www.hongdian.com
User Manual
H8922 3G/4G Router

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the LCH8922 and is the answer not in the manual?

Questions and answers

Related Manuals for Shenzhen Hongdian Technologies LCH8922

Summary of Contents for Shenzhen Hongdian Technologies LCH8922

  • Page 1 www.hongdian.com User Manual H8922 3G/4G Router...
  • Page 2 Hongdian Technologies Corporation. Trademarks and Permissions and DTU are the trademarks and logos of Shenzhen Hongdian Technologies Corporation. Other trademarks and logos mentioned in this manual bel ong to other organizations related. Shenzhen Hongdian Technologies Corporation does not own the rights of other trademarks and logos.

  • Page 3: Foreword

    H8922 3G/4G Router User Manual Foreword Overview H8922 3G/4G router is designed and manufactured by Hongdian, it based on 3G/4G cellular network technology, industrial class quality. With its embedded cellular module, it has been widely used in finance, transportation, telecom, electricity, security system and other industries.

  • Page 4: Conventions

    H8922 3G/4G Router User Manual Conventions Symbol Conventions The symbols that may be found in this document are defined as follows. Symbol Description Indicates a potentially hazardous situation, which if not avoided, could result in equipment damage, data loss, performance degradation, or unexpected results.

  • Page 5: Modifying Records

    H8922 3G/4G Router User Manual GUI Conventions Convention Description Boldface Buttons, menus, parameters, tabs, window, and dialog titles are in boldface. For example, click OK. > Multi-level menus are in boldface and separated by the ">" signs. For example, choose File > Create > Folder. Keyboard Operations Format Description...
  • Page 6 H8922 3G/4G Router User Manual Doc. Time of Modifying Introduction Version Modifying H8951 hardware version update to V30 from V13. Remove serial port function. Doc. Version 1.1...

  • Page 7: Table Of Contents

    H8922 3G/4G Router User Manual Contents Foreword ............................ii Overview ....................................ii Product Version ..................................ii Organization ....................................ii Conventions....................................iii Modifying Records................................... iv 1 Product Introduction ........................4 About this chapter..................................4 1.1 Overview .....................................4 1.2 Product positioning ................................5 1.3 Function & Features ................................5 1.4 Specification..................................6 2 Product structure ..........................
  • Page 8 H8922 3G/4G Router User Manual 4.3.1 Login WEB GUI ..............................22 5 Router config ..........................23 About this chapter................................. 23 5.1 Overview ..................................23 5.2 Network configuration..............................23 5.2.1 LAN ..................................24 5.2.2 WAN..................................25 5.2.3 Modem ................................... 28 5.2.4 WLAN ..................................34 5.2.5 Parameter select (Recommend to Single module dual SIM version)............
  • Page 9 H8922 3G/4G Router User Manual 5.7.6 Network Test ............................... 100 5.7.7 Files ..................................101 5.8 Status ....................................107 5.8.1 Overview ................................107 5.8.2 Base Information ..............................107 5.8.3 LAN ..................................108 5.8.4 WAN..................................109 5.8.5 Modem ................................. 110 5.8.6 Routing Table ..............................112 5.9 RESET button function ..............................
  • Page 10 H8922 3G/4G Router User Manual Table Contents Table 2-1 H8922 3G/4G router size ............................8 Table 2-2 H8922 3G/4G router accessories.........................9 Table 4-1 LED instruction ..............................15 Table 5-1 LAN Parameter instruction ..........................24 Table 5-2 WAN connection type parameter instruction ....................25 Table 5-3 “Modem”...
  • Page 11 H8922 3G/4G Router User Manual Table 5-27 OSPF parameter instruction ..........................79 Table 5-28 OSPF route parameter instruction ......................... 80 Table 5-29 VPDN rule parameter instruction........................83 Table 5-30 Tunnel rule parameter instruction ......................... 85 Table 5-31 IPSec Phase 1 Parameter instruction ......................87 Table 5-32 IPSec Parameter instruction ..........................
  • Page 12 H8922 3G/4G Router User Manual Figure Contents Figure 1-1 Network structure..............................5 Figure 2-1 H8922 3G/4G router appearance........................7 Figure 2-2 H8922 3G/4G router views..........................8 Figure 2-3 H8922 3G/4G router drawing ..........................9 Figure 2-4 Front pannel ................................9 Figure 2-5 Back pannel ................................. 10 Figure 3-1 Pop out SIM slot ..............................
  • Page 13 H8922 3G/4G Router User Manual Figure 5-13 Connection type window..........................40 Figure 5-14 Link Backup ............................... 42 Figure 5-15 DHCP................................... 44 Figure 5-16 ICMP Check tab ..............................46 Figure 5-17 ICMP adding page ............................47 Figure 5-18 DDNS configuration ............................49 Figure 5-19 SNMP configuration ............................
  • Page 14 H8922 3G/4G Router User Manual Figure 5-50 IPSec phase 2 configuration ........................... 89 Figure 5-51 IPSec configuration tab ........................... 90 Figure 5-52 OpenVPN configuration page ........................92 Figure 5-53 Local Log tab ..............................95 Figure 5-54 Remote Log tab ..............................96 Figure 5-55 “NTP”...

  • Page 15: Product Introduction

    H8922 3G/4G Router User Manual Product Introduction About this chapter Chapter Content 1.1 Overview Simple introduction of H8922 3G/4G router Product Product Positioning of H8922 3G/4G router Positioning Function & Unique function & features features 1.4 Specification Detail specification of this router 1.1 Overview H8922 3G/4G router based on 3G/4G technology, except tradition router function like VPN, firewall, NAT, SNMP, DHCP.

  • Page 16: Product Positioning

    H8922 3G/4G Router User Manual 1.2 Product positioning H8922 3G/4G router widely used in Telecom, economic, advertisement, traffic, and environment protection business area. For example, in economic area, H8922 3G/4G router connect server by IPSec & GRE to ensure data security, and dual module online or dual module switch online ensured network availability.

  • Page 17: Specification

    H8922 3G/4G Router User Manual Available cellular network  LTE FDD: B1,B2,B4,B5,B7,B8,B12 LTE TDD: B38  LTE FDD: B1,B3,B7,B8,B20 LTE TDD: B40  LTE FDD: B1,B3,B7,B8,B20  LTE FDD: B2,B4,B5,B13,B17,B25  LTE TDD: B38,B39,B40 LTE FDD: B7  LTE FDD: B1/3/5/7/8/18/19/28 LTE TDD: B38/39/40/41 ...

