Page 1: User Manual
SHENZHEN HONGDIAN TECHNOLOGIES CO., LTD. Mobile Data Communications User Manual Galaxy Mobile Router (H7921) - Page 2 Hongdian Hongdian, Hongdian Technologies and Shenzhen Hongdian are the logos and trademarks of Shenzhen Hongdian Technologies Co., Ltd. The other company trademarks and logos in this manual are owned by the owner, Hongdian does not have the right for those trademarks and logos.
- Page 3 GTP-id GTP Identity Home Location Register Abbreviations HSCSD High Speed Circuit Switch Data IGMP Internet Group Management Protocol Access Point Name IGRP Internet Gateway Routing Protocol Application Intelligent Network Asynchronous Transfer Mode Internet Protocol Auto Table Machine IPv4 IP version 4 Authentication Centre IPv6 IP version 6...
- Page 4 PTM-M Point-to-Multipoint Multicast Quality of Service Routing Area RADIUS Remote Authentication Dial In User Service Routing Information Protocol Register Service Center RTOS Real Time Operating System Real-time Transport Protocol Remote Terminal Unit RSVP Resource reSerVation Protocol SCADA Supervisory Control and Data Acquisition SGSN Serving GPRS Support Node Subscriber Identify Module...
-
Page 5: Table Of Contents
Contents CHAPTER 3 ROUTER CONFIGURATION ............13 3.1 CONNECTION......................13 CHAPTER 1 INTRODUCTION ...................1 3.2 CONFIGURATIONS ....................17 1.1 GENERAL ........................1 3.2.1 ROUTER STATUS ....................20 1.2 SYSTEM FEATURES ....................2 3.2.2 ONLINE HELP ......................21 1.3 SPECIFICATIONS .......................3 3.2.3 SYSTEM TOOLS.....................21 1.4 TYPICAL APPLICATIONS ..................4 3.2.4 NETWORK SETTING ....................26 1.5 TYPES DESCRIPTION ....................6 3.2.5 ROUTE CONFIGURATION ..................33... -
Page 6: Chapter 1: Introduction
Galaxy H7921 Mobile Router User Manual Chapter 1: Introduction Galaxy H7921 Mobile Router User Manual Chapter 1: Introduction GPRS network theoretically can provide a maximum bandwidth 171.2Kbps, Chapter 1 Introduction actually; it works at 40~100Kbps bandwidth (it depends on service provider’s operation policy). -
Page 7: Typical Applications
Galaxy H7921 Mobile Router User Manual Chapter 1: Introduction Galaxy H7921 Mobile Router User Manual Chapter 1: Introduction Real time clock Serial port (DB9): RS-232(DCE) or RS-485 (Optional) Serial port data rate: 300~115,200 bits/s Enhanced Features Ethernet interface: 10/100BaseT/RJ45 (Auto sense) Support multiple protocol conversion Configuration: WEB/Telnet or RS-232 Support data center and network management... - Page 8 Galaxy H7921 Mobile Router User Manual Chapter 1: Introduction Galaxy H7921 Mobile Router User Manual Chapter 1: Introduction GPRS or GPRS or GPRS or GPRS or CDMA 1X CDMA 1X CDMA 1X CDMA 1X Network Network Network Network Internet Internet Internet Internet GPRS or...
-
Page 9: Chapter 2 Installation
+5V power adapter 1 (+12V power adapter Optional) 接口： RS-232/Ethernet 电源：＋ 7.5~+12VDC Fixed part 1 pair 深圳市宏电技术开发有限公司 CAT-5 UTP cable Shenzhen Hongdian Technologies Co., Ltd. http://www.hongdian.com User manual 1 (CD-ROM) Made in Shenzhen, China Qualified & Repair Card Optional accessories Standard antenna... -
Page 10: Ground
Galaxy H7921 Mobile Router User Manual Chapter 2: Installation Galaxy H7921 Mobile Router User Manual Chapter 2: Installation Panels Connectors’ description: Front Panel COM: Serial port (RS-232/485), serial data port or console port. RJ45: 10/100BaseT auto sense Ethernet interface. DC: DC power supply interface (+5VDC, +7.5V~+24VDC optional, check the label before power on.) RESET: Reset button, press and hold for 5 seconds to reset the Galaxy router back to its default factory configurations. - Page 11 Galaxy H7921 Mobile Router User Manual Chapter 2: Installation Galaxy H7921 Mobile Router User Manual Chapter 2: Installation Attention! Normally, the power supply is +5VDC, +7.5V~+24VDC is optional. You should check the Galaxy router label before power on. Galaxy router should be powered by the AC adapter supplied by Hongdian. Hongdian will not guarantee Galaxy router performance if it is powered by any other unqualified AC adapter.
