1.3.1 Front Panel LEDs

ITEM
Power status
Alarm status
Fiber port status
RJ45 Speed
RJ45 Link/Act
Table 1: Status LEDs
Note that the LEDs on all RJ45 Ethernet ports regardless of port orientation are
connected such that the top LED of each port is always the Speed indicator and the
bottom LED is always the Link/Activity indicator.

1.3.2 Front Panel Ethernet Options

A varied mix of Ethernet port options is available across four basic models. The basic
configuration and available options for each model are listed in Table 2, below.
i800
Port
1 to 4 10/100Tx
5
6
10/100Tx
7
8
9 Not present
Table 2: Front Panel Ethernet Options by model
For detailed Ethernet port specifications, please refer to Sections 3.5 and 3.6.
RuggedSwitch™i800 family
Color Activity
Green
Red
Blinking
Yellow
Yellow
Yellow
Blinking
i801
10/100Tx
10/100Tx
10/100/1000Tx
1000SX MM
1000LX SM
7
Comments
Solid
Solid Alarm condition exists
Link Established
Solid Tx/Rx Activity
Solid
Solid Link Established
Tx/Rx Activity
i802
10/100Tx
10/100Tx
10/100/1000Tx
100FX MM/SM
1000SX MM
1000LX SM
Not present
Product Overview
Power On
100Mbps
i803
10/100Tx
100FX MM/SM
100FX MM/SM
1000SX MM
1000LX SM
Not present
Not present
