  • Page 1 H7932 3G Router User Manual Hongdian Corporation F5~6, Building 14, Shangsha Science & Tech Park, Binhe Blvd., Shenzhen, China Tel: +86-755-88864288 Fax: +86-755-83404677 : 518048 Postal Code www.hongdian.com www.mdtu.com Copyright © 1997-2012 Release 1.0.2...
  • Page 2 Manual Declaration Copyright All information in this user manual is protected by copyright law. Whereby, no organization or individual shall copy or reproduce the whole or part of this user manual by any means without written authorization from Shenzhen Hongdian Technologies Corporation. Trademark , Hongdian, GPRS DTU, MDTU, Hongdian Technologies, Shenzhen Hongdian and Galaxy are the trademarks and logos of Shenzhen Hongdian...
  • Page 3 H7932 3G Router User Manual CONTENTS CHAPTER 1 ABOUT THIS MANUAL ..............4 Purpose....................4 Applicable scope..................4 Version information................4 Convention ....................5 Technical support...................5 Acronym and term .................6 CHAPTER 2 Product Introduction ..............9 2.1 Galaxy 3G overview ..................9 2.1.1 Product appearance ................9 2.1.2 Other Accessories................11 2.1.3 Device installation .................11 2.2 Function and features................12 2.2.1 Hardware function.................13...
  • Page 4 This chapter briefly describes the function and role the this user manual has had, and gives the readers the information on how to read this user manual as the ® best guideline while Hongdian H7932 series products are installed and operated. Purpose Applicable scope...
  • Page 5 H7932 3G Router User Manual 1.4 Convention For reading and using this user manual fast and conveniently, the following conventions are reached for some abbreviations, icons, notes, security warnings and tips that appear in this user manual: Table -1.2: Convention Table Item Description Note...
  • Page 6 H7932 3G Router User Manual E-mail service: Technical support: support@hongdian.com Service service@hongdian.com Website and BBS service: Website: www.hongdian.com BBS: http://www.mdtu.com/forum/default.asp 1.6 Acronym and term In this user manual, the following acronyms and terms are used: Access Point Name Application Asynchronous Transfer Mode Auto Table Machine Authentication Centre Border Gateway...
  • Page 7 H7932 3G Router User Manual ETSI European Telecommunications Standards Institute GGSN Gateway GPRS Support Node GMSC Gateway MSC GPRS General Packet Radio Service Global System for Mobile Communications GPRS Support Node GPRS Tunneling Protocol GTP-id GTP Identity Home Location Register HSCSD High Speed Circuit Switch Data IGMP...
  • Page 8 H7932 3G Router User Manual Packet Control Function Packet Data Protocol Packet Data Network PDSN Packet Data Service Node PLMN Public Land Mobile Network Point of Sales PTM-G Point-to-Multipoint Group Call PTM-M Point-to-Multipoint Multicast Quality of Service Routing Area RADIUS Remote Authentication Dial In User Service Routing Information Protocol Register Service Center...
  • Page 9 H7932 3G Router User Manual CHAPTER 2 Product Introduction 2.1 Galaxy 3G overview Combining with the third generation of mobile communication technology and WLAN technology, Galaxy 3G mobile network data communication terminal product is designed as a high-tech 3G product upon the needs of users. It can provide data communication service for these users at any time and in any place.
  • Page 10 H7932 3G Router User Manual TWO SIM card slots Fig. 2.1.1-1: Front Panel The indicators on the front panel are described as the table below: Indicator State Description PWR： Power supply indicator, light, solid: normal RUN： Router status, blink slowly: works normal LAN1～5—LINK：...
  • Page 11 H7932 3G Router User Manual ANT：Antenna (SMA negative terminal) interface, which is able to match with standard short antenna, vehicular antenna or directional antenna; DEF：Reset button used for restoring the default parameters. DC：DC power supply interface. (Be sure to check if the voltage of power supply is consistent with the label on the router) LAN：10/100BaseT self-adapting Ethernet interface;...
  • Page 12 H7932 3G Router User Manual Galaxy H7932 3G Router can be placed in office, on wall or installed or fixed in any places, without special wiring and heat radiating requirements. To ensure the long-term and stable operation of system, grounding measures and dust-proof measures should be taken on power supply, keep ventilation and a proper room temperature.