  • Page 18: Product Structure

    H8922 3G/4G Router User Manual Product structure About this chapter Chapter Content 2.1 Hardware H8922 3G/4G router hardware. 2.2 Structure Structure of H8922 3G/4G router. 2.1 Hardware 2.1.1 Appearance & Size Appearance Figure 2-1 H8922 3G/4G router appearance Hongdian Corporation...

  • Page 19: Table 2-1 H8922 3G/4G Router Size

    H8922 3G/4G Router User Manual Size Table 2-1 H8922 3G/4G router size Model Dimension (mm) Interface  4×10/100Mb LAN interface H8922 176×105×25  1×10/100Mb WAN interface 3G/4G 4× SMA-K 3G/4G antenna interface  router 2× SMA-K Wi-Fi antenna interface  ...

  • Page 20: Accessories

    H8922 3G/4G Router User Manual Figure 2-3 H8922 3G/4G router drawing 2.1.2 Accessories Table 2-2 H8922 3G/4G router accessories Accessories name Number Note H8922 3G/4G router 1 pcs CD-ROM 1 pcs Optional 3G/4G antenna 1 or 2 pcs According to module number inside Wi-Fi antenna 1 pcs Optional...

  • Page 21: Figure 2-5 Back Pannel

    H8922 3G/4G Router User Manual Figure 2-5 Back pannel Hongdian Corporation...

  • Page 22: Installation Of H8922 3G/4G Router

    H8922 3G/4G Router User Manual Installation of H8922 3G/4G router About this chapter Chapter Content 3.1 Unpacking Unpack H8922 3G/4G router box and the packing list. 3.2 How to install How to install H8922 3G/4G router with SIM/UIM card and Ethernet cable .etc.

  • Page 23: Ethernet Cable Connection

    H8922 3G/4G Router User Manual Step 1 Use a small stick push the yellow button on router, the SIM slot will pop out as Figure 3-1 shows. Figure 3-1 Pop out SIM slot Step 2 Put SIM card in slot at proper direction as Figure 3-2 shows. Figure 3-2 SIM/UIM card install.

  • Page 24: Power Supply

    H8922 3G/4G Router User Manual Figure 3-3 Single Equipment Direct Connection Multiple equipment local area network connection H792x 3G/4G Router supports to simultaneously connect to multiple equipments through a switch (such equipments may not be in the same network segment) as shown in the figure below.
  • Page 25 H8922 3G/4G Router User Manual Notice Step 1 Check antenna connection. Step 2 Check SIM/UIM card installation to confirm SIM/UIM card is available. Step 3 Power on H8922 3G/4G router, the LEFT SIM slot is SIM 1, take it as a example: ...

  • Page 26: Before Config

    H8922 3G/4G Router User Manual Before config About this chapter Chapter Content 4.1 LED Status The meaning of LED status. 4.2 Local config How to local config H8922 3G/4G router. 4.3 Basic config Basic config & function. 4.1 LED Status There are LED on front panel of H8922 3G/4G router, they show how H8922 3G/4G router works.

  • Page 27: Local Config

    H8922 3G/4G Router User Manual LED name Status Dark：No module or no auto-dial  4.2 Local config Precondition  Already power on H8922 3G/4G router  Ethernet cable connect to H8922 3G/4G router You could specify a static IP or DHCP get IP for your computer. Static IP Step 1 Click “start >...

  • Page 28: Figure 4-2 Connection Properties

    H8922 3G/4G Router User Manual Figure 4-2 Connection properties Figure 4-3 Internet protocol (TCP/IP) Hongdian Corporation...
  • Page 29 H8922 3G/4G Router User Manual You could change your IP address or add a IP address in Advanced setting.  General configuration This method will temporarily interrupts the communication between the computer under configuration and LAN, and the specific parameter configuration is shown as below: IP address: 192.168.8.* (*indicates any integral between 2 to 254) Subnet mask: 255.255.255.0 Default gateway: 192.168.8.1...

  • Page 30: Figure 4-4 Advanced Tcp/Ip Settings

    H8922 3G/4G Router User Manual  Advanced configuration If you don’t want to interrupt local PC LAN communication and configure H8922 3G/4G Router when the former network configuration exists, it is required add route (IP). The configuration operation is shown as below: Click the “Advanced…”button to enter the interface as below: Figure 4-4 Advanced TCP/IP Settings Click the “Add (A)”button under the “IP address (R)”, and fill in the IP address that you...

  • Page 31: Figure 4-5 Tcp/Ip Address

    H8922 3G/4G Router User Manual Figure 4-5 TCP/IP address After the configuration is completed, click the “Add”. By now the computer has a route to router H8922. Note: “Default gateway” depends on whether the configuration computer connects with Internet through original local network configuration. If Internet is accessed through original local network, the default gateway setting does not need to be modified;...

  • Page 32: Figure 4-6 Connectivity Check

    H8922 3G/4G Router User Manual Network Check Step 1 IP configuration check Use the command of ipconfig to check whether the IP address is correctly set or added. You can enter DOS mode and key-in command: ipconfig, for instance: C:\>ipconfig Windows IP Configuration Ethernet adapter local connection: Connection-specific DNS Suffix.

  • Page 33: Basic Config

    H8922 3G/4G Router User Manual 4.3 Basic config Through this chapter, you could achieve basic function: visit internet. 4.3.1 Login WEB GUI Step 1 Run a Internet Explorer and visit “http://192.168.8.1/”, to enter identity page. Figure 4-7 User identity page Step 2 User should use default user name and password when log in for the first time: User name: admin Password: admin...

  • Page 34: Router Config

    H8922 3G/4G Router User Manual Router config About this chapter Chapter Content 5.1 Overview Enter H8922 3G/4G Router WEB GUI to configure Network Network configuration & function configuration 5.3 Application Advanced function of router like timing operation, link backup .etc. 5.4 Security Security setting of H8922 5.5 Forward...

