User Manual

H8951-LQA Cellular Wi-Fi Router
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the H8951-LQA and is the answer not in the manual?

Questions and answers

Related Manuals for Shenzhen Hongdian Technologies H8951-LQA

Summary of Contents for Shenzhen Hongdian Technologies H8951-LQA

  • Page 1: User Manual

    User Manual H8951-LQA Cellular Wi-Fi Router...
  • Page 3 Hongdian Technologies Corporation. Trademarks and Permissions and DTU are the trademarks and logos of Shenzhen Hongdian Technologies Corporation. Other trademarks and logos mentioned in this manual belong to other organizations related. Shenzhen Hongdian Technologies Corporation does not own the rights of other trademarks and logos.

  • Page 4: About This Document

    ATM connection, remote office security connection, data collection. Etc. This document introduced how to use H8951 and its function features. Related Versions The following table lists the product versions related to this document. Model Version H8951-LQA/H8951/H8951/H7920/H7921 V30/V11/V12/V13 /H8922/H8922S Organization Chapter Description Features of H8951 3G 4G router and target market.

  • Page 5: Command Conventions

    H8951 3G 4G router Content Conventions Symbol Conventions The symbols that may be found in this document are defined as follows. Symbol Description Indicates a potentially hazardous situation, which if not avoided, could result in equipment damage, data loss, performance degradation, or unexpected results.

  • Page 6: Keyboard Operations

    H8951 3G 4G router GUI Conventions Convention Description Boldface Buttons, menus, parameters, tabs, window, and dialog titles are in boldface. For example, click OK. > Multi-level menus are in boldface and separated by the ">" signs. For example, choose File > Create > Folder. Keyboard Operations Format Description...

  • Page 7: Table Of Contents

    H8951 3G 4G router Content Content 1 Product Introduce ........................- 1 - 1.1 Overview................................- 1 - 1.2 Product positioning............................- 2 - 1.3 Function & Features............................- 2 - 1.4 Specification..............................- 3 - 2 Product structure ........................- 4 - 2.1 Hardware...............................
  • Page 8 H8951 3G 4G router 5.2.5 Parameter select..........................- 38 - 5.2.6 Connection Type............................38 5.2.7 Link Backup............................- 41 - 5.2.8 DHCP Service............................- 43 - 5.3 Application program configuration......................- 46 - 5.3.1 ICMP check............................- 46 - 5.3.2 DDNS configuration.......................... - 48 - 5.3.3 SNMP configuration (Optional)......................- 50 - 5.3.4 M2M configuration..........................- 52 - 5.3.5 Timing configuration.........................
  • Page 9 H8951 3G 4G router Content 6.1 Overview..............................- 110 - 6.2 Awake function(Option)..........................- 110 - 6.3 Parameter select............................- 111 - 6.4 VPN................................- 115 - 6.5 Timing Task..............................- 118 - 7 FAQ ............................ - 120 - 7.1 Hardware Failure............................- 120 - 7.1.1 All LED dark............................
  • Page 10 H8951 3G 4G router Table Content Table 2-1 H8951 3G 4G router size........................- 6 - Table 2-2 H8951 3G 4G router accessories......................- 7 - Table 4-4 LED instruction..........................- 13 - Table 5-1 LAN Parameter instruction........................- 24 - Table 5-2 WAN connection type parameter instruction...................- 25 - Table 5-3 “Modem”...
  • Page 11 H8951 3G 4G router Content Table 5-30 VPDN rule parameter instruction....................- 83 - Table 5-31 Tunnel rule parameter instruction....................- 85 - Table 5-32 IPSec Phase 1 Parameter instruction....................- 87 - Table 5-33 IPSec Parameter instruction......................- 89 - Table 5-34 IPSec Parameter instruction......................- 91 - Table 5-35 Remote log parameter instruction....................
  • Page 13 H8951 3G 4G router Figure Content Figure 1-1 Network structure..........................- 2 - Figure 2-2 H8951 3G 4G router Appearance....................- 5 - Figure 2-3 H8951 3G 4G router Figure......................- 7 - Figure 2-1 Front pannel............................- 8 - Figure 2-2 Back pannel............................- 8 - Figure 3-3 Pop out SIM slot..........................
  • Page 14 H8951 3G 4G router Figure 5-30 DDNS configuration........................- 49 - Figure 5-31 SNMP configuration........................- 51 - Figure 5-32 M2M configuration........................- 53 - Figure 5-33 Timing configuration........................- 54 - Figure 5-34 To add timing task......................... - 55 - Figure 5-35 Wake up configuration........................- 57 - Figure 5-38 IP Filter tab............................
  • Page 15 H8951 3G 4G router Figure 5-70 Network Test Tab...........................- 97 - Figure 5-71 Files tab............................- 98 - Figure 5-72 Add an IP address.......................... - 99 - Figure 5-73 CFE mode upgrading........................- 100 - Figure 5-74 CFE upgrading page........................- 100 - Figure 5-75 Backup setting page........................- 101 - Figure 5-76 Factory setting page........................- 102 - Figure 5-78 reboot............................- 103 -...