  • Page 13 H7932 3G Router User Manual 2.2.1 Hardware function SYSTEM, NET, LAN indicators Factory default configuration restoration button Antenna interface: 50Ω/SMA negative end Serial data interface (DB9): RS-232(DCE) Serial data interface rate: 300 to 230,400 bits/s Ethernet interface: one 10/100BaseT/RJ45 self-adapting Configuration interface: WEB/Telnet or RS-232 2.2.2 Software function Supporting HSUPA/HSDPA/EDGE/GPRS or EVDO/CDMA 1x...
  • Page 14 H7932 3G Router User Manual Diagram chematic diagram for video application 2.3-1: S Application Mode Two: Application in SoHo There is one built-in 10M/100M self-adapting fast Ethernet port within H7932 3G Router, which greatly facilitates SoHo user getting access to the internet.
  • Page 15 H7932 3G Router User Manual H7932 3G Router is able to be connected to the target machine and other network devices at the same time. Take ATM network in the banking business for example. ATM machine needs to be connected to the host computer of bank, and at the same time, it is also connected to the video camera, and thereby monitoring the conditions around ATM machine.
  • Page 16 H7932 3G Router User Manual Computer with Ethernet card and TCP/IP protocol IE6.0 or higher Support 1024x768 resolution display 3.2.2 Connection method For your convenient use, we recommend you plug your SIM/UIM card into H7932’s card slot before your configuration. Then power on H7932 and begin your configuration. Upon the actual conditions, connect and configure Galaxy H7932 3G Router by the following two methods: Note:...
  • Page 17 H7932 3G Router User Manual 3.2.2.2 LAN connection method When it is required to connect Galaxy H7932 3G Router to local network through HUB or switch, connect the hub or switch out-link port with any one of its switch ports as shown in the figure below.
  • Page 18 H7932 3G Router User Manual ANT – antenna interface The standard 5OΩ/SMA radio-frequency connector (negative terminal) is adopted for use. In addition, the lightning-proof measures need to be adopted for some operating conditions, so you may place a lightning protection device between the connector and the antenna. Attention: The products shall be far away from any heating device;...
  • Page 19 H7932 3G Router User Manual Fig. 3.2.3-2: Computer Local Connection Configuration Select the “Internet Protocol (TCP/IP)”, click the “Properties”, and enter the interface as below:...
  • Page 20 H7932 3G Router User Manual Fig. 3.2.3-3: TCP/IP Properties Configuration Method 1: general configuration This method will temporarily interrupts the communication between the computer under configuration and LAN, and the specific parameter configuration is shown as below: IP address: 192.168.8.* (*indicates any integral between 2 to 254) Subnet mask: 255.255.255.0 Default gateway: 192.168.8.1 Remember:...
  • Page 21 H7932 3G Router User Manual The configuration operation is shown as below: Click the “Advanced (V)…”button in Fig. 3.2-5 to enter the interface as below: Fig. 3.2.3-4: Advanced TCP/IP Properties Configuration Click the “Add (A)”button under the “IP address (R)”, and fill in the IP address that you want to add: Fig.
  • Page 22 H7932 3G Router User Manual Note: As shown in Fig. 3.2-3, “Default gateway” depends on whether the configuration computer connects with Internet through original local network configuration. Internet is accessed through original local network, the default gateway setting does not need to be modified; if Galaxy H7932 3G Router + is used, you need to modify the default gateway and configure it as Galaxy H7932 3G Router’s default LAN IP address 192.168.8.1.
  • Page 23 H7932 3G Router User Manual And then you can enter user login identity authentication interface as shown below: Fig. 3.2.4-2: User Login Verification User should use default user name and password when log in for the first time: User name: admin Password: admin Input correct user name and password, and enter the WEB configuration interface.
  • Page 24 H7932 3G Router User Manual Drawing 3.3.1-1: System Configuration Window You can select the function and display the configuration window for the function after clicking on the related option on the top left corner of configuration window. Please see the following drawing: Menu Descriptions Drawing 3.3.1-2: Main Option Bar The options on the main option bar are as follows:...
