1.5 i800 Family Bottom Panel View

Ports 5-7, 7&8, or 9:
10/100/1000Base Tx,
100FX, 1000SX/LX
DIN Rail
mounting
bracket

Figure 3: Bottom Panel

For details on connecting the console port, see Section 2.4.
For a description of the memory slot, see Section 2.6.
RuggedSwitch™i800 family
Ports 1 – 4/6/8:
10/100Base Tx
front
MEMORY
SLOT
CONSOLE
57600-N-8-1
back
9
Product Overview
Micro-SD
Memory Slot
RS-232
Console Port
RuggedCom®