  • Page 17: Product Introduce

    H8951 3G 4G router 1 Product Introduce Product Introduce About this chapter Chapter Content 1.1 Overview Simple introduction of H8951 3G 4G router 1.2 Product Positioning Product Positioning of H8951 3G 4G router 1.3 Function & features Unique function & features 1.4 Specification Detail specification of this router 1.1 Overview...

  • Page 18: Product Positioning

    H8951 3G 4G router 1.2 Product positioning H8951 3G 4G router widely used in Telecom, economic, advertisement, traffic, environment protection business area. For example, in economic area, H8951 3G 4G router connect server by IPSec & GRE to ensure data security, and module online or switch to wan online ensured network availability. All these technology ensured safe and reliable data transmission, and minimize the probability of network disconnection, and maximize the usability of economic business like ATM, POS .etc.

  • Page 19: Specification

    H8951 3G 4G router 1 Product Introduce Available cellular network HSPA+/HSUPA/HSDPA/WCDMA/UMTS 2100/1900/1700/900/850/800MHz  LTE Band 2/4/12  1.4 Specification Interface 1×10/100Mb LAN interface  1×10/100Mb WAN/LAN interface(optional to customize RS232 console port and RJ45)  2× SMA-K antenna interface  1×...

  • Page 20: Product Structure

    H8951 3G 4G router Product structure About this chapter Chapter Content 2.1 Hardware H8951 3G 4G router hardware. 2.2 Structure Structure of H8951 3G 4G router . (2014-07-01) - 4 -...

  • Page 21: Hardware

    H8951 3G 4G router 1 Product Introduce 2.1 Hardware 2.1.1 Appearance & Size Appearance Figure 2-2 H8951 3G 4G router Appearance (2014-07-01) - 5 -...
  • Page 22 H8951 3G 4G router Size Table 2-1 H8951 3G 4G router size Model Dimension (mm) Interface H8951 3G 4G 100×98×23 1×10/100Mb LAN interface router 1×10/100Mb WAN/LAN interface 1× RS-232 console port(RJ45) 2× SMA-K antenna interface 1× Standard SIM/R-UIM interface 1× Standard DC power interface H8951 3G 4G router appearance as Figure 2-2, Figure 2-3 shows (2014-07-01) - 6 -...

  • Page 23: Accessories

    H8951 3G 4G router 1 Product Introduce Figure 2-3 H8951 3G 4G router Figure 2.1.2 Accessories Table 2-2 H8951 3G 4G router accessories Accessories name Number Note H8951 3G 4G router 1 pcs CD-ROM 1 pcs Optional 3G antenna 1 or 2 pcs According to module number inside RJ45 cable 1 pcs...

  • Page 24: Structure

    H8951 3G 4G router 2.2 Structure Figure 2-4 Front pannel 3G/4G(DIV) Antenna SIM Card Slot Figure 2-5 Back pannel 3G/4G Antenna RESET POWER LAN1 LAN2/WAN WiFi Antenna (2014-07-01) - 8 -...

  • Page 25: Installation Of H8951 3G 4G Router

    H8951 3G 4G router 1 Product Introduce Installation of H8951 3G 4G router About this chapter Chapter Content 3.1 Unpacking Unpack H8951 3G 4G router box and the packing list. 3.2 How to install How to install H8951 3G 4G router with SIM/UIM card and Ethernet cable .etc.