  • Page 35: Lan

    H8922 3G/4G Router User Manual 5.2.1 LAN LAN setting used to manage local area network PC which connect to H8922, make them could visit internet and the network segment connectivity normal. Step 1 Login H8922 WEB GUI. Step 2 Single click “Network > LAN”. Figure 5-1 LAN window Step 3 LAN parameter.

  • Page 36: Wan

    H8922 3G/4G Router User Manual After change the LAN IP, if pa ge has no response anymore, please make sure your PC address is in the same network segment, or set a new IP to your PC to insure that. ---END 5.2.2 WAN Wired connect to Internet by static IP, DHCP or PPPoE.
  • Page 37 H8922 3G/4G Router User Manual Parameter Details Operation ”Connection Type” select ”PPPoE” Service Name Configure PPPoE WORD type, up to 64 characters, service name, which is not blank, please refer to usually used for parameters regulation format identification and judgment between client and server, and is usually provided by the service side, while...
  • Page 38 H8922 3G/4G Router User Manual Parameter Details Operation Disable  Compression Negotiate which compress control  Negotiation Control Protocol protocol used on PPP link  Disable Address/Control Whether compress IP address  Negotiation Compression Disable  Protocol Field Whether compress Whether Negotiation ...

  • Page 39: Modem

    H8922 3G/4G Router User Manual Parameter Details Operation default-asyncmap  Step 4 Single click “save” icon. ---END 5.2.3 Modem H8922 3G/4G Router core function, connect Internet by cellular modem, H8922 3G/4G Router support single modem single SIM, single modem dual SIM, dual modem dual SIM, those three working type provide internet connection to customers.

  • Page 40: Table 5-3 "Modem" Parameter Instruction

    H8922 3G/4G Router User Manual Figure 5-4 Modem page Input suitable parameter. Table 5-3 “Modem” Parameter instruction Parameter Details Operation Auto-dialup current modem, if all Enable   Auto-dialup modem auto-dialup disabled, router will Disable  not auto-dialup If your router has dual cellular ...
  • Page 41 H8922 3G/4G Router User Manual Parameter Details Operation Network type force to 2.5G or 3G/4G  Network type Dropdown List WCDMA:  auto  wcdma  edge EVDO: auto  evdo  cdma  HSPA+ module, its network type is not mandatory: selecting “3G”...
  • Page 42 H8922 3G/4G Router User Manual Parameter Details Operation Compression Negotiation   Disable Protocol Field Whether compress Whether  Negotiation Compression compress IP address Disable  VJ TCP/IP Header Whether allow TCP/IP Negotiation  Compress communicate by compressing VJ  Disable Connection-ID Whether...

  • Page 43: Figure 5-5 Single Module Single Sim/Dual Module Dual Sim

    H8922 3G/4G Router User Manual Figure 5-5 Single module single SIM/dual module dual SIM Figure 5-6 Single module dual SIM Hongdian Corporation...

  • Page 44: Figure 5-7 Advanced Setting

    H8922 3G/4G Router User Manual Figure 5-7 Advanced setting Single click “save” icon to finish. Grey i con means enabled. ---END Hongdian Corporation...

  • Page 45: Wlan

    H8922 3G/4G Router User Manual 5.2.4 WLAN H8922 3G/4G Router provides WLAN AP, Station Client, Repeater three functions, through AP function, H8922 3G/4G Router can provide wireless LAN hotspots; through Station client function, it allows H8922 3G/4G Router access to other AP devices, such H8922 3G/4G Router downlink machine can access the Internet via the AP connection;...

  • Page 46: Table 5-4 Wlan Parameter Instruction

    H8922 3G/4G Router User Manual Figure 5-9 Station mode configure interface Figure 5-10 Station scan signal interface Step 4 “WLAN” configure parameter instruction, parameter instruction as Table 5 -4. Table 5-4 WLAN parameter instruction Parameter Details Operation WLAN Enable disable WLAN Dropdown List Status...
  • Page 47 H8922 3G/4G Router User Manual Parameter Details Operation Basic Setting SSID WLAN server identity WORD type, max to 32Bytes  WLAN work mode, support Wireless Dropdown List ap/station Mode  station  Network WLAN network mode, Dropdown List Mode different network models are ...
  • Page 48 H8922 3G/4G Router User Manual Parameter Details Operation manually add the SSID The router is used as station, Dropdown List Distribution and the router can get the IP  dhcp：get IP address from DHCP （when address when it is connected static：manually set IP address ...

  • Page 49: Parameter Select (Recommend To Single Module Dual Sim Version)

    H8922 3G/4G Router User Manual Parameter Details Operation WLAN connection, authentication fails, disconnect WLAN connection When the working mode select s ta tion or repea ter, H8922 Router will automa ti cally ma tch according to the selected AP and the corresponding encryption algorithm (to keep consistent with AP encryption); sha red key upda te interval is requi red to fill in the connections of AP key and interval .

  • Page 50: Table 5-5 Parameter Instruction

    H8922 3G/4G Router User Manual Figure 5-12 Add rule Table 5-5 Parameter instruction Parameter Details Operation  Enable Status For enabled rule: Only one rule is  Disable running at one time, when it checks failed, next rule start running For disabled rule: all related interface also disabled Basic settings...

  • Page 51: Table 5-6 Connection Type Parameter Instruction

    H8922 3G/4G Router User Manual Parameter Details Operation Interface name Set related modem interface Dropdown List choose, current available option will show below Check method If state, router will check link state Dropdown List If ICMP, router will ping the ICMP state ...

  • Page 52: Link Backup

    H8922 3G/4G Router User Manual Parameter Details Operation MASQ route  Default Gateway, do not suggest to change Default Default route Dropdown List route Gateway If default route is wan static IP, need Example: specify gateway and DNS 192.168.10.254 DNS type If Interface, will get DNS automatically Dropdown List ...

  • Page 53: Table 5-7 Link Backup Parameter

    H8922 3G/4G Router User Manual Figure 5-14 Link Backup Table 5-7 Link Backup Parameter Parameter Details Operation Enable  Status Enable or Disable Link Backup feature  Disable Value area: 0-9  Rule Name Link Backup rule name identification Note: 0 can act as chain link or backup link, 1-9 only can act as backup link 1-9 can take the priority according to the...