-
Page 12: Chapter 3 Router Configuration
Galaxy H7921 Mobile Router User Manual Chapter 3: Router Configuration Galaxy H7921 Mobile Router User Manual Chapter 3: Router Configuration Chapter 3 Router Configuration Your PC Your PC This chapter describes the Galaxy router parameters configuration before putting it in service. 1. - Page 13 Galaxy H7921 Mobile Router User Manual Chapter 3: Router Configuration Galaxy H7921 Mobile Router User Manual Chapter 3: Router Configuration Here, you can select “Obtain an IP automatically” or “Use the following IP address”. If Galaxy router is connected to your PC directly, it is possible to select “Obtain an IP automatically”.
- Page 14 Galaxy H7921 Mobile Router User Manual Chapter 3: Router Configuration Galaxy H7921 Mobile Router User Manual Chapter 3: Router Configuration The new add address should be limited at the subnet same as the Galaxy router, i.e. 192.168.8.xxx (xxx is the number from 2 to 254). Subnet mask should be 255.255.255.0;...
-
Page 15: Router Status
Galaxy H7921 Mobile Router User Manual Chapter 3: Router Configuration Galaxy H7921 Mobile Router User Manual Chapter 3: Router Configuration Main Menu Console Mode The Galaxy router RS-232 interface can configured for a data communication Router Status: Display major parameters port or a Console port. -
Page 16: System Tools
Galaxy H7921 Mobile Router User Manual Chapter 3: Router Configuration Galaxy H7921 Mobile Router User Manual Chapter 3: Router Configuration Configuration Profile 3.2.2 Online Help Mobile Network Testing Click “Start”->"Online Help", a new windows will be opened, and the below System Information System Log webpage picture appears. - Page 17 Galaxy H7921 Mobile Router User Manual Chapter 3: Router Configuration Galaxy H7921 Mobile Router User Manual Chapter 3: Router Configuration The remote management port can be changed, and also the timeout period can Mobile network testing function is a useful troubleshooting tool to locate the be specified.
-
Page 18: Network Setting
Galaxy H7921 Mobile Router User Manual Chapter 3: Router Configuration Galaxy H7921 Mobile Router User Manual Chapter 3: Router Configuration Click "Start"->"System Tools"->"System Information" menu to start this page. PPTP Log Click correspondence button to view the detail log information. Click the “Setting”... - Page 19 Galaxy H7921 Mobile Router User Manual Chapter 3: Router Configuration Galaxy H7921 Mobile Router User Manual Chapter 3: Router Configuration Default DNS: Configure the DNS server IP address, there are three DNS server can be defined. It can be modified in accordance with application requirement. Press "Save"...
- Page 20 Galaxy H7921 Mobile Router User Manual Chapter 3: Router Configuration Galaxy H7921 Mobile Router User Manual Chapter 3: Router Configuration GPRS: *99***1# (for China Mobile) CDMA 1x: #777 (for China Unicom) User Name and Password Input a correct user name and password provides by local mobile service provider;...
- Page 21 Galaxy H7921 Mobile Router User Manual Chapter 3: Router Configuration Galaxy H7921 Mobile Router User Manual Chapter 3: Router Configuration Local IP address is the Galaxy router IP address obtained from mobile network. Remote IP address is GGSN or PDSN IP address. DHCP Server: Enable or Disable.
-
Page 22: Route Configuration
Galaxy H7921 Mobile Router User Manual Chapter 3: Router Configuration Galaxy H7921 Mobile Router User Manual Chapter 3: Router Configuration Service Provider Host Name User ID/E-Mail Password/Key You can get the information from dynamic DNS service provider after successful application. Dynamic DNS service provider list will be added or deleted accordingly. - Page 23 Galaxy H7921 Mobile Router User Manual Chapter 3: Router Configuration Galaxy H7921 Mobile Router User Manual Chapter 3: Router Configuration At default setting, the network behind Galaxy router is isolated from outside Protocol: The “TCP”, “UDP” and both of them (ALL) can be specified. network to provide safety for the hosts.
- Page 24 Galaxy H7921 Mobile Router User Manual Chapter 3: Router Configuration Galaxy H7921 Mobile Router User Manual Chapter 3: Router Configuration Common used ports list: Security Configuration With the security configuration function, you can control data envelops security Protocol Service Port in/out your network.
- Page 25 Galaxy H7921 Mobile Router User Manual Chapter 3: Router Configuration Galaxy H7921 Mobile Router User Manual Chapter 3: Router Configuration For each policy, there are following items can be defined. Protocol: TCP, UDP, ICMP or All selectable. Source IP address/Netmask: Define source data envelops IP address and subnet.
- Page 26 Galaxy H7921 Mobile Router User Manual Chapter 3: Router Configuration Galaxy H7921 Mobile Router User Manual Chapter 3: Router Configuration Enable VPN L2TP Server: Tick it to start L2TP server Press “Add” button to create a client setting. Allocate from this IP range: Define the server IP address assignment range for L2TP client.