  • Page 26: Ethernet Cable Connection

    H8951 3G 4G router Before install SIM/UIM card, disconnect any power resource of the router. Use a small stick push the yellow button on router, the SIM slot will pop out as Figure 3-1 shows. Figure 3-6 Pop out SIM slot ---END 3.2.2 Ethernet cable connection Use Ethernet port directly connect H8951 3G 4G router and computer, or transferred by a...
  • Page 27 H8951 3G 4G router 1 Product Introduce Step 3 Power on H8951 3G 4G router , the LEFT SIM slot is SIM 1, take it as a example: After connect power 14s, router RUN solid light, means router system works ok. ...

  • Page 28: Before Config

    H8951 3G 4G router 1 Product Introduce Before config About this chapter Chapter Content 4.1 LED Status The meaning of LED status. 4.2 Local config How to local config H8951 3G 4G router . 4.3 Basic config Basic config & function. 4.1 LED Status There are LED on front panel of H8951 3G 4G router , they show how H8951 3G 4G router works.

  • Page 29: Local Config

    H8951 3G 4G router LED name Status Solid light: connect 3G ok Blinking slowly(0.5s): connect 2.5G network ok Blinking quickly(2s): dialing Dark：No module or no auto-dial Solid light: run ok 4.2 Local config Precondition Already power on H8951 3G 4G router ...
  • Page 30 H8951 3G 4G router 1 Product Introduce Step 3 Change or add a IP 192.168.8.* on your computer. (2014-07-01) - 15 -...
  • Page 31 H8951 3G 4G router Figure 4-8 Connection properties Figure 4-9 Internet protocol (TCP/IP) (2014-07-01) - 16 -...
  • Page 32 H8951 3G 4G router 1 Product Introduce You could change your IP address or add a IP address in Advanced setting. General configuration  This method will temporarily interrupts the communication between the computer under configuration and LAN, and the specific parameter configuration is shown as below: IP address: 192.168.8.* (*indicates any integral between 2 to 254) Subnet mask: 255.255.255.0...
  • Page 33 H8951 3G 4G router Login password: admin Advanced configuration  If you don’t want to interrupt local PC LAN communication and configure H8951 3G 4G router when the former network configuration exists, it is required add route (IP). The configuration operation is shown as below: Click the “Advanced…”button to enter the interface as below: Figure 4-10 Advanced TCP/IP Settings Click the “Add (A)”button under the “IP address (R)”, and fill in the IP address that you...
  • Page 34 H8951 3G 4G router 1 Product Introduce Figure 4-11 TCP/IP address After the configuration is completed, click the “Add”. By now the computer has a route to router H8951. Note: “Default gateway” depends on whether the configuration computer connects with Internet through original local network configuration.
  • Page 35 H8951 3G 4G router Network Check Step 4 IP configuration check Use the command of ipconfig to check whether the IP address is correctly set or added. You can enter DOS mode and key-in command: ipconfig, for instance: C:\>ipconfig Windows IP Configuration Ethernet adapter local connection: Connection-specific DNS Suffix.

  • Page 36: Basic Config

    H8951 3G 4G router 2 Product structure 4.3 Basic config Through this chapter, you could achieve basic function: visit internet. 4.3.1 Login WEB GUI Step 1 Run a Internet Explorer and visit “http://192.168.8.1/”, to enter identity page. Figure 4-13 User identity page Step 2 User should use default user name and password when log in for the first time: User name: admin Password: admin...

  • Page 37: Router Config

    H8951 3G 4G router 2 Product structure Router config About this chapter Chapter Content 5.1 Overview Enter H8951 3G 4G router WEB GUI to config 5.2 Network config Network config & function 5.3 Application Advanced function of router like timing operation, link backup .etc. 5.4 Security Security setting of H8951 5.5 Forward...

  • Page 38: Lan

    5.2.1 LAN LAN setting used to manage local area network PC which connect to H8951, make them could visit internet and the network segment connectivity normal. Step 1 Login H8951 WEB GUI. Step 2 Single click “Network > LAN”. Figure 5-14 LAN window Step 3 LAN parameter.