  • Page 54: Dhcp Service

    H8922 3G/4G Router User Manual Parameter Details Operation cost of network overhead and charges. Cold refers to only the interface of current working link is enabled, and the others, as the interfaces of non-working link, are in offline state. If the current link is main link, shows the ...

  • Page 55: Table 5-8 Dhcp Parameter

    H8922 3G/4G Router User Manual Figure 5-15 DHCP Step 3 Configure DHCP parameter. Step 4 DHCP parameter instructions are as Table 5-8. Table 5-8 DHCP Parameter Parameter Details Operation Enable  DHCP Enable or Disable DHCP feature Disable  Server Basic Settings（DHCP is not recommended configure in the case of no special network requirement) Dropdown List...
  • Page 56 H8922 3G/4G Router User Manual Parameter Details Operation Start IP When IP pool select custom Manual input configuration, configure the DHCP Format：A.B.C.D/Mask pool start IP address Example：192.168.8.2 End IP When pool select custom Manual input configuration, configure the DHCP Format：A.B.C.D/Mask pool end IP address Example：192.168.8.254 ...

  • Page 57: Application Program Configuration

    H8922 3G/4G Router User Manual ---END 5.3 Application program configuration Based on years of customer experience for different applications, besides SNMP, DDNS, H8922 3G/4G router has developed many functions for wireless network equipment, such as ICMP check, interface flow check function, M2M terminal management function, task management function and waking on demand function.

  • Page 58: Table 5-9 Icmp Check Rules Parameter Instruction

    H8922 3G/4G Router User Manual Figure 5-17 ICMP adding page Configure the ICMP check parameter. Table 5-9 ICMP check rules Parameter instruction Parameter Details Operation ICMP check To enable or disable ICMP check Button service rules, multiple rules can be used Enable ...
  • Page 59 H8922 3G/4G Router User Manual Parameter Details Operation recognize ICMP check fails Value area ：1～65535 Retry Check time interval and max check times/normal failure times when link is OK, if Unit: second/time interval check failure times reaches the max times, then “timeout action ” will be executed, e.g.

  • Page 60: Ddns Configuration

    H8922 3G/4G Router User Manual Click “refresh” to refresh the page. ---END 5.3.2 DDNS configuration Network of SIM/UIM shall be a public address so that router can be visited for a DDNS. Step 1 Log-on WEB GUI of H8922 3G/4G router. Step 2 Click “Applications”...
  • Page 61 H8922 3G/4G Router User Manual Parameter Details Operation When “custom” in WORD type, max 64 bytes “service provider” is selected, “Server IP or Domain” will be configured. Default is standard DDNS protocol. for customized protocol, please contact our engineer Server Port Set the port number of Value area: 1～65535 the DDNS server provided...

  • Page 62: Snmp Configuration

    H8922 3G/4G Router User Manual Parameter Details Operation Update Set the interval of the Value area: 120～86400 Interval DDNS client obtains new Unit: seconds IP, suggest 240s or above Step 4 Click “Save” to complete DDNS configuration DDNS in China : 88IP (www.88i p.net), 3322 (www.3322.org) DDNS outside of China : DNSEXIT (www.dnsexi t.com),...

  • Page 63: M2M Configuration

    H8922 3G/4G Router User Manual Step 3 Configure SNMP parameter. Table 5-11 SNMP Parameter instruction Parameter Details Operation SNMP service To enable or disable SNMP service Options: Enable  Disable  Basic Config Port SNMP port, suggest to be default Value area: 1～65535 port161 Default: 161...

  • Page 64: Table 5-12 M2M Parameter Instruction

    H8922 3G/4G Router User Manual upgrading, firmware upgrading, parameter configuration, monitor the network strength, time delay, flow. Its configuration is as follows: Step 1 Log-on WEB GUI of H8922 3G/4G router. Step 2 Click “Applications > M2M” to open M2M configuration tab. Figure 5-20 M2M configuration Step 3 Configure M2M parameter.

  • Page 65: Timing Configuration

    H8922 3G/4G Router User Manual Parameter Details Operation Heartbeat Time interval to send heartbeat Value area: 1～65535 Interval which maintains the like with M2M Unit: seconds platform server. The heartbeat includes the network status info which will update the network info of the M2M platform Retry Times There is a retry mechanism for...

  • Page 66: Table 5-13 Timing Task Parameter Instruction

    H8922 3G/4G Router User Manual Figure 5-22 To add timing task Step 4 Configure timing task parameter. Table 5-13 Timing task parameter instruction Parameter Details Operation Status To enable or disable a options timing task. Some task shall Enable  be enabled together with Disable ...
  • Page 67 H8922 3G/4G Router User Manual Parameter Details Operation during the configured time period. Modem will be offline (no dialing) for other time Schedule This is Linux shell WORD type. Max 64 digits command. Usually suggested not to use it. In case of need, please contact our technical engineers...

  • Page 68: Wake Up Configuration

    H8922 3G/4G Router User Manual 5.3.6 Wake up configuration 3G/4G fee is mostly based on flow. H8922 3G/4G router can get on/off line on demand. It supports on/offline or reboot triggered by voice, SMS or data. It supports max 10 cell phone Nos.
  • Page 69 H8922 3G/4G Router User Manual Parameter Details Operation Add phone Number Phone Phone No to trigger the router WORD type. Max 32 digits. Number action. One phone No for one action of one modem. Triggered action includes  Task type Dropdown List options modem-up, modem-down,...

  • Page 70: Gps Configuration (Optional)

    H8922 3G/4G Router User Manual One phone number be set for acti ons of di fferent modems , but cannot be set as di fferent a ctions of one modem. It’s OK for ei ther SIM of the two SIMs of H8922 3G/4G router to open SMS or voice functi on, no matter whi ch slot to be ins talled.

  • Page 71: Security

    H8922 3G/4G Router User Manual Parameter Details Operation Product Mark The identification of the Word Type, max length is 64 router GPS, used for identifying the device Local Port The router port for reporting Value: 1-65535 the GPS data Server IP or Server IP or domain for Format：A.B.C.D/Mask or Word Domain...

  • Page 72: Figure 5-25 Ip Filter Tab

    H8922 3G/4G Router User Manual Figure 5-25 IP Filter tab Step 3 In the forwarding filtering rules.  Black List：The default allows packet forwarding, in line with the list of "discarded" rules packet cannot be forwarded through the router.  White List：The default refuses packet forwarding, in line with the list of "accept"...