- Page 27 Galaxy H7921 Mobile Router User Manual Chapter 3: Router Configuration Galaxy H7921 Mobile Router User Manual Chapter 3: Router Configuration LNS: the L2TP server IP address or domain name. Enable VPN PPTP Server: tick it on to start the PPTP server. User Name: the user account created at the L2TP server.
- Page 28 Galaxy H7921 Mobile Router User Manual Chapter 3: Router Configuration Galaxy H7921 Mobile Router User Manual Chapter 3: Router Configuration PPTP Client Configuration IPSec Configuration (N/A for this version) Click "Start"->"Route Configuration"->"PPTP Client Configuration" menu to start this setup page to setup VPN PPTP Client parameters. Click "Start"->"Route Configuration"->"IPSec Configuration"...
-
Page 29: Special Setting
Galaxy H7921 Mobile Router User Manual Chapter 3: Router Configuration Galaxy H7921 Mobile Router User Manual Chapter 3: Router Configuration For Example: 3.2.6 Special Setting (N/A for this version) Galaxy router is not only integrated with router functionality, but also can be configured for many other applications. - Page 30 Galaxy H7921 Mobile Router User Manual Chapter 3: Router Configuration Galaxy H7921 Mobile Router User Manual Chapter 3: Router Configuration For many applications, it requires to keep the links always online. The heartbeat setting should be set to keep the links alive. However, the heartbeat is the data traffic packets and it may be charged (depends service provider).
- Page 31 Galaxy H7921 Mobile Router User Manual Chapter 3: Router Configuration Galaxy H7921 Mobile Router User Manual Chapter 3: Router Configuration If the serial port is enabled, the DSC IP address or domain name must be specified. Interface Select serial port interface type: RS-232 or RS-485; RS-485 is not available at this version hardware.
- Page 32 Galaxy H7921 Mobile Router User Manual Chapter 3: Router Configuration Galaxy H7921 Mobile Router User Manual Chapter 3: Router Configuration COM Port Setting: Before enabling this function, it is required to connect a dial-up modem (ie. V.90 modem) to the Galaxy router’s COM interface. A special cable will be needed. The cable wiring is showed at the below diagram.
-
Page 33: Hongdian Products
Galaxy H7921 Mobile Router User Manual Chapter 3: Router Configuration Galaxy H7921 Mobile Router User Manual Chapter 3: Router Configuration For example, dial a number 83890677, fill in the below code at the “Dial Script” filed. 3.2.7 Hongdian Products ----------------------------- Click "Start"->"Hongdian Products"... -
Page 34: Power Supply
Galaxy H7921 Mobile Router User Manual Chapter 3: Router Configuration Galaxy H7921 Mobile Router User Manual Chapter 4: Operation Instruction Hongdian Update tool Chapter 4 Operation Instruction TFTP update This chapter introduces Galaxy H7921 router operation introductions. H7921 is built-in with a tftp client. Operator can update the firmware via a TFTP sever. -
Page 35: Operation
Galaxy H7921 Mobile Router User Manual Chapter 4: Operation Instruction Galaxy H7921 Mobile Router User Manual Chapter 4: Operation Instruction (Note: Galaxy router’s LINK and PC’s Link should lights-up if it is connection). 4.2 Operation Check your TCP/IP setting. (Note: If the Galaxy router LAN IP is 192.168.8.1, your PC local connection IP address should be 192.168.8.xxx). -
Page 36: Appendix 1: Hypertext Terminal Setting
Galaxy H7921 Mobile Router User Manual Appendix 1: Hypertext Terminal Setting Galaxy H7921 Mobile Router User Manual Appendix 1: Hypertext Terminal Setting The COM port parameters should be specified. Select COM number (i.e. COM2), Bites per second, Data bits, Parity, Stop bits and and Flow control. Appendix 1: Hypertext Terminal Setting This Appendix introduces Microsoft Windows HyperTerminal setup instruction. - Page 37 Galaxy H7921 Mobile Router User Manual Appendix 1: Hypertext Terminal Setting Galaxy H7921 Mobile Router User Manual Appendix 1: Hypertext Terminal Setting 4. ASCII Setup Click “ASCII Setup” button, set ASCII parameters. 3. Host System Encoding Method Click “Input Translation” button, set host system encoding method. M80-792101-01 M80-792101-01...
-
Page 38: Appendix 2: Firmware Update Tool
Galaxy H7921 Mobile Router User Manual Appendix 2: Firmware Update Tool Galaxy H7921 Mobile Router User Manual Appendix 2: Firmware Update Tool Appendix 2: Firmware Update Tool This appendix describes Galaxy router firmware update tool user instructions. Galaxy H7921 Firmware Update Tool Set up the PC IP address subnet same as the router that will be updated. - Page 39 Galaxy H7921 Mobile Router User Manual Appendix 2: Firmware Update Tool Warning Do not disconnect or power off the router during firmware updating. Mobile network may be failed sometimes; it is a high risk to update firmware remotely. M80-792101-01...
