H7921 3G Router

User Manual

Hongdian Corporation
F5~6, Building 14, Shangsha Science & Tech Park, Binhe Blvd., Shenzhen, China
Tel: +86-755-88864288
Fax: +86-755-83404677
: 518048
Postal Code
www.hongdian.com
www.mdtu.com
Copyright © 1997-2012
Release 1.0.2

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the H7921 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Shenzhen Hongdian Technologies H7921

Summary of Contents for Shenzhen Hongdian Technologies H7921

  • Page 1: User Manual

    H7921 3G Router User Manual Hongdian Corporation F5~6, Building 14, Shangsha Science & Tech Park, Binhe Blvd., Shenzhen, China Tel: +86-755-88864288 Fax: +86-755-83404677 : 518048 Postal Code www.hongdian.com www.mdtu.com Copyright © 1997-2012 Release 1.0.2...
  • Page 2 Hongdian Technologies Corporation. Trademark , Hongdian, GPRS DTU, MDTU, Hongdian Technologies, Shenzhen Hongdian and Galaxy are the trademarks and logos of Shenzhen Hongdian Technologies Corporation. Other trademarks and logos mentioned in this manual belong to other organizations related. Shenzhen Hongdian Technologies Corporation does not own the rights of other trademarks and logos.

  • Page 3: Table Of Contents

    H7921 3G Router User Manual CONTENTS CHAPTER 1 ABOUT THIS MANUAL ..............4 Purpose....................4 Applicable scope..................4 Version information................4 Convention ....................5 Technical support...................5 Acronym and term .................6 CHAPTER 2 Product Introduction ..............9 2.1 Galaxy 3G overview ..................9 2.1.1 Product appearance ................9 2.1.2 Other Accessories................11 2.1.3 Device installation .................11...

  • Page 4: Chapter 1 About This Manual

    Convention Technical support Acronyms and terms 1.1 Purpose This user manual is developed mainly on the basis of H7921 V1.0, and is used ® as the guideline while Hongdian H7921 series products are installed and tested. 1.2 Applicable scope...

  • Page 5: Convention

    H7921 3G Router User Manual 1.4 Convention For reading and using this user manual fast and conveniently, the following conventions are reached for some abbreviations, icons, notes, security warnings and tips that appear in this user manual: Table -1.2: Convention Table...

  • Page 6: Acronym And Term

    H7921 3G Router User Manual E-mail service: Technical support: support@hongdian.com Service service@hongdian.com Website and BBS service: Website: www.hongdian.com BBS: http://www.mdtu.com/forum/default.asp 1.6 Acronym and term In this user manual, the following acronyms and terms are used: Access Point Name Application Asynchronous Transfer Mode...
  • Page 7 H7921 3G Router User Manual ETSI European Telecommunications Standards Institute GGSN Gateway GPRS Support Node GMSC Gateway MSC GPRS General Packet Radio Service Global System for Mobile Communications GPRS Support Node GPRS Tunneling Protocol GTP-id GTP Identity Home Location Register...
  • Page 8 H7921 3G Router User Manual Packet Control Function Packet Data Protocol Packet Data Network PDSN Packet Data Service Node PLMN Public Land Mobile Network Point of Sales PTM-G Point-to-Multipoint Group Call PTM-M Point-to-Multipoint Multicast Quality of Service Routing Area RADIUS...

  • Page 9: Chapter 2 Product Introduction

    Galaxy H7921 3G Router is characterized with excellent transmission reliability and a wide range of applicability. It is the ideal choice for various sectors as a special data communication system.
  • Page 10 H7921 3G Router User Manual SYSTEM： It lights when router works normally. Back panel interface Galaxy H7921 3G Router’s all interfaces are designed on the back panel as shown below: POWER RESET ANT Fig. 2.1.1-2: Back Panel The interfaces on the back panel are described as below: ANT：Antenna (SMA negative terminal) interface, which is able to match with standard...