  • Page 73: Table 5-16 Ip Filter Parameter Instruction

    H8922 3G/4G Router User Manual Figure 5-27 IP Filter “Forward” type Table 5-16 IP filter parameter instruction Parameter Details Operation Type Select a filter type, you can choose Dropdown List options according to their needs, "Input" or "Forward" Input: whether to allow access to the router Forward: whether to allow the router forwarding...

  • Page 74: Domain Filter

    H8922 3G/4G Router User Manual Parameter Details Operation Dropdown List options  Protocol Protocol used by IP packets    icmp   The source IP address of the packet Source IP Manual input Format：A.B.C.D/Mask Source Port The source Port of the packet, when Value area: 1-65535 or the protocol choose "icmp", it don’t [1-65535], it can be a...

  • Page 75: Table 5-17 Domain Filter Parameter Instruction

    H8922 3G/4G Router User Manual Step 7 Click “Security> Domain Filter” to open “Domain Filter” tab. Figure 5-28 Domain filter tab  Black list: websites in the blacklist cannot be visited. Click “black list” to forbid visiting the websites in the list. ...

  • Page 76: Table 5-18 Mac Filter Explanation

    H8922 3G/4G Router User Manual MAC Filter Step 10 Log-on WEB GUI of H8922 3G/4G router. Step 11 Click “Security> MAC Filter” to open “MAC Filter” tab. Figure 5-30 MAC Filter tab Table 5-18 MAC Filter explanation Paramet Details Operation Input configuration Blacklist: rules in blacklist cannot visit router, ...

  • Page 77: Forward Configuration

    H8922 3G/4G Router User Manual Figure 5-31 MAC Filter configuration Table 5-19 MAC Filter Parameter instruction Parameter Details Operation Basic Settings MAC to be filtered WORD type MAC format: XX:XX:XX:XX:XX:XX Default Action Default actions of the rule. Can be To choose “accept” or “accept”...

  • Page 78: Nat

    H8922 3G/4G Router User Manual 5.5.2 NAT DNAT configuration rule DNAT is used to replace the destination address of packets accessing external network, router will replace the destination address of packet accessing external network into the user custom settings. Step 1 Log-on WEB GUI of H8922 3G/4G router. Step 2 Click “Forward >...

  • Page 79: Table 5-20 Dnat Parameter Instruction

    H8922 3G/4G Router User Manual Figure 5-33 DNAT rule configuration Step 4 Select “DNAT” in NAT Type, to configure DNAT rule parameter. Table 5-20 DNAT Parameter instruction Parameter Details Operation Basic Settings Protocol Supports “TCP”, “UDP”, Select from Dropdown List “ICMP”...

  • Page 80: Figure 5-34 Snat Rule Configuration

    H8922 3G/4G Router User Manual Parameter Details Operation Original port The port of external IP, Value area: 1～65535 the port need to be replaced Mapping Internal IP address e.g. 192.168.8.1 address Mapping port The port of Internal IP Value area :1～65535 address Step 5 Single click “save”...

  • Page 81: Table 5-21 Snat Rule Instruction

    H8922 3G/4G Router User Manual Table 5-21 SNAT rule instruction Parameter Details Operation Dropdown List  Protocol Convert some kind of protocol  packets into address   icmp  Original The source address need to be Manual input Address replaced Format1：A.B.C.D Format2: A.B.C.D/Mask...

  • Page 82: Static Routing

    H8922 3G/4G Router User Manual Figure 5-35 MASQ configuration Step 14 Configure MASQ rule parameter. Table 5-22 MASQ rule Parameter instruction Parameter Details Operation NAT Type To select “MASQ” Select “MASQ” Interface Interface includes: Select from Dropdown List  br0: use br0 interface as commutation address between router &...

  • Page 83: Figure 5-36 Static Routing Interface

    H8922 3G/4G Router User Manual based on the source address that match with the policy to forward the packets (forwarding router detects the received packet's source address, and then forward packages according to the source which matches policy route) and policy routing priority, use numbers 3 to 252 to differentiate, the smaller number with higher priority.

  • Page 84: Table 5-23 Static Routing Parameter Instruction

    H8922 3G/4G Router User Manual Figure 5-38 Policy Routing Interface Parameter Instruction as Table 5-24. Table 5-23 Static Routing Parameter Instruction Parameter Details Operation Basic Setting Dropdown List  Routing Type To select “Static Route” or “Policy Route” When Routing Type is “Static Route” Network Set the destination IP address Manual input...

  • Page 85: Qos (Optional)

    H8922 3G/4G Router User Manual Parameter Details Operation Interface  Network It can be configured when Manual input “static IP” is selected in source Format1: A.B.C.D/Mask type, by adding IP address or subnet manually. Source When source type is policy Dropdown List Interface route, need to manually set...

  • Page 86: Table 5-24 Qos Parameter Instruction

    H8922 3G/4G Router User Manual not delayed or dropped, while ensuring the efficient operation of the network, our H8922 3G/4G Router supports custom QoS services. Step 1 Log-on WEB GUI of H8922 3G/4G router. Step 2 Click “Forward > QoS” to open “QoS” tab, as Figure 5-52. Figure 5-39 QoS interface Step 3 QOS configuration parameter, configuration parameter instruction as Table 5 -25.

  • Page 87: Dynamic Routing (Optional)

    H8922 3G/4G Router User Manual Parameter Details Option  br0：QOS interface is LAN modem：QOS interface is modem   modem2：QOS interface is modem2 Network The network address that flow in Full in destination address and out via the QOS interface, is the and subnet mask object of speed limit.

  • Page 88: Table 5-25 Rip Parameter Instruction

    H8922 3G/4G Router User Manual Step 1 Log-on WEB GUI of H8922 3G/4G router. Step 2 Click “Forward > RIP” to open “RIP” tab, as Figure 5-53. Figure 5-40 RIP interface Parameter Instruction as Table 5-26. Table 5-25 RIP Parameter Instruction Parameter Details Operation...