  • Page 39: Wan

    H8951 3G 4G router 3 Installation of H8951 3G 4G router After change the LAN IP, if page has no response anymore, please make sure your PC address is in the same network segment, or set a new IP to your PC to insure that. ---END 5.2.2 WAN Wired connect to Internet by static IP, DHCP or PPPoE.
  • Page 40 Parameter Details Operation Select DHCP get IP address from DHCP ”Connection Type”select”PPPoE” Service Name Configure PPPoE service WORD type, up to 64 characters,not name,which is usually blank,please refer to parameters used for identification regulation format and judgment between client and server, and is usually provided by the service side, while ADSL dial-up provided by your...
  • Page 41 H8951 3G 4G router 3 Installation of H8951 3G 4G router Parameter Details Operation Compression Disable  Protocol Field Whether compress Whether compress Negotiation  Compression IP address Disable  VJ TCP/IP Header Whether allow TCP/IP to communicate Negotiation  Compress by compressing VJ Disable...

  • Page 42: Modem

    5.2.3 Modem H8951 3G 4G router core function, connect Internet by cellular modem, H8951 3G 4G router support single modem single SIM, those three working type provide internet connection to customers. Usually 3G network bandwidth is 1～5Mbps, 3.5G up to 20Mbps. Step 1 Login H8951 WEB GUI.
  • Page 43 H8951 3G 4G router 4 Before config Figure 5-17 Modem page Input suitable parameter. Table 5-6 Modem Parameter instruction Parameter Details Operation Auto-dialup current modem, if all Enable  Auto-dialup modem auto-dialup disabled, router will Disable  not auto-dialup Interface Name Interface name, to identify this interface WORD type, up to 12 characters...
  • Page 44 Parameter Details Operation Network type force to 2.5G or 3G Network type Dropdown List WCDMA: auto  wcdma  edge  EVDO: auto  evdo  cdma  HSPA+ module force 3G means 3G auto, AUTO means 2.5G/3G auto PPP process advanced parameter, do Advance Setting Single click to show not suggest to modify the setting.
  • Page 45 H8951 3G 4G router 4 Before config Parameter Details Operation More Disable  Debug Enable PPP dialing log, default value is Negotiation  enable, in order to check more info about dialing, suggest no changing Disable  Peer’s DNS Auto get peer DNS when PPP dialing. Negotiation ...
  • Page 46 Figure 5-18 Modem Dialup (2014-07-01) - 32 -...
  • Page 47 H8951 3G 4G router 4 Before config Figure 5-19 Advanced setting Single click “save” icon to finish. Grey icon means enabled. (2014-07-01) - 33 -...

  • Page 48: Wlan

    ---END 5.2.4 WLAN H8951 3G 4G router provides WLAN AP, Station Client, Repeater three functions, through AP function, H8951 3G 4G router can provide wireless LAN hotspots; through Station client function, it allows H8951 3G 4G router access to other AP devices, such H8951 3G 4G router downlink machine can access the Internet via the AP connection;...
  • Page 49 H8951 3G 4G router 4 Before config Figure 5-21 Station mode configure interface Figure 5-22 Repeater mode configure interface (2014-07-01) - 35 -...
  • Page 50 Figure 5-23 Station/Repeater scan signal interface Step 4 “WLAN” configure parameter instruction, parameter instruction as Table 5-4. Table 5-7 WLAN parameter instruction Parameter Details Operation WLAN Status Enable or disable WLAN feature Dropdown List Enable  Disable  Basic Setting SSID WLAN server identity WORD type, max to 32Bytes...
  • Page 51 H8951 3G 4G router 4 Before config Parameter Details Operation interference occur, automatically jump out interfere to work with the smaller channel Bandwith Bandwith configure when WLAN Dropdown List work at 802.11n 20MHz  40MHz  40MHz represents highspeed mode AP Isolate AP isolate the WLAN client, so Dropdown List...

  • Page 52: Parameter Select

    Parameter Details Operation 26 bits hex digits  shared Password connected to WLAN Configure according to the previous "Encryption" result wpa/wpa2（WiFi Protected Access) Algorithms Encryption algorithms Dropdown List tkip   Share WLAN encryption key, used to WORD or Number type, refer to connect the specified SSID "Parameter Specification Table"...
  • Page 53 H8951 3G 4G router 5 Router config Figure 5-24 parameter select Step 3 Add, modify, del, enable and disable the parameter select rule.  Figure 5-25 add rule Table 5-8 Parameter instruction Parameter Details Operation Enable  Status For enabled rule: Only one rule is Disable ...

