0 Black LC4—DS1 LC4—DS1 Cisco uBR-3x10 RF Switch Hardware Installation and Cabling Guide 5-21 OL-1984-06...
  • Page 108 Table 5-17 DS Cables from VXRs to UPx3 Ports (by Router) Color VXR5 UPx3 Input LC1—DS0 White LC1—DS1 Blue LC2—DS0 Green LC2—DS1 Yellow LC3—DS0 Violet LC3—DS1 Orange LC4—DS0 Black LC4—DS1 Cisco uBR-3x10 RF Switch Hardware Installation and Cabling Guide 5-22 OL-1984-06...
  • Page 109 Use different colored cables for each connection. The example shows alternating gray and brown. Figure 5-16 Output Cables (Gray and Brown) UPx 3 UPx 2 UPx 1 Cisco uBR-3x10 RF Switch Hardware Installation and Cabling Guide 5-23 OL-1984-06...
  • Page 110 Color UPx3 Output RFS Ports Gray RFS-2, P2F Brown RFS-2, P2M Gray RFS-2, P1F Brown RFS-2, P1M Gray RFS-1, P2F Brown RFS-1, P2M Gray RFS-1, P1F Brown RFS-1, P1M Cisco uBR-3x10 RF Switch Hardware Installation and Cabling Guide 5-24 OL-1984-06...
  • Page 111 RF Switch Cable Plant Outputs (Turquoise) RFS-2 RFS-1 P2A-P2H P1A-P1H 2A-2H 4A-4H 6A-6H 8A-8H 7H-7A 5H-5A 3H-3A 1H-1A 1A-1H 3A-3H 5A-5H 7A-7H 8H-8A 6H-6A 4H-4A 2H-2A Working CMTS Protect Cisco uBR-3x10 RF Switch Hardware Installation and Cabling Guide 5-25 OL-1984-06...
  • Page 112 Place the power switch on the power supply in either the AC or DC position, depending on which type of power source is connected to your Cisco RF Switch. The green LED on the power supply goes on. Step 4 During the boot process, monitor the Cisco uBR 3x10 RF Switch system initialization and LED behavior for any errors or failures.

  • Page 113: Troubleshooting

    Cisco uBR 3x10 RF Switch hardware being inappropriately installed or set up. Refer to this chart, as necessary, to follow the steps to isolate hardware problems to a specific module;...
  • Page 114 Ensure that the voltage selection switch is in the appropriate AC or DC position. • If you are unable to resolve the problem, see the “Obtaining Technical Assistance” section on page 12 for information on contacting Cisco technical assistance. Cisco uBR-3x10 RF Switch Hardware Installation and Cabling Guide OL-1984-06...
  • Page 115 A problem has been detected configuring or controlling the switch modules. One or more of the – switch modules ERROR LEDs is on. If so, refer to the “Troubleshooting Upstream and Downstream Switch Modules” section on page 6-6. Cisco uBR-3x10 RF Switch Hardware Installation and Cabling Guide OL-1984-06...
  • Page 116 Status LEDs (SYS, ERR ACT, LNK) RJ-45 receptacle Transmit (TX)/ receive (RX) LEDs EIA/TIA-232 receptacle Power input/ C interface connector SW4-option select SW3-system configuration SW2-serial port hardware control Cisco uBR-3x10 RF Switch Hardware Installation and Cabling Guide OL-1984-06...
  • Page 117 EIA/TIA-422 Mode CTS Termination OFF—No termination ON—120-ohm termination RXDT EIA/TIA-422 Mode RXD Termination OFF—No termination ON—12-ohm termination RTSS EIA/TIA-422 Mode RTS line OFF—RTS+ not connected ON—RTS+ connected MODE Serial Port Mode OFF—EIA/TIA-232 ON—EIA/TIA-422 Cisco uBR-3x10 RF Switch Hardware Installation and Cabling Guide OL-1984-06...
  • Page 118 Use the test module command to diagnose failure. If you are unable to resolve the problem, refer to the “Obtaining Technical Assistance” section on page 12 for information on contacting Cisco technical assistance. Cisco uBR-3x10 RF Switch Hardware Installation and Cabling Guide OL-1984-06...
  • Page 119 RF modules and the ports assigned to each module. The modules are listed as seen from the front of the RF switch. Table 6-6 Switching Matrix for the Cisco uBR 3x10 RF Switch (Upstream and Downstream Modules) Module Working Ports...
  • Page 120 Chapter 6 Troubleshooting Troubleshooting the Installation and Setup Cisco uBR-3x10 RF Switch Hardware Installation and Cabling Guide OL-1984-06...

  • Page 121: Physical Specifications

    Operational temperature range:32 to 104°F (0 to +40°C) Operating temperature range:23 to 151°F (-5 to +55°C) Software requirement Cisco IOS Release 12.2(8)BC2 or later version of Cisco IOS Release 12.2BC Regulatory compliance Safety: CSA950/UL1950, EN60950, IEC 60950, ACAN TS001, AS/NZS3260 EMC Emissions: CFR 47 part 15:2000 Class B;...
  • Page 122 Appendix A Specifications and Component Part Numbers RF Specifications RF Specifications The following table lists the RF specifications for the Cisco uBR 3x10 RF Switch. Table A-2 RF Specifications Description Specification Input/output impedance 75 ohms Maximum RF input power +15 dBm (63.75 dBmV)

  • Page 123: Part Numbers

    MCX connector MCXFP MCX female to F female adapter 531-40137 Crimp tool for MCXFP 47-10120 Crimp tool for ASFP ACT-270 Stripper for MCXFP, ASFP CPT-7538-125 www.whitesandsengineering.com 1. Whitesands Engineering URL: Cisco uBR-3x10 RF Switch Hardware Installation and Cabling Guide OL-1984-06...

  • Page 124: Cable Part Numbers

    — RFS to cable plant Cable–single — WS940 YR46940 no connectors Cable–5 bundle — WS942 YR46942 no connectors Cable–10 bundle — WS943 YR46943 no connectors 1. RFS–RF switch 2. UPx–upconverter Cisco uBR-3x10 RF Switch Hardware Installation and Cabling Guide OL-1984-06...
  • Page 125 3-4, 3-5 crossover 1-5, 2-11 connecting power interference AC power 3-16 management bracket 2-10, 3-8 DC power 3-17 number of connectors part numbers console port settings protect cards 5-9, 5-10 Cisco uBR-3x10 RF Switch Hardware Installation and Cabling Guide IN-5 OL-1984-06...
  • Page 126 1-6, 6-3 header block power supply 1-5, 5-26 installation troubleshooting protect 5-11 upstream module header blocks 4-5, 4-8 lifting the chassis installing lightning storm, safety during Cisco uBR-3x10 RF Switch Hardware Installation and Cabling Guide IN-6 OL-1984-06...
  • Page 127 5-26 AC, site requirements specifications connections turn on power 4-31 AC power 3-16 rf switch DC power 3-17 component partnumbers cord RFswitchApp site requirements emergency power-off switch surge suppression Cisco uBR-3x10 RF Switch Hardware Installation and Cabling Guide IN-7 OL-1984-06...
  • Page 128 RF switch modules RF switch slot information turning on the RF switch 5-26 universal cable holder upconverter 4-4, 4-15, 5-21, 5-22, 5-24 cabling 4-17, 4-18 Cisco uBR-3x10 RF Switch Hardware Installation and Cabling Guide IN-8 OL-1984-06...