  • Page 89: Table 5-26 Rip Parameter Instruction

    H8922 3G/4G Router User Manual Figure 5-41 RIP route configuration interface Step 4 Configure RIP route parameter instruction, as Table 5-27. Table 5-26 RIP parameter instruction Parameter Details Operation Basic Setting Add Type Add the type of RIP Click the button to select Add Type route When it is “Network”, need to ...

  • Page 90: Table 5-27 Ospf Parameter Instruction

    H8922 3G/4G Router User Manual OSPF configuration OSPF (Open Shortest Path First) protocol is one of the (Interior Gateway Protocol), the most widely used IGP, for a single AS (autonomous system) in the routing decisions for large networks. OSPF business can be based whether the user needs to be configured at the factory H8922 3G/4G Router.

  • Page 91: Table 5-28 Ospf Route Parameter Instruction

    H8922 3G/4G Router User Manual Parameter Details Operation Redistribute Enable or disable Redistribute Static Click the button to select Static Enable  Disable  Redistribute Enable or disable Redistribute Click the button to select Kernel Kernel Enable  Disable  Step 8 Click “Add”...

  • Page 92: Vpn Configuration

    H8922 3G/4G Router User Manual Neighbor The router can reach in Manual input the next hop Format1: A.B.C.D/Mask When Add Type is “Interface”, Dropdown List  Interface The interface of the  Name router  modem modem2  eth1  eth0 ...

  • Page 93: Vpdn Configuration

    H8922 3G/4G Router User Manual 5.6.2 VPDN configuration VPDN stands for Virtual Private Dial-up Networks. Now VPDN supports L2TP and PPTP Step 1 Log-on WEB GUI of H8922 3G/4G router. Step 2 See “4.3.1 Login WEB GUI Step 3 Click “VPN > VPDN” to open “VPDN” tab. Figure 5-44 VPDN configuration Step 4 Click “Add”...

  • Page 94: Table 5-29 Vpdn Rule Parameter Instruction

    H8922 3G/4G Router User Manual Table 5-29 VPDN rule parameter instruction Parameter Details Operation VPDN service To enable or disable the VPDN rule Click “Enable” Basic Settings Interface Name of this VPDN rule Cannot be modified after name save. protocol VPDN protocol includes Select from Dropdown List, cannot be modified...

  • Page 95: Tunnel Configuration

    H8922 3G/4G Router User Manual 5.6.3 Tunnel configuration Tunnel technology transfers data between the networks through the Internet infrastructure. In the whole process of transmission, when the encapsulated data package delivered on a public Internet, the logic path which the packet passes through is called tunnel.

  • Page 96: Ipsec Configuration

    H8922 3G/4G Router User Manual Table 5-30 Tunnel rule parameter instruction Parameter Details Operation IP Tunnel To enable or disable IP tunnel Click “Enable” Service service Basic Settings Tunnel name Name of the tunnel, cannot be Input the name of tunnel modified after save Tunnel Mode Tunnel mode:...

  • Page 97: Figure 5-48 Ipsec Tab

    H8922 3G/4G Router User Manual Figure 5-48 IPSec tab Step 3 Click “Add” to add a new IPSec rule. There are 3 phases for IPSec configuration: Phase 1 parameter Hongdian Corporation...

  • Page 98: Table 5-31 Ipsec Phase 1 Parameter Instruction

    H8922 3G/4G Router User Manual Figure 5-49 IPSec phase 1 configuration Table 5-31 IPSec Phase 1 Parameter instruction Parameter Details Operation Basic Settings Select To select which phase of IPSec, Select “Phase 1” phase 1, phase 1 or phase IPSec Policy Name Name of phase 1, mainly to To input the name of phase 1.
  • Page 99 H8922 3G/4G Router User Manual Parameter Details Operation Authenticatio To select authentication Select from Dropdown List, presently only “PSK” supported Pre Share Key To set pre share key Max 24 letters Self Identify To set the self ID of IPSec To input the ID, need to match the ID of other side Match...

  • Page 100: Table 5-32 Ipsec Parameter Instruction

    H8922 3G/4G Router User Manual Figure 5-50 IPSec phase 2 configuration Table 5-32 IPSec Parameter instruction Parameter Details Operation Basic Settings Select To select which phase of Select “Phase 2” IPSec, phase 1, phase 1 or phase IPSec Policy Name Name of phase 2, mainly to To input the name of phase 2.

  • Page 101: Table 5-33 Ipsec Parameter Instruction

    H8922 3G/4G Router User Manual Parameter Details Operation To open or close PFS Select from Dropdown List Lifetime IPSec SA key life time Value area: 120～86400 Unit: second Transport Supports tunnel, transport Select from Dropdown List Mode and auto. Local Subnet Set local subnet No need to set for “transport”...

  • Page 102: Openvpn Configuration

    H8922 3G/4G Router User Manual Parame Details Operation Select To select which phase of Select “IPSec” IPSec, phase 1, phase 1 or phase IPSec Interfac Name of this phase Input name e Name Match To select a matching name Select from Dropdown List. Phase1 of “phase1”...

  • Page 103: Table 5-34 Openvpn Parameter Instruction

    H8922 3G/4G Router User Manual Step 3 Click "VPN > OpenVPN".Enter "OpenVPN" page, as shown in Figure 2-4. Figure 5-52 OpenVPN configuration page Step 4 Configure OpenVPN parameter. Step 5 The parameter instruction is shown in Table 2 -1. Table 5-34 OpenVPN parameter instruction Parameter Detail Operation...
  • Page 104 H8922 3G/4G Router User Manual Parameter Detail Operation Dev represents the network Dropdown list options: interface type, and supports two Select the required types: working mode from Tun(OSI Layer 3):Simulates dropdown list.  network layer device to operate Demand consistent with the third layer data packets, such peer.
  • Page 105 H8922 3G/4G Router User Manual Parameter Detail Operation Authenticatio Configuring the VPN data transfer Dropdown list options: mode: Select the required data  SSL: encrypt the network transfer type from connection in transport layer, high dropdown list. safety factor.  Text: transport with text form during transmission, low safety factor...

  • Page 106: System Configuration

    H8922 3G/4G Router User Manual 5.7 System configuration 5.7.1 Overview “System” can let you know the status of router, firmware upgrading and other maintenance. 5.7.2 Local Log Step 1 Log-on WEB GUI of H8922 3G/4G router. Step 2 Click “System > Local Log” to open “Local Log” tab. Figure 5-53 Local Log tab Step 3 Select type of “Local Log”...