  • Page 54: Connection Type

    Parameter Details Operation failed, next rule start running For disabled rule: all related interface also disabled Basic settings Rule name Name value decided running order Value area ：[0,9] Interval/Retry Check interval and retry time, if all Value area ：1～512 Times check failed, switch to next rule Units: seconds/time Default: 60/3...

  • Page 55: Link Backup

    H8951 3G 4G router 5 Router config Figure 5-26 Connection type window Table 5-9 Connection type Parameter instruction Parameter Details Operation Work mode Gateway: IP data transfer with MASQ Dropdown List Router: all IP data just transfer, no MASQ gateway ...
  • Page 56 Step 1 Login H8951 WEB GUI. Step 2 Single click “network > Link Backup”. Figure 5-27 Link Backup Table 5-10 Link Backup Parameter Parameter Details Operation Enable  Status Enable or Disable Link Backup feature Disable  Value area: 0-9 Rule Name Link Backup rule name identification Note:...

  • Page 57: Dhcp Service

    H8951 3G 4G router 5 Router config Parameter Details Operation Hot refers to the corresponding link  treatment enabled, the advantage of hot backup is switching fast, deficiency is when the link online will increase the cost of network overhead charges.
  • Page 58 Figure 5-28 DHCP Step 3 Configure DHCP parameter. DHCP parameter instructions as Table 5-8. Table 5-11 DHCP Parameter Parameter Details Operation Enable  DHCP Server Enable or Disable DHCP feature Disable  Basic Settings（DHCP is not recommended configure in the case of no special network requirement) Dropdown List IP Pool...
  • Page 59 H8951 3G 4G router 5 Router config Parameter Details Operation start IP address Format：A.B.C.D/Mask Example：192.168.8.2 End IP When pool select custom Manual input configuration, configure the DHCP pool Format：A.B.C.D/Mask end IP address Example：192.168.8.254 Dropdown List Gateway DHCP client access gateway IP source, Type divided into default, br0, eth0, custom Default value：default...

  • Page 60: Application Program Configuration

    5.3 Application program configuration Based on years of customers experience for different applications, besides SNMP, DDNS, H8951 3G 4G router has developed many functions for wireless network equipment, such as ICMP check, interface flow check function, M2M terminal management function, task management function and waking on demand function.
  • Page 61 H8951 3G 4G router 5 Router config Figure 5-30 ICMP adding page Configure the ICMP check parameter. Table 5-12 ICMP check rules Parameter instruction Parameter Details Operation ICMP check To enable or disable ICMP check Button service rules, multiple rules can be used Enable ...

  • Page 62: Ddns Configuration

    Parameter Details Operation Retry Check time interval and max check Value area ：1～65535 times/Normal failure times when link is OK, if check Unit: second/time interval failure times reaches the max times, then “timeout action ” will be executed, e.g “modem reset” Source Interface Router sends an ICMP detected Dropdown List options...
  • Page 63 H8951 3G 4G router 5 Router config Figure 5-31 DDNS configuration Step 3 Configure DDNS parameter. Table 5-13 DDNS Parameter instruction Parameter Details Operation DDNS Service Set whether enable DDNS Button service function Enable  Disable  Basic Config Service Provider Select the DDNS service Dropdown List options provider that router currently...

  • Page 64: Snmp Configuration (Optional)

    Parameter Details Operation User Set user name/password of Normal WORD type/CODE type, max name/Password the DDNS service registered 64 bytes in the service provider User Domain Set the domain of the DDNS Normal WORD type, max 64 bytes service provided by the service provider Update Interval Set the interval of the DDNS...
  • Page 65 H8951 3G 4G router 5 Router config Figure 5-32 SNMP configuration Step 3 Configure SNMP parameter. Table 5-14 SNMP Parameter instruction Parameter Details Operation SNMP service To enable or disable SNMP service Options: Enable  Diable  Basic Config Port SNMP port, suggest to be default Value area: 1～65535 port161...