  • Page 11: Other Accessories

    Storage Temperature: -30~+70ºC Relative Humidity: <95% (no condensation) Galaxy H7921 3G Router can be placed in office, on wall or installed or fixed in any places, without special wiring and heat radiating requirements. To ensure the long-term and stable operation of system, grounding measures and dust-proof measures should be taken on power supply, keep ventilation and a proper room temperature.

  • Page 12: Function And Features

    2.1.3.2 Wiring RJ-45 - Ethernet interface Standard 10/100BaseT Ethernet switch port, self-adaptive DC - power supply interface, Galaxy H7921 3G router’s power supply is generally +12VDC ANT - antenna interface The standard 5OΩ/SMA RF connector (female) is applied. In the environment of some industrial applications, the lightning protection measures should be taken.

  • Page 13: Software Function

    Local Firmware Upgrading/ Configuration Backup System Log Server 2.3 System application Multiple application modes for H7921 3G Router are described as follows: Application Mode One: Application in video monitoring The center-to-multipoint network generally needs to be adopted for the application mode of video monitoring. Please connect and install the router and network camera according to the following schematic diagram.
  • Page 14 2.3-1: S Application Mode Two: Application in SoHo There is one built-in 10M/100M self-adapting fast Ethernet port within H7921 3G Router, which greatly facilitates SoHo user getting access to the internet. Diagram chematic diagram for 2.3-2: S...

  • Page 15: Chapter 3 Router Configuration

    When you enter Galaxy H7921 3G Router built-in WEB configuration interface, you can set and manage its parameters as described below. 3.2 Connection settings 3.2.1 Environment requirements When you want to use Galaxy H7921 3G Router , a computer and a UIM/SIM card should be prepared according to the following requirements:...

  • Page 16: Connection Method

    Never pull or plug your SIM/UIM card when H7921 is power on. Your card may be damaged. Warning: The metal casing of H7921 3G Router has to be well connected to the ground so as to ensure the router a safe, stable and reliable operation.
  • Page 17 H7921 3G Router User Manual 3.2.2.2 LAN connection method When it is required to connect Galaxy H7921 3G Router to local network through HUB or switch, connect the hub or switch out-link port with any one of its switch ports as shown in the figure below.

  • Page 18: Network Configuration

    H7921 3G Router User Manual Self-adapting (Version 2.0 or above) standard 10/100BaseT Ethernet switching interface ANT – antenna interface The standard 5OΩ/SMA radio-frequency connector (negative terminal) is adopted for use. In addition, the lightning-proof measures need to be adopted for some operating conditions, so you may place a lightning protection device between the connector and the antenna.
  • Page 19 H7921 3G Router User Manual Enter (double click or right click) the “Local Area Connection” “Property (R)” and enter the interface shown in the figure below: Fig. 3.2.3-2: Computer Local Connection Configuration Select the “Internet Protocol (TCP/IP)”, click the “Properties”, and enter the interface as...
  • Page 20 Management interface login IP address: 192.168.8.1 Login name: admin Login password: admin Method 2: advanced configuration If you don’t want to interrupt local PC LAN communication and configure Galaxy H7921 3G Router when the former network configuration exists, it is required add route (IP).
  • Page 21 H7921 3G Router User Manual The configuration operation is shown as below: Click the “Advanced (V)…”button in Fig. 3.2-5 to enter the interface as below: Fig. 3.2.3-4: Advanced TCP/IP Properties Configuration Click the “Add (A)”button under the “IP address (R)”, and fill in the IP address that you want to add: Fig.

  • Page 22: System Login

    Internet is accessed through original local network, the default gateway setting does not need to be modified; if Galaxy H7921 3G Router + is used, you need to modify the default gateway and configure it as Galaxy H7921 3G Router’s default LAN IP address 192.168.8.1.

  • Page 23: Web-Based Configuration

    Input correct user name and password, and enter the WEB configuration interface. 3.3 WEB-based configuration Galaxy H7921 3G Routers can be configured in WEB mode. The WEB-based operation features visualization and simplicity, so it is recommended to perform parameter configuration and operation in WEB mode. Connect the PC and Galaxy router according to the description in the previous section.
  • Page 24 H7921 3G Router User Manual Drawing 3.3.1-1: System Configuration Window You can select the function and display the configuration window for the function after clicking on the related option on the top left corner of configuration window. Please see the following drawing: Menu Descriptions Drawing 3.3.1-2: Main Option Bar...

