Security - Draytek VigorAP 800 User Manual

WMM Capable
Antenna
Tx Power
3 . 4 . 2 S e c u r i t y
3 . 4 . 2 S e c u r i t y
This page allows you to set security with different modes for SSID 1, 2, 3 and 4 respectively.
After configuring the correct settings, please click OK to save and invoke it.
By clicking the Security Settings, a new web page will appear so that you could configure
the settings.
VigorAP 800 User's Guide
To apply WMM parameters for wireless data transmission, please
click the Enable radio button.
VigorAP 800 can be attached with two antennas to have good
data transmission via wireless connection. However, if you have
only one antenna attached, please choose 1T1R.
The default setting is the maximum (100%). Lower down the
value may degrade range and throughput of wireless.
32
