Global Commands List
Command Name
Enable all Outputs
Disable all Outputs
Program all Voltages Set all power supply
Program all Currents Set all power supply
Save Settings of all
power supplies
Recall Settings of all
power supplies
Reset all supplies
Table 7-12: Global Commands

7.13 Command Summary

Common Commands
SCPI Command
*CLS
*ESE <NRf>
*ESE?
*ESR?
*IDN?
*OPC
*OPC?
*OPT?
*PSC {1|0}
*PSC?
*RCL {1|2|3|4}
*RST
*SAV {1|2|3|4}
*SRE <NRf>
*SRE?
*STB?
*TRG
Description
Output On to last V
& I levels
Turn outputs Off to
zero V & I
GLOBal:VOLTage:[AMPLitude] xxx.yy
output voltage
GLOBal:CURRent:[AMPLitude] xxx.yy
output current
Same as *SAV n
Same as *RCL n
Same as *RST
Description
Clear status
Standard event status enable
Return standard event status enable
Return event status register
Return instrument identification string
Set "operation complete" bit in ESR
Return a "1" when operation command complete <NC>
Return option number
Power - ON status enable (1) /disable (0)
Power - ON status clear
Recalls a saved instrument state
Reset
Saves an instrument state
Set service request enable register
Return service request enable register
Return status byte
Trigger
SCPI Format
GLOBal:OUTPut:STATe 1|ON
GLOBal:OUTPut:STATe 0|OFF
GLOBal:*SAV <NR1>
GLOBal:*RCL <NR1>
GLOBal:*RST
117
Result From
GEN Format
Supply
GOUT 1 None
GOUT 0 None
GPV xxx.yy None
GPC xxx.yy None
GSAV n None
GRCL n None
GRST None
GEN Command
CLS
<NC>
<NC>
<NC>
IDN?
<NC>
<NC>
<NC>
<NC>
RCL
RST
SAV
<NC>
<NC>
<NC>
<NC>