  • Page 25: Network

    H7921 3G Router User Manual 3.3.2 Network When you click the “Internet” tab, the following sub-tabs appear on the page: Modem Parameter Select Connection Type DHCP Sever Fig. 3.3.2: Internet Configuration Tab 3.3.2.1 LAN In the “Local Network” main tab, click the “LAN” sub-tab to set the LAN port and enter the following configuration interface: Fig.
  • Page 26 H7921 3G Router User Manual Fig. 3.3.2.1-1: Modem 【Mod】: Modify the current settings. 【Del】: Delete current settings. 【En】: Enable/disable the current settings. 【Add】: Add SIM ID. 【Auto-Dialup】: Set the account number of 3G network service provided by ISP. 【Interface Name】: Set the SIM card name.
  • Page 27 H7921 3G Router User Manual Note: This feature is special. It’s used to match with Parameter Select feature together. For example, if need to communicate with two different data servers via VPN tunnel. There is a priority for two VPN tunnel. So each tunnel need to bind one SIM ID.

  • Page 28: Parameter Select

    H7921 3G Router User Manual Fig. 3.3.2.1-2: PPP Advanced Settings Considering the difference of mobile network authorization, the Point to Point Protocol connection should be compatible with different network. Advanced setting is used for the PPP special setting. Click “PPP Advanced Setting” button to start settings.
  • Page 29 H7921 3G Router User Manual Fig. 3.3.2.3: Parameter Select Interface Fig. 3.3.2.3-1: Parameter Select Interface 【Status】Enable/disable the parameter select feature. 【Rule Name】Set the rule ID from 0 to 9. 0 is the prepreerence. 【Interval】: Set the check interval. 【Retry Times】: Set the check times.

  • Page 30: Connection Type

    H7921 3G Router User Manual ICMP mode means router will automatically check the specified destination IP as the interval and retry times. Once the ICMP is failed, router will automatically switch rule from current rule. 3.3.2.4 Connection Type In the “Internet” main tab, click the “Internet Connection Type” sub-tab to set the internet connection type.

  • Page 31: Applications

    H7921 3G Router User Manual Fig. 3.3.2.5: DHCP Configuration Interface The configuration parameters include: 【DHCP Server】: Set whether enable the DHCP server function: Enable/Disable. 【IP Pool】: Set the range of the DHCP dynamic address pool as the default bro interface or customize the IP address range.