  • Page 66: M2M Configuration

    Parameter Details Operation configuration successfully, the router Diable  reported Trap IP packet source address is the loopback address, If the "Loopback Status" to "Disabled" means router IP packet source address for the LAN port address Step 4 Single click “save” icon to finish SNMP configuration. MIB for SNMP can be downloaded from our website, if necessary, please contact our technical engineers.
  • Page 67 H8951 3G 4G router 6 FAQ Figure 5-33 M2M configuration Step 3 Configure M2M parameter . Parameter instruction is shown. Table 5-15 M2M Parameter instruction Parameter Details Operation M2M service To enable or disable M2M function. Button This function shall be used with our Enable ...

  • Page 68: Timing Configuration

    Parameter Details Operation Retry Times There is a retry mechanism for package Value area: 1～5 exchange between router and M2M Unit: seconds platform. When exchange times reach retry times, router will judge the exchange fails and usually no operation will be made Task Failure The time to judge an exchange fails, if Value area: 1～65535...
  • Page 69 H8951 3G 4G router 5 Router config Figure 5-35 To add timing task Step 4 Configure timing task parameter. Table 5-16 Timing task parameter instruction Parameter Details Operation Status To enable or disable a timing options task. Some task shall be Enable ...

  • Page 70: Wake Up Configuration(Optional)

    Parameter Details Operation offline (no dialing) for other time Schedule This is linux shell command. WORD type. Max 64 digits Usually suggested not to use it. In case of need, please contact our technical engineers Set time Time type Range or interval for status Dropdown List options: task or action task range...
  • Page 71 H8951 3G 4G router 5 Router config Step 2 Click “Applications > Wake up” to open “Wake up” tab. Figure 5-36 Wake up configuration Step 3 Configure “wake up” parameter. After finish “basic setting” parameter, click “save” to save it in the flash memory. Table 5-17 Wake up Parameter instruction Parameter Details...
  • Page 72 Parameter Details Operation Triggered action includes Task type Dropdown List options modem-up, modem-down, modem-down  reboot. modem-up  reboot  Basic setting Wake up method To configure actions triggered, it Dropdown List options supports phone and data. If choose phone/data ...

  • Page 73: Security

    H8951 3G 4G router 5 Router config One phone number be set for actions of different modems, but cannot be set as different actions of  one modem. It’s OK for SIM of H8951 3G 4G router to open SMS or voice function, no matter which slot to be ...
  • Page 74 Figure 5-37 IP Filter tab Step 3 In the forwarding filtering rules. Black List：The default allows packet forwarding, in line with the list of "discarded" rules  packet can not be forwarded through the router. White List：The default refuses packet forwarding, in line with the list of "accept" rules ...
  • Page 75 H8951 3G 4G router 5 Router config Figure 5-38 IP filter “Input” type Figure 5-39 IP Filter “Forward” type (2014-07-01) - 61 -...
  • Page 76 Table 5-18 IP filter parameter instruction Parameter Details Operation Type Select a filter type, you can choose Dropdown List options according to their needs, "Input" or "Forward" Input: whether to allow access to the router Forward: whether to allow the router forwarding Default Action The default action rule.

  • Page 77: Domain Filter

    H8951 3G 4G router 5 Router config Parameter Details Operation Destination Port IP packet access router ports (when the Value area: 1-65535 or protocol select "icmp", requires no [1-65535], it can be a range, configuration) or a single port When the IP Filter type select “Forward” Destination IP IP packet destination IP Manual input...
  • Page 78 Figure 5-41 Domain filter tab Table 5-19 Domain Filter parameter instruction Parameter Details Operation Domain keyword Keyword of domain for filter WORD type, max 64 digits. E.g. www.google.com, the keyword is “google”. Accept.  Default action Actions to filter the keyword Drop ...
  • Page 79 H8951 3G 4G router 5 Router config Figure 5-42 MAC Filter tab Table 5-20 MAC Filter explanation Paramete Details Operation Input configuration Blacklist: rules in blacklist cannot visit router,  Action To activate MAC other MACs can visit router. input filtering black Whitelist: rules in whitelist can visit router, other ...

  • Page 80: Forward Configuration

    Figure 5-43 MAC Filter configuration Table 5-21 MAC Filter Parameter instruction Parameter Details Operation Basic Settings MAC to be filtered WORD type MAC format: XX:XX:XX:XX:XX:XX Default Action Default actions of the rule. Can be To choose “accept” or “accept” or “Drop”: “Drop”...