  • Page 25 H7932 3G Router User Manual 3.3.2 Network When you click the “Internet” tab, the following sub-tabs appear on the page: Modem Parameter Select Connection Type DHCP Sever Fig. 3.3.2: Internet Configuration Tab 3.3.2.1 LAN In the “Local Network” main tab, click the “LAN” sub-tab to set the LAN port and enter the following configuration interface: Fig.
  • Page 26 H7932 3G Router User Manual Fig. 3.3.2.1-1: Modem 【Mod】: Modify the current settings. 【Del】: Delete current settings. 【En】: Enable/disable current settings. 【Add】: Add SIM ID. 【Auto-Dialup】: Set the account number of 3G network service provided by ISP. 【Interface Name】: Set the SIM card name. 【APN】: Set the APN of the internet access service provided by ISP.
  • Page 27 H7932 3G Router User Manual Note: This feature is special. It’s used to match with Parameter Select feature together. For example, if need to communicate with two different data servers via VPN tunnel. There is a priority for two VPN tunnel. So each tunnel need to bind one SIM ID. In the “Advanced setting”...
  • Page 28 H7932 3G Router User Manual Fig. 3.3.2.1-2: PPP Advanced Settings Considering the difference of mobile network authorization, the Point to Point Protocol connection should be compatible with different network. Advanced setting is used for the PPP special setting. Click “PPP Advanced Setting” button to start settings. Normally, it is not required to change the setting for most of networks and applications.
  • Page 29 H7932 3G Router User Manual Fig. 3.3.2.3: Parameter Select Interface Fig. 3.3.2.3-1: Parameter Select Interface 【Status】Enable/disable the parameter select feature. 【Rule Name】Set the rule ID from 0 to 9. 0 is the prepreerence. 【Interval】: Set the check interval. 【Retry Times】: Set the check times. 【Running Timeout】: Set the active time for current rule.
  • Page 30 H7932 3G Router User Manual ICMP mode means router will automatically check the specified destination IP as the interval and retry times. Once the ICMP is failed, router will automatically switch rule from current rule. 3.3.2.4 Connection Type In the “Internet” main tab, click the “Internet Connection Type” sub-tab to set the internet connection type.
  • Page 31 H7932 3G Router User Manual Fig. 3.3.2.5: DHCP Configuration Interface The configuration parameters include: 【DHCP Server】: Set whether enable the DHCP server function: Enable/Disable. 【IP Pool】: Set the range of the DHCP dynamic address pool as the default bro interface or customize the IP address range. 【Gateway Type】...
  • Page 32 H7932 3G Router User Manual Fig. 3.3.3: Applications Configuration Tab 3.3.3.1 ICMP Check In the “Applications” main tab, click the “ ICMP Check ” sub-tab to set the ICMP Check parameters and go to the following configuration interface: Fig. 3.3.3.1: ICMP Check Interface Trigger On-line Data parameters include: 【Destination IP or Domain】: Set whether enable the ICMP Check Service IP and domain name.
  • Page 33 H7932 3G Router User Manual Fig. 3.3.3.2: Interface Check 【Interface Name】: Set which interface will be check. 【Flow Direction】: the way to check data flow. 【Check Interval】: Set the interval of check. 【Retry Times】: Set the check times. 3.3.3.3 DDNS The router is designed with DDNS (Dynamic Domain System) function which can make others to search the dynamic IP address by internet domain.
  • Page 34 H7932 3G Router User Manual Fig. 3.3.3.3: DDNS Configuration Interface DDNS configuration parameters include: 【DDNS Server】: Set whether enable DDNS service function: Enable/Disable. 【Service Provider】: Select the DDNS service provider that router currently supports. Domestic DDNS service provider: 88IP (www.88ip.net), 3322 (www.3322.org); oversea DDNS service provider: DNSEXIT (www.dnsexit.com), ZONEEDIT (www.zoneedti.com), CHANGEIP (www.changeip.com), Dyndns (members.dyndns.org);...