  • Page 32: Icmp Check

    H7921 3G Router User Manual Fig. 3.3.3: Applications Configuration Tab 3.3.3.1 ICMP Check In the “Applications” main tab, click the “ ICMP Check ” sub-tab to set the ICMP Check parameters and go to the following configuration interface: Fig. 3.3.3.1: ICMP Check Interface Trigger On-line Data parameters include: 【Destination IP or Domain】: Set whether enable the ICMP Check Service IP and...
  • Page 33 H7921 3G Router User Manual Fig. 3.3.3.2: Interface Check 【Interface Name】: Set which interface will be check. 【Flow Direction】: the way to check data flow. 【Check Interval】: Set the interval of check. 【Retry Times】: Set the check times. 3.3.3.3 DDNS The router is designed with DDNS (Dynamic Domain System) function which can make others to search the dynamic IP address by internet domain.
  • Page 34 H7921 3G Router User Manual Fig. 3.3.3.3: DDNS Configuration Interface DDNS configuration parameters include: 【DDNS Server】: Set whether enable DDNS service function: Enable/Disable. 【Service Provider】: Select the DDNS service provider that router currently supports. Domestic DDNS service provider: 88IP (www.88ip.net), 3322 (www.3322.org); oversea DDNS service provider: DNSEXIT (www.dnsexit.com), ZONEEDIT (www.zoneedti.com),...
  • Page 35 H7921 3G Router User Manual Fig. 3.3.3.4: DTU Interface DTU parameters include: 【DTU Service】: Set whether enable the DTU Service. 【Work Mode】 : Work as a Server or a Client. Client will register to server automatically. 【Local Port】: Set the receive port if work mode is server.
  • Page 36 H7921 3G Router User Manual Fig. 3.3.3.5 SNMP 【SNMP Sevice】: Set whether enable the DTU Service. 【Port】: Set the SNMP port. 【Community】: Set the SNMP community. 3.3.3.6 M2M In the “Applications” main tab, click the “M2M” sub-tab to set the Timing Operation parameters and go to the following configuration interface: Fig.
  • Page 37 H7921 3G Router User Manual 【M2M Sevice】: Set whether enable the M2M Service. 【Server IP or Domain】: Set the server IP or domian. 【Server Port】: Set the server port. 【Login Times】: Set login max times. 【Heartbeat Interval】: Set the heartbeat interval for M2M connection.
  • Page 38 H7921 3G Router User Manual 3.3.3.8 Wake Up In the “Applications” main tab, click the “ Wake Up ” sub-tab to set the Trigger On-line Data parameters and go to the following configuration interface: Fig. 3.3.3.8: Wake Up Interface Wake Up parameters include: 【Wake Up Service】: Set whether enable the Wake Up .
  • Page 39 H7921 3G Router User Manual Fig. 3.3.4: VPN Interface When you click the “VPN” tab, the following sub-tabs appear on the page: VPDN Tunnel IPSec 3.3.4.1 VPDN Click the “Add” tab; the following sub-tabs appear on the page: Fig. 3.3.4.1-1: VPDN Interface...
  • Page 40 H7921 3G Router User Manual Fig. 3.3.4.1-2: VPDN Interface 【VPDN Service】: Enable/disable the VPDN Service. 【Interface Name】: Set the VPDN name. 【Protocol】: Select the VPN protocol for PPTP or L2TP. 【Server IP or Domain】: Set the VPN server IP or domain name.
  • Page 41 H7921 3G Router User Manual Fig. 3.3.4.2-2: Tunnel Interface 【IP Tunnel Service】: Enable/disable the tunnel service. 【Tunnel Name】: Set the tunnel name. 【Tunnel Mode】: Select tunnel mode for ipip or GRE 【Local Virtual IP】: Set the local virtual IP of tunnel.
  • Page 42 H7921 3G Router User Manual Fig. 3.3.4.3-1: IPsec Interface Click the “Add” tab; the following sub-tabs appear on the page: Fig. 3.3.4.3-2: IPsec Interface 【Select】: Select the IPSec phase 1. 【Policy Name】: Set the policy name in IPSec phase 1.
  • Page 43 H7921 3G Router User Manual Fig. 3.3.4.3-3: IPsec Interface 【Select】: Select the IPSec phase 2. 【Policy Name】: Set the policy name in IPSec phase 1. 【Encryption Protocol】: Select 【Encrypt】: Select IPSec encryption arithmetic. 【Hash】: Select IPSec Hash arithmetic. 【PFS】: Enable/disable PFS.

  • Page 44: Forward

    H7921 3G Router User Manual Fig. 3.3.4.3-4: IPsec Interface 【Select】: Select the IPsec setting. 【Interface Name】: Set the IPSec name. 【Match Phase 1】: Select IPSec policy name for phase 1. 【Match Phase 2】: Select IPSec policy name for phase 1.

  • Page 45: Static Route

    H7921 3G Router User Manual Fig. 3.3.5.1-1: NAT Interface Select the “NAT” option to go to the following configuration interface: Fig. 3.3.5.1-2: NAT Interface 【Select】: Select NAT or MASQ. 【Chain】: Select the NAT mode. 【Protocol】: Select the protocol for NAT mode.