  • Page 81: Nat

    H8951 3G 4G router 5 Router config 5.5.2 NAT DNAT configuration rule DNAT used to replace the destination address of packets accessing external network, router will replace the destination address of packet accessing external network into the user custom settings. Step 1 Log-on WEB GUI of H8951 3G 4G router .
  • Page 82 Figure 5-45 DNAT rule configuration Step 4 NAT Type select “DNAT”, Configure DNAT rule parameter. Table 5-22 DNAT Parameter instruction Parameter Details Operation Basic Settings Protocol Supports “TCP”, “UDP”, Select from Dropdown List “ICMP” or “ALL” Original Address The destination address of Dropdown List Type the IP packet needs to be...
  • Page 83 H8951 3G 4G router 5 Router config Parameter Details Operation Mapping address The new source address e.g. 192.168.8.1 after destination address is replaced Mapping port The port of destination Value area :1～65535 address after is replaced Step 5 Single click “save” icon to finish. ---END SNAT configuration rule SNAT is the source address translation, and its role is to translate source address of IP packets...
  • Page 84 Table 5-23 SNAT rule instruction Parameter Details Operation Dropdown List Protocol Convert some kind of protocol packets  into address   icmp  Original Address The source address need to be replaced Manual input Format1：A.B.C.D Format2: A.B.C.D/Mask Original Port The port of source address need to be Value area: 1-65535 or replaced...

  • Page 85: Static Routing

    H8951 3G 4G router 5 Router config Figure 5-47 MASQ configuration Step 4 Configure MASQ rule parameter. Table 5-24 MASQ rule Parameter instruction Parameter Details Operation NAT Type To select “MASQ” Select “MASQ” Interface Interface includes: Select from Dropdown List br0: use br0 interface as commutation ...
  • Page 86 is based on the destination address as an alternative route; while policy route is based on the source address that match with the policy to forward the packets (forwarding router detects the received packet's source address, and then according to the source that match the appropriate address of policy route to forward) and policy routing priority, use numbers 3 to 252 to differentiate, the smaller number with higher priority.
  • Page 87 H8951 3G 4G router 5 Router config Figure 5-50 Policy Routing Interface Parameter Instruction as Table 5-24. Table 5-25 Static Routing Parameter Instruction Parameter Details Operation Basic Setting Dropdown List Routing Type To select “Static Route”or“Policy Route” When Routing Type is “Static Route” Network Set the destination IP address and Manual input...

  • Page 88: Qos (Optional)

    Parameter Details Operation Interface  Network When source type is static route, Manual input need to manually set network Format1: A.B.C.D/Mask address Source Interface When source type is policy route, Dropdown List need to manually set source modem  network address of policy router eth0 ...
  • Page 89 H8951 3G 4G router 5 Router config Figure 5-51 QoS interface Step 3 QOS configuration parameter, configuration parameter instruction as Table 5-25. Table 5-26 QoS parameter instruction Parameter Details Option Status Enable or disable QoS feature Click the button to select Basic Setting Rule Name QoS rule name...

  • Page 90: Dynamic Routing(Optional)

    Parameter Details Option Format1: A.B.C.D/Mask Port The network interface of QOS Value area: 1-65535 You can not configure the port, if not the configuration represents all ports Rate Transmission rate of the network Value area：1～65535 address settings Units：Kbps Ceil Rate In ensuring the basic rate and the spare Value area：1～65535 bandwidth, the maximum bandwidth of...
  • Page 91 H8951 3G 4G router 5 Router config Figure 5-52 RIP interface Parameter Instruction as Table 5-26. Table 5-27 RIP Parameter Instruction Parameter Details Operation RIP Service Enable or disable RIP Service Click the button to select. Enable  Disable  Redistribute Enable or disable Redistribute Click the button to select.
  • Page 92 Figure 5-53 RIP route configuration interface Step 4 Configure RIP route parameter instruction,as Table 5-27. Table 5-28 RIP parameter instruction Parameter Details Operation Basic Setting Add Type Add the type of RIP route Click the button to select Add Type When it is “Network”,need to ...