  • Page 35 H7932 3G Router User Manual Fig. 3.3.3.4: DTU Interface DTU parameters include: 【DTU Service】: Set whether enable the DTU Service. 【Work Mode】 : Work as a Server or a Client. Client will register to server automatically. 【Local Port】: Set the receive port if work mode is server. 【Protocol:】: Select the protocol used to transmit.
  • Page 36 H7932 3G Router User Manual Fig. 3.3.3.5 SNMP 【SNMP Sevice】: Set whether enable the DTU Service. 【Port】: Set the SNMP port. 【Community】: Set the SNMP community. 3.3.3.6 M2M In the “Applications” main tab, click the “M2M” sub-tab to set the Timing Operation parameters and go to the following configuration interface: Fig.
  • Page 37 H7932 3G Router User Manual 【M2M Sevice】: Set whether enable the M2M Service. 【Server IP or Domain】: Set the server IP or domian. 【Server Port】: Set the server port. 【Login Times】: Set login max times. 【Heartbeat Interval】: Set the heartbeat interval for M2M connection. 【Retry Times】: Set the SNMP community.
  • Page 38 H7932 3G Router User Manual 3.3.3.8 Wake Up In the “Applications” main tab, click the “ Wake Up ” sub-tab to set the Trigger On-line Data parameters and go to the following configuration interface: Fig. 3.3.3.8: Wake Up Interface Wake Up parameters include: 【Wake Up Service】: Set whether enable the Wake Up .
  • Page 39 H7932 3G Router User Manual Fig. 3.3.4: VPN Interface When you click the “VPN” tab, the following sub-tabs appear on the page: VPDN Tunnel IPSec 3.3.4.1 VPDN Click the “Add” tab; the following sub-tabs appear on the page: Fig. 3.3.4.1-1: VPDN Interface...
  • Page 40 H7932 3G Router User Manual Fig. 3.3.4.1-2: VPDN Interface 【VPDN Service】: Enable/disable the VPDN Service. 【Interface Name】: Set the VPDN name. 【Protocol】: Select the VPN protocol for PPTP or L2TP. 【Server IP or Domain】: Set the VPN server IP or domain name. 【Username】: Set the username.
  • Page 41 H7932 3G Router User Manual Fig. 3.3.4.2-2: Tunnel Interface 【IP Tunnel Service】: Enable/disable the tunnel service. 【Tunnel Name】: Set the tunnel name. 【Tunnel Mode】: Select tunnel mode for ipip or GRE 【Local Virtual IP】: Set the local virtual IP of tunnel. 【Interface Type】: Select interface type of tunnel for interface or static IP.
  • Page 42 H7932 3G Router User Manual Fig. 3.3.4.3-1: IPsec Interface Click the “Add” tab; the following sub-tabs appear on the page: Fig. 3.3.4.3-2: IPsec Interface 【Select】: Select the IPSec phase 1. 【Policy Name】: Set the policy name in IPSec phase 1. 【Initial Mode】: Select IPsec mode for main mode or aggressive mode.
  • Page 43 H7932 3G Router User Manual Fig. 3.3.4.3-3: IPsec Interface 【Select】: Select the IPSec phase 2. 【Policy Name】: Set the policy name in IPSec phase 1. 【Encryption Protocol】: Select 【Encrypt】: Select IPSec encryption arithmetic. 【Hash】: Select IPSec Hash arithmetic. 【PFS】: Enable/disable PFS. 【Lifetime】: Set the lifetime in phase 2.
  • Page 44 H7932 3G Router User Manual Fig. 3.3.4.3-4: IPsec Interface 【Select】: Select the IPsec setting. 【Interface Name】: Set the IPSec name. 【Match Phase 1】: Select IPSec policy name for phase 1. 【Match Phase 2】: Select IPSec policy name for phase 1. 【Destination IP or Domain】: Set the peer IP or domain name.
  • Page 45 H7932 3G Router User Manual Fig. 3.3.5.1-1: NAT Interface Select the “NAT” option to go to the following configuration interface: Fig. 3.3.5.1-2: NAT Interface 【Select】: Select NAT or MASQ. 【Chain】: Select the NAT mode. 【Protocol】: Select the protocol for NAT mode. 【Source Address】: Set the source IP address.