  • Page 46: Security

    H7921 3G Router User Manual Fig. 3.3.5.2-1: Static Route Configuration Interface To add the static route, click the “Add” button and go to the following configuration interface: Fig. 3.3.5.2-2: Static Route Configuration Interface 【IP Address/Mask】: Configure the destination network address and mask of this static route.
  • Page 47 H7921 3G Router User Manual Fig. 3.3.6.1-1: IP Filter Interface You can choose filter type here: IP filter rules for Basic or Expand Select the “Basic” to go to the following configuration interface: Fig. 3.3.6.1-2: IP Filter Interface The configuration parameters include: 【Type】: Basic type is based on IP address filter.

  • Page 48: Domain Filter

    H7921 3G Router User Manual 【Wildcard Bits】: Configure the wildcard for source IP address or IP segments. 【Destination IP】: Set the source IP address of the filter rule, may be defined IP address or one IP segment. Specially, you must configure the initial IP of IP segment.

  • Page 49: System

    H7921 3G Router User Manual Fig. 3.3.6.3-1: MAC Filter Interface 【MAC】: Set the the MAC address. 【Default Action】: Select the action mode for accept or drop. 【Filter Mode】: Select the filter mode for input, forward or both. 3.3.7 System When you click the “System Tools” tab, the following sub-tabs appear on the page:...

  • Page 50: Remote Log

    H7921 3G Router User Manual Fig. 3.3.7.1: Log View Interface Log view settings include: 【Local Log】: Set the type of log to be displayed. After selecting the log type, you can make the following operations: 【View】: Display log in the Log Table.

  • Page 51: System Clock

    H7921 3G Router User Manual Fig. 3.3.7.2: System Log Management Interface The system log configuration parameters include: 【Local Log Status】: Set whether enable local log function: Enable/Disable. 【Remote IP or Domain】: Set the IP address/domain name of the remote server, generally the IP address of the PC that receives the log information.
  • Page 52 H7921 3G Router User Manual Fig. 3.3.8.3: Clock Configuration Interface The system clock configuration parameters include: 【Status】: Enable/disable the Clock service 【NTP Server IP or Domain】: Set the domain or IP address of the NTP server. 【NTP Sever Backup】: Set the backup NTP server IP address/domain.

  • Page 53: Network Test

    H7921 3G Router User Manual Fig. 3.3.7.4: Account Interface The system clock configuration parameters include: 【Account Type】: Set the account based on Web. 【Account Level】 :Set the account authority. Admin authority can configure all features. Guest authority just can view all feature.

  • Page 54: Status

    H7921 3G Router User Manual Fig. 3.3.7.5: System Reboot Interface 【Firmware Setting】:Upgrade firmware/patch . 【Backup Setting】:Import/export the configuration. 【Save】: Save the current configuration as default. 【Load】: Default the current configuration to default. 【View】: Check the current patch name in the router.
  • Page 55 H7921 3G Router User Manual 【LAN】: Display LAN port’s running information. 【Embedded Modem】: Display USB wireless network’s running information. 【Route Table】: Display the route table information. 【DHCP Client】: Display the DHCP Client information.

  • Page 56: Chapter 4 Frequently Asked Questions (Faq)

    (Note: H7921 Router’s LINK indicator and PC’s Link indicator must be on). Whether PC’s TCP/IP environment is configured correctly? (Note: If H7921 Router’s IP address is 192.168.8.1, PC’s IP address must be 192.168.8.xxx). For more check, click the relevant menu and enter the DOS interface. Type the...
  • Page 57 H7921 3G Router User Manual C:\>ipconfig Windows IP Configuration Ethernet adapter local connection: Connection-specific DNS Suffix..: IP Address ....: 192.168.8.48 Subnet Mask .

  • Page 58: Appendix: Software Upgrade Description

    H7921 3G Router User Manual Appendix: Software Upgrade Description Upgrade tool description and operating instructions Galaxy H7921 3G Router is designed with the platform technology, whose software can be upgraded with the development of the communication and network technology. WEB upgrade: Galaxy H7921 3G Router supports the function of upgrading the firmware directly by importing the upgrade file via the WEB configuration interface.
