Shenzhen Hongdian Technologies Galaxy Mobile Router H7920 User Manual

Shenzhen galaxy mobile router user manual h7920
Hide thumbs Also See for Galaxy Mobile Router H7920:
Table of Contents

Advertisement

Quick Links

Download this manual See also: User Manual
Enlarged version
SHENZHEN HONGDIAN TECHNOLOGIES CO., LTD.
Mobile Data Communications

User Manual

Galaxy Mobile Router
(H7920)

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Galaxy Mobile Router H7920 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Shenzhen Hongdian Technologies Galaxy Mobile Router H7920

Summary of Contents for Shenzhen Hongdian Technologies Galaxy Mobile Router H7920

  • Page 1: User Manual

    SHENZHEN HONGDIAN TECHNOLOGIES CO., LTD. Mobile Data Communications User Manual Galaxy Mobile Router (H7920)
  • Page 2 MOBILE DATA COMMUNICATIONS Galaxy Mobile Router (H7920) User Manual Shenzhen Hongdian Technologies Co., Ltd. West F6, Building 201, Terra Science & Tech Park, Chegongmiao, Shenzhen 51840, China Tel: (755)88864288 Fax: (755)83404677 Postcode: 518040 Website: www.hongdian.com www.mdtu.com © Copyright 2006 M80-792001-01 Release 2.0.1...
  • Page 3 Abbreviations Access Point Name Application Asynchronous Transfer Mode Auto Table Machine Authentication Centre Border Gateway Border Gateway Protocol Base Station Controller Base Station System BSSGP BSS GPRS Protocol Base Transceiver System CDMA Code Division Multiple Access Call Detail Record Charging Gateway Function Command Line Interface Circuit Switch Data Digital Data Network...
  • Page 4 Register Service Center RTOS Real Time Operating System Real-time Transport Protocol Remote Terminal Unit RSVP Resource reSerVation Protocol SCADA Supervisory Control and Data Acquisition SGSN Serving GPRS Support Node Subscriber Identify Module Short Message Service SMSC Short Message Service Center SNMP Simple Network Management Protocol SIM Tool Kits...

  • Page 5: Table Of Contents

    Contents CHAPTER 1 INTRODUCTION ...1 1.1 GENERAL ...1 1.2 SYSTEM FEATURES ...2 1.3 SPECIFICATIONS ...3 1.4 TYPICAL APPLICATIONS ...4 1.5 TYPES DESCRIPTION ...7 CHAPTER 2 INSTALLATION...8 2.1 GENERAL ...8 2.2 OPEN BOX ...8 2.3 INSTALLATION AND CABLE CONNECTION...8 2.4 GROUND ...12 2.5 POWER SUPPLY ...12 2.6 CHECK THE MOBILE NETWORK ...13 CHAPTER 3...

  • Page 6: Chapter 1 Introduction

    Since Hongdian has many years experience of mobile data communication, it proves that Hongdian products are widely applied and work stably. Galaxy router is a dedicated ideal data transmission channel for industrial applications. The manual explains setup procedure of H7920 router and provides the system operation guide. Basic Features...
  • Page 7 Galaxy H7920 Mobile Router User Manual Enhanced Features Support multiple protocol conversion Support data center and network management Online detection and redial Online/Offline control Online/Offline controlled by user’s equipment Online/Offline triggered by user’s data Timing online/offline STK/UTK card special function configuration...
  • Page 8 Internet Internet Application 4: Mobile Network/PSTN backup Galaxy H7920 can be connected to mobile network, PSTN dialup network and Ethernet, those channels can be backup each other with the built-up backup function. Bellow diagram is a typical solution for finance application. At the normal situation, the transaction data generated by POS or ATM will be transmitted via GPRS/EDGE or CDMA 1X network.