  • Page 107: Remote Log

    H8922 3G/4G Router User Manual To see “local log”, “remote log” mus t be enabled. ---END 5.7.3 Remote Log Step 1 Log-on WEB GUI of H8922 3G/4G router. Step 2 Click “System > Remote Log” to open “Local Log” tab. Figure 5-54 Remote Log tab Step 3 Configure “Remote Log”...

  • Page 108: Clock

    H8922 3G/4G Router User Manual 5.7.4 Clock Step 1 Log-on WEB GUI of H8922 3G/4G router. Step 2 Click “System > Clock” to open “Clock” tab. Figure 5-55 “NTP” Time Synch. Figure 5-56 Manual Time Synch. Type Step 3 Set “clock” parameters. Table 5-36 Clock Parameter instruction Parameter Details...

  • Page 109: Account

    H8922 3G/4G Router User Manual Select “NTP”  Time Synch. Type Type to synchronize system “Manual” time When select “NTP” in “Time Synch. Type” NTP Server IP or IP or domain of NTP server Select from Dropdown Domain List NTP Server Backup Backup NTP server Manual input server domain or IP address...

  • Page 110: Table 5-37 Account Parameter Instruction

    H8922 3G/4G Router User Manual Figure 5-57 Account tab Step 3 Set account parameters. Table 5-37 Account parameter instruction Parameter Details Operation Select from Dropdown List  Account Type Visit the router on web Account Level Level of account to login Select from Dropdown List router Admin: can view and change the...

  • Page 111: Network Test

    H8922 3G/4G Router User Manual Parameter Details Operation Default: 80 Step 4 Click “Save” to finish configuration. After saving, user needs to login again. ---END 5.7.6 Network Test Network Test This function includes Ping function and Trace router function. Step 1 Log-on WEB GUI of H8922 3G/4G router. Step 2 Click “System >...

  • Page 112: Files

    H8922 3G/4G Router User Manual Parameter Details Operation tested domain to be tested Ping To use Ping to test link Click “Ping” Trace To use Trace command to test hops Click “Trace” from the router to destination Result Test result ---END 5.7.7 Files Firmware Setting...

  • Page 113: Figure 5-60 Add An Ip Address

    H8922 3G/4G Router User Manual Step 3 Click “Browse” to select upgrading file and then click “Upgrade”. ---END CFE mode upgrading If upgrading file is larger than 6MB, CFE mode upgrading shall be used to upgrade. Step 4 Add an IP address 192.168.1. Figure 5-60 Add an IP address Step 5 Press the RESET/DEF interface.

  • Page 114: Figure 5-61 Cfe Mode Upgrading

    H8922 3G/4G Router User Manual Figure 5-61 CFE mode upgrading Step 7 Click “Browse” to select upgrading file, and then click “Upload” to begin upgrading. Figure 5-62 CFE upgrading page Upgrading will need 4-6 minutes, if RUN light is on, upgrading is OK. You can also PING br0 address on your PC (ping 192.168.8.1 –t).

  • Page 115: Figure 5-63 Backup Setting

    H8922 3G/4G Router User Manual Figure 5-63 Backup setting page After import, router will reboot automati call y. “Key”: i f key is i nput when export configura tion file, this key need to be input in i mport. Not more than 8 di gits for key.

  • Page 116: Figure 5-64 Factory Setting

    H8922 3G/4G Router User Manual Figure 5-64 Factory setting page  Save: to save the current setting as default factory configuration setting.  Load: to resume default factory setting. Patch operation function H8922 3G/4G router supports to delete patch. Hongdian Corporation...

  • Page 117: Figure 5-65 Patch Operation

    H8922 3G/4G Router User Manual Figure 5-65 Patch operation  Delete: to delete patch. Reboot/Refresh Click “Reboot” to restart the router, or click “Refresh” to refresh the page. Hongdian Corporation...

  • Page 118: Status

    H8922 3G/4G Router User Manual Figure 5-66 Reboot /Refresh 5.8 Status 5.8.1 Overview Status provides the basic info, network status info, router info of H8922 3G/4G Router. 5.8.2 Base Information Step 1 Log-on WEB GUI of H8922 3G/4G router. Step 2 Click “Status > Base information” to open “Base Information” tab. Figure 5-67 Base Information tab Hongdian Corporation...

  • Page 119: Lan

    H8922 3G/4G Router User Manual Table 5-39 Base information Parameter instruction Parameter Details Operation Router Router model info Model Router SN Router Serial No info Hardware Router hardware version info version Software OS and application software info. version 5.8.3 LAN Step 1 Log-on WEB GUI of H8922 3G/4G router.

  • Page 120: Wan

    H8922 3G/4G Router User Manual 5.8.4 WAN Step 1 Log-on WEB GUI of H8922 3G/4G router. Step 2 Click “Status > WAN” to open “WAN” tab. There are three types of WAN status: static IP/DHCP/PPPOE. Figure 5-69 Static IP WAN status Figure 5-70 DHCP WAN status Hongdian Corporation...

  • Page 121: Modem

    H8922 3G/4G Router User Manual Figure 5-71 PPPoE WAN status Table 5-41 WAN Parameter instruction Parameter Details Operatio WAN status To show the current WAN is used or not WAN Type To show the current WAN type Local IP To show the local IP of WAN interface Subnet mask To show the subnet mask To show the MAC address of the router...

  • Page 122: Table 5-42 Modem Parameter Instruction

    H8922 3G/4G Router User Manual Figure 5-72 Modem Status page Table 5-42 Modem Parameter instruction Parameter Details Operatio Modem To show the current modem name Select Up tome To show the current on line time of the modem Unit: second Modem To show the Router’s status to link to the mobile Status...

  • Page 123: Routing Table

    H8922 3G/4G Router User Manual Parameter Details Operatio IP Address To show the external network IP address which the router links To show which DNS router is using SIM Status Status of current SIM 5.8.6 Routing Table Step 1 Log-on WEB GUI of H8922 3G/4G router. Step 2 Click “Status >...

  • Page 124: Reset Button Function

    H8922 3G/4G Router User Manual Parameter Details Operation Static route Policy route Priority Priority the router select route ---END 5.9 RESET button function “RESET” button is on the rear panel and next to power interface. This button can be used when the router is in use or when the router is turned on.