  • Page 46 H7932 3G Router User Manual Fig. 3.3.5.2-1: Static Route Configuration Interface To add the static route, click the “Add” button and go to the following configuration interface: Fig. 3.3.5.2-2: Static Route Configuration Interface 【IP Address/Mask】: Configure the destination network address and mask of this static route.
  • Page 47 H7932 3G Router User Manual Fig. 3.3.6.1-1: IP Filter Interface You can choose filter type here: IP filter rules for Basic or Expand Select the “Basic” to go to the following configuration interface: Fig. 3.3.6.1-2: IP Filter Interface The configuration parameters include: 【Type】: Basic type is based on IP address filter.
  • Page 48 H7932 3G Router User Manual 【Wildcard Bits】: Configure the wildcard for source IP address or IP segments. 【Destination IP】: Set the source IP address of the filter rule, may be defined IP address or one IP segment. Specially, you must configure the initial IP of IP segment. 【Wildcard Bits】: Configure the wildcard for source IP address or IP segments.
  • Page 49 H7932 3G Router User Manual Fig. 3.3.6.3-1: MAC Filter Interface 【MAC】: Set the the MAC address. 【Default Action】: Select the action mode for accept or drop. 【Filter Mode】: Select the filter mode for input, forward or both. 3.3.7 System When you click the “System Tools” tab, the following sub-tabs appear on the page: Local Log Remote Log Clock...
  • Page 50 H7932 3G Router User Manual Fig. 3.3.7.1: Log View Interface Log view settings include: 【Local Log】: Set the type of log to be displayed. After selecting the log type, you can make the following operations: 【View】: Display log in the Log Table. 【Clear】: Clear the log in the Log Table.
  • Page 51 H7932 3G Router User Manual Fig. 3.3.7.2: System Log Management Interface The system log configuration parameters include: 【Local Log Status】: Set whether enable local log function: Enable/Disable. 【Remote IP or Domain】: Set the IP address/domain name of the remote server, generally the IP address of the PC that receives the log information.
  • Page 52 H7932 3G Router User Manual Fig. 3.3.8.3: Clock Configuration Interface The system clock configuration parameters include: 【Status】: Enable/disable the Clock service 【NTP Server IP or Domain】: Set the domain or IP address of the NTP server. 【NTP Sever Backup】: Set the backup NTP server IP address/domain. 【NTP Synch.
  • Page 53 H7932 3G Router User Manual Fig. 3.3.7.4: Account Interface The system clock configuration parameters include: 【Account Type】: Set the account based on Web. 【Account Level】 :Set the account authority. Admin authority can configure all features. Guest authority just can view all feature. 3.3.7.5 Network Test In the “System”...
  • Page 54 H7932 3G Router User Manual Fig. 3.3.7.5: System Reboot Interface 【Firmware Setting】:Upgrade firmware/patch . 【Backup Setting】:Import/export the configuration. 【Save】: Save the current configuration as default. 【Load】: Default the current configuration to default. 【View】: Check the current patch name in the router. 【Delete】:Delete the selected patch.
  • Page 55 H7932 3G Router User Manual 【LAN】: Display LAN port’s running information. 【Embedded Modem】: Display USB wireless network’s running information. 【Route Table】: Display the route table information. 【DHCP Client】: Display the DHCP Client information.
  • Page 56 H7932 3G Router User Manual Chapter 4 Frequently Asked Questions (FAQ) 4.1 Fault analysis Fault 1: All indicators are off. Check whether the cables are connected correctly. Meanwhile, check whether the power supply complies with the requirements. Galaxy H7932 3G Router’s label indicates the detailed requirements regarding the power supply voltage.
  • Page 57 H7932 3G Router User Manual C:\>ipconfig Windows IP Configuration Ethernet adapter local connection: Connection-specific DNS Suffix..: IP Address ....: 192.168.8.48 Subnet Mask .
  • Page 58 H7932 3G Router User Manual Appendix: Software Upgrade Description Upgrade tool description and operating instructions Galaxy H7932 3G Router is designed with the platform technology, whose software can be upgraded with the development of the communication and network technology. WEB upgrade: Galaxy H7932 3G Router supports the function of upgrading the firmware directly by importing the upgrade file via the WEB configuration interface.