  • Page 9: Chapter 2 Installation

    E-EDGE Network H7920 platform G-GPRS network * Z=Radio Module Manufacturer, n=Radio Module (can be null), i.e.: M2=Motorola G24 For Example: H7920-RGM2 -- Galaxy GPRS Router, built-in with Motorola G24 radio module. M80-792001-01 Chapter 1: Introduction Galaxy H7920 Mobile Router User Manual...
  • Page 10 Galaxy H7920 Mobile Router User Manual A valid GPRS/EDGE SIM card or CDMA 1X UIM card (Depends router type) Galaxy router should be placed on desktop, wall or any other fixed place. There is no special requirement for wiring and heating dispersion. However, it is...

  • Page 11: Ground

    Galaxy H7920 Mobile Router User Manual Connectors’ description: COM: Serial port (RS-232/485), serial data port or console port. RJ45: 10/100BaseT auto sense Ethernet interface. DC: DC power supply interface (+5VDC, +7.5V~+24VDC optional, check the label before power on.) RESET: Reset button, press and hold for 5 seconds to reset the Galaxy router back to its default factory configurations.

  • Page 12: Router Configuration

    SIM or UIM (depends your router type and network) and switch on power. Galaxy H7920 router “RUN” LED will light up. If “RUN” LED is flashing, it means the Galaxy is working normally. If the “LINK” LED is flashing, it means there are data stream input/out over router data port.

  • Page 13: Connection

    Galaxy H7920 Mobile Router User Manual Your PC Your PC Setup Correct Network Settings You may be required to configure your PC IP address and associated parameters after connecting the PC and router. You can set PC IP address “Obtain an IP automatically”...
  • Page 14 Galaxy H7920 Mobile Router User Manual Here, you can select “Obtain an IP automatically” or “Use the following IP address”. If Galaxy router is connected to your PC directly, it is possible to select “Obtain an IP automatically”. Galaxy router built-in DHCP server will assign an IP address to the connected PC.

  • Page 15: Router Status

    Galaxy H7920 Mobile Router User Manual Input user name: “admin” and password: “hongdian” It will display the main page “Welcome” if it is correct user name and password. Click “Start” button to continue the management. Click the “Start” button to display main menu.

  • Page 16: Online Help

    Galaxy H7920 Mobile Router User Manual Console Mode The Galaxy router RS-232 interface can configured for a data communication port or a Console port. The Console port is only used for factory testing and trouble shooting. 3.2.1 Router Status Click "Start"->"Router Status" menu, you will find Galaxy router operation main information including settings and inbound/outbound data traffic.

  • Page 17: System Tools

    Galaxy H7920 Mobile Router User Manual This is the detail operation instructions; all configuration and setting procedures have been described in the Online Help file. Additionally, clicking the item “Online Help” on the left of Help page, Galaxy router will connect to Hongdian website to check updates.
  • Page 18 Galaxy H7920 Mobile Router User Manual With the built-in with real time clock function, GALAXY router will be automatically synchronized with clock sources when it is powered on. For CDMA version, Galaxy router will be locked at CDAM network clock source.