  • Page 125: Overview

    H8922 3G/4G Router User Manual 6.4 VPN H8922 3G/4G Router VPN setting 6.5 Timing Task Set Timing task on H8922 3G/4G Router 6.1 Overview H8922 3G/4G Router commonly used function includes wake up, parameter switch, VPN, etc. 6.2 Awake function Typical case H8922 3G/4G router support wake up function, means router will not auto-dial after power on, but dial triggered by data or call or SMS.

  • Page 126: Parameter Select

    H8922 3G/4G Router User Manual Figure 6-1 Wake up/trigger setting example Effect By this setting, after router power on, if there are data trigger or you could call/SMS SIM1 or SIM2 number from 8618888888888 to trigger corresponding SIM online, modem will dial online, After 3600s, router will offline.

  • Page 127: Figure 6-2 Rules Setting

    H8922 3G/4G Router User Manual Parameter Select Let us check an example: Please set the “Parameter select” of modem and modem2 separately Set rules as below Figure 6-2 Rules setting Hongdian Corporation...

  • Page 128: Figure 6-3 Parameter Select Setting 1

    H8922 3G/4G Router User Manual Figure 6-3 Parameter select setting 1 Hongdian Corporation...

  • Page 129: Vpn

    H8922 3G/4G Router User Manual Figure 6-4 Parameter select setting 2 When a working modem is offline, router will run parameter select rule: “check icmp”, check the IP you set by ping, in this case, 8.8.8.8. After 3 times failure, router will switch to modem2, and dial online works again.

  • Page 130: Figure 6-5 Build Ipsec

    H8922 3G/4G Router User Manual Figure 6-5 Build IPSec PC1 connect H8922 then build IPSEC link by VPN function of H8922 with company router. I assume using IPSec tunnel mode, H8922 end local network 192.168.86.1/24, company server end 192.168.99.1/24, by IPSEC, two LAN could communicate. Parameter Setting Figure 6-6 IPSec Phase 1 Hongdian Corporation...

  • Page 131: Figure 6-7 Ipsec Phase 2

    H8922 3G/4G Router User Manual Figure 6-7 IPSec Phase 2 Figure 6-8 IPSec Company router server should have same setting but the identity and subnet setting for the company router server should be the opposite of those for H8922 3G/4G Router. Result After setting H8922 3G/4G Router and company router parameter, they can connect each other by IPSEC, and ping peer subnet, you could check status by click “view”...

  • Page 132: Timing Task

    H8922 3G/4G Router User Manual Figure 6-9 IPSec status ～ # ping 192.168.99.1 -I 192.168.86.1 PING 192.168.99.1 (192.168.99.1) from 192.168.86.1: 56 data bytes 64 bytes from 192.168.99.1: seq=0 ttl=255 time=1569.360 ms 64 bytes from 192.168.99.1: seq=1 ttl=255 time=769.937 ms --- 192.168.99.1 ping statistics --- 2 packets transmitted, 2 packets received, 0% packet loss round-trip min/avg/max = 769.937/1169.648/1569.360 ms 6.5 Timing Task...

  • Page 133: Figure 6-11 Router Online

    H8922 3G/4G Router User Manual Figure 6-11 Router online Figure 6-12 Router off line Figure 6-13 Router reboot ---END Hongdian Corporation...

  • Page 134: Faq

    H8922 3G/4G Router User Manual About this chapter Chapter Content 7.1 Hardware failure Possible hardware failure during using H8922 3G/4G Router and how to handle them 7.2 Dial online problem Possible problem during dialing and how to handle them 7.3 VPN Possible problem when connecting VPN 7.4 WEB config problem Possible WEB config problem and how to handle them...

  • Page 135: Ethernet Connection

    H8922 3G/4G Router User Manual Possible Reason  SIM slot damaged  SIM card wrong direction Solution  SIM slot damaged, please contact us to repair  Check the SIM card direction, please make sure the SIM goldfinger is up 7.1.3 Ethernet Connection Phenomenon LAN LED dark, cannot visit router WEB GUI...

  • Page 136: No Signal

    H8922 3G/4G Router User Manual Possible Reason  SIM card network type do not match  SIM charges owed  Power supply do not match  Modem setting wrong Solution  Change to a suitable SIM card  Recharge SIM card ...

  • Page 137: Compress Protocol Not Match

    H8922 3G/4G Router User Manual Possible Reason  Antenna connect wrong  Area signal weak Solution  Check the antenna and re-connect it.  Contact Telecom Operator to confirm signal problem  Change to high-gain antenna 7.2.5 Compress Protocol not match Phenomenon H8922 3G/4G Router dial failure, log shows compress protocol not match Possible Reason...

  • Page 138: Router Can Communicate But Subnet Cannot

    H8922 3G/4G Router User Manual Possible Reason  Router table config wrong  VPN peer server config wrong Solution  Add related Router table  Check VPN peer server setting 7.3.3 Router can communicate but subnet cannot Phenomenon Router can communicate but subnet cannot Possible Reason ...

  • Page 139: Backup Setting Problem

    H8922 3G/4G Router User Manual 7.4.2 Backup setting problem Phenomenon Router import backup setting failure Possible Reason  Backup setting file format wrong  No reboot after backup setting Solution  Choose a right file to import  Must reboot after import setting, then parameters available 7.4.3 Updating patch failure Phenomenon Updating fix patch failure, after updating, view fix patch and found no fix patch...

  • Page 140: Update Failure In Web Gui

    H8922 3G/4G Router User Manual 7.4.5 Update failure in WEB GUI Phenomenon Updating by WEB GUI, failed and cannot visit WEB GUI again Possible Reason Firmware oversize cause updating failure Solution Using CFE mode to update again, and router will restore to factory mode. If after CFE updating, still cannot visit WEB GUI, please contact us for repairing 7.4.6 Forget Router Password Phenomenon...
  • Page 141 Create smart things F14 - F16, Tower A, Building 14, No.12, Ganli 6th Road, Longgang District, Shenzhen 518112, China. +86-755-88864288-5 +86-755-83404677 hongdianchina www.hongdian.com sales@hongdian.com Hongdian_China...
