Product Overview

1.4 i800 Family Top Panel View

DIN Rail
mounting
bracket
Power
Connector
Chassis
Ground

Figure 2: Top Panel

For details on connecting the power supplies and Ground, see Section 2.2.
For details on connecting the Fail-Safe Relay, see Section 2.3
RuggedCom®
back
P1+
P1-
GND
P2-
P2+
Ratings:
12-24V ,
, 2A
front
8
Fail-Safe
Relay
RuggedSwitch™i800 family