  • Page 19: Network Setting

    Galaxy H7920 Mobile Router User Manual System Log Click "Start"->"System Tools"->"System Log" menu to start this page. There are two options: "Local Log": tick it on to log router operation information at router's memory. Hongdian does not recommend ticking it on at the normal operation.
  • Page 20 Galaxy H7920 Mobile Router User Manual Press "Save" button to store the modification. Reconnecting the host (or PC) after its IP address has been modified successfully. Mobile Network Configuration Those parameters should be configured in accordance with the information provide by the local service provider.
  • Page 21 Galaxy H7920 Mobile Router User Manual Normally, it is not required to change the setting for most of networks and applications. If it is necessary, please consult with the local mobile operator and try different settings. Dial Debug Info It is a useful tool to check detail dial-up information. Select this option if the router is unable to dial network, and send the dial-up information to Hongdian for trouble shooting.
  • Page 22 Galaxy H7920 Mobile Router User Manual SNMP: Enable or Disable, tick it to enable the SNMP function. It supports SNMP V1 and V2C (V3 ready) automatically. Set Community: Set the community name, such as "public". IP: Set the SNMP management IP address. Usually, it is the router LAN interface IP address.
  • Page 23 Galaxy H7920 Mobile Router User Manual NAT/NAPT Configuration Security Configuration Routing Table NAT/NAPT Configuration NAT is the abbreviation of Network Address Translation. It maps the out side IP address to a host or terminal in your LAN. It isolates unidentified data envelops to guard the LAN against hacker’s attack.
  • Page 24 Galaxy H7920 Mobile Router User Manual Security Configuration With the security configuration function, you can control data envelops security in/out your network. All outbound envelops are secured by this setting. Only envelops to NAT or DMZ hosts toward inbound direction are secured.
  • Page 25 Galaxy H7920 Mobile Router User Manual For Example: Network Network Network Network 192.168.2.11 192.168.2.11 192.168.2.11 192.168.2.33 192.168.2.33 192.168.2.33 192.168.8.1 192.168.8.1 192.168.3.1 192.168.3.1 192.168.8.22 192.168.8.22 192.168.3.44 192.168.3.44 With the route policy showing above picture, the data envelops must be transferred by gateway (192.168.2.33) if the transmitting data envelops are from host 192.168.8.22 to 192.168.3.44.
  • Page 26 Galaxy H7920 Mobile Router User Manual Data Service Center (DSC) DSC can be enabled or disabled. Default setting is "Enable". Type of Service There are two options: Client: The Galaxy router will act a client function to send data to the specified DSC.
  • Page 27 Galaxy H7920 Mobile Router User Manual Rate Setup serial port interface data rate: 300/600/1200/2400/4800/9600/19200/38400/57600/115200(BPS) Parity Select parity: None/Odd/Even Data Bits Setup data bits: 5/6/7/8bits Stop Bits Setup stop bits: 1 or 2bits Flow Setup flow control: None/Hardware/Software (Xon/Xoff) Operation Mode For industrial applications, requirements may be different from customer to customer.
  • Page 28 Galaxy H7920 Mobile Router User Manual Route Detecting: Detecting the destination host IP address, if there is no response at the set time interval and times, the router will switch over to the selected backup route. When the "Radio" is set to the default route and the backup routing function is enabled, we recommend setting the operator's gateway as the destination IP address for detecting.

  • Page 29: Power Supply

    3.3 CLI Operation Chapter 3: Router Configuration TFTP update H7920 is built-in with a tftp client. Operator can update the firmware via a TFTP sever. The latest version H7920 firmware has the tftp feature included. Download the tftp server at: http://www.hongdian.com/en/download/software.htm...

  • Page 30: Chapter 4 Operation Instruction

    1. Panel Indication 2. Operation 3. Trouble Shooting 4.1 Panel Indication There are four LEDs at Galaxy H7920 router front panel; it indicates the router and network operation status. Status Blinking (data detected) Connected 10BaseT device and data transmission detected...

  • Page 31: Appendix 1: Hypertext Terminal Setting

    Galaxy H7920 Mobile Router User Manual (Note: Galaxy router’s LINK and PC’s Link should lights-up if it is connection). Check your TCP/IP setting. (Note: If the Galaxy router LAN IP is 192.168.8.1, your PC local connection IP address should be 192.168.8.xxx).
  • Page 32 Galaxy H7920 Mobile Router User Manual Appendix 1: Hypertext Terminal Setting The COM port parameters should be specified. Select COM number (i.e. COM2), Bites per second, Data bits, Parity, Stop bits and Flow control. Notice: “Flow control” should be set to “None”.

  • Page 33: Appendix 2: Firmware Update Tool

    Galaxy H7920 Mobile Router User Manual Appendix 1: Hypertext Terminal Setting 4. ASCII Setup Click “ASCII Setup” button, set ASCII parameters. M80-792001-01 Galaxy H7920 Mobile Router User Manual Appendix 2: Firmware Update Tool This appendix describes Galaxy router firmware update tool user instructions.
  • Page 34 Galaxy H7920 Mobile Router User Manual Press “Update” button to update the router firmware (Fig. 5) Waiting about 20 seconds, “Update success” info will appear. It means the router has been update successfully, otherwise it fails. Note: If you can not open the Galaxy router webpage after updating software, reconnect your PC local connection.