  • Page 93: Ospf Configuration

    H8951 3G 4G router 5 Router config OSPF configuration OSPF (Open Shortest Path First) protocol is one of the (Interior Gateway Protocol), the most widely used IGP, for a single AS (autonomous system) in the routing decisions for large networks. OSPF business can be based whether the user needs to be configured at the factory H8951 3G 4G router .
  • Page 94 Parameter Details Operation Redistribute Enable or disable Redistribute Click the button to select Connected Connected Enable  Disable  Redistribute Enable or disable Redistribute Static Click the button to select Static Enable  Disable  Redistribute Enable or disable Redistribute Kernel Click the button to select Kernel Enable...
  • Page 95 H8951 3G 4G router 5 Router config AS Number Used to identify the network Manual input (only the routers with the Value area:[0,65535] same domain address can exchange routing information) When Add Type is “Neighbor”, Neighbor The router can reach in the Manual input next hop Format1: A.B.C.D/Mask...

  • Page 96: Vpn Configuration

    5.6 VPN configuration 5.6.1 Overview H8951 3G 4G router supports VPN (Virtual Private Network) including L2TP/PPTP/GRE/IPIP/IPSEC. What’s more, it supports VPN OVER VPN, e.g. GRE over IPSec, IPSec over PPTP/L2TP/GRE/IPIP. 5.6.2 VPDN configuration VPDN stands for Virtual Private Dial-up Networks. Now VPDN supports L2TP and PPTP Step 1 Log-on WEB GUI of H8951 3G 4G router .
  • Page 97 H8951 3G 4G router 5 Router config Figure 5-57 VPDN rule configuration Step 4 Configure VPDN rule parameter. Table 5-31 VPDN rule parameter instruction Parameter Details Operation VPDN service To enable or disable the VPDN rule Click “Enable” Basic Settings Interface name Name of this VPDN rule Cannot be modified after...

  • Page 98: Tunnel Configuration

    After a VPDN rule is added, router will build VPN communication with service address automatically. To see the tunnel status, click “View” in “Tunnel” tab. Figure 5-58 L2TP tunnel status ---END 5.6.3 Tunnel configuration Tunneling through a network infrastructure to transfer data between the network mode. The entire transfer process, the logic path encapsulated packet delivery over the public Internet through which called tunnel.
  • Page 99 H8951 3G 4G router 5 Router config Figure 5-59 Tunnel configuration Step 4 Configure Tunnel rule parameter Table 5-32 Tunnel rule parameter instruction Parameter Details Operation IP Tunnel To enable or disable IP tunnel Click “Enable” Service service Basic Settings Tunnel name Name of the tunnel, cannot be Input the name of tunnel...

  • Page 100: Ipsec Configuration

    Parameter Details Operation Local Extern This parameter will need to be set if Select from Dropdown List. interface “interface” is selected in “interface type”. Choose any connected interface as external interface Local extern IP This parameter need to be set if Format: interface type “static IP”...
  • Page 101 H8951 3G 4G router 5 Router config Phase 1 parameter Figure 5-61 IPSec phase 1 configuration Table 5-33 IPSec Phase 1 Parameter instruction Parameter Details Operation Basic Settings Select To select which phase of IPSec, Select “Phase 1” phase 1, phase 1 or phase IPSec Policy Name Name of phase 1, mainly to match To input the name of phase 1.
  • Page 102 Parameter Details Operation Hash Supports md5 and sha1 Select from Dropdown List Authentication To select authentication Select from Dropdown List, presently only “PSK” supported Pre Share Key To set pre share key Max 24 letters Self Identify To set the self ID of IPSec To input the ID, need to match the ID of other side Match Identify...
  • Page 103 H8951 3G 4G router 5 Router config Figure 5-62 IPSec phase 2 configuration Table 5-34 IPSec Parameter instruction Parameter Details Operation Basic Settings Select To select which phase of Select “Phase 2” IPSec, phase 1, phase 1 or phase IPSec Policy Name Name of phase 2, mainly to To input the name of phase 2.
  • Page 104 Parameter Details Operation To open or close PFS Select from Dropdown List Lifetime IPSec SA key life time Value area: 120～86400 Unit: second Transport Mode Supports tunnel, transport and Select from Dropdown List auto. Local Subnet Set local subnet No need to set for “transport” mode,only for “auto”...

  • Page 105: System Configuration

    H8951 3G 4G router 5 Router config Table 5-35 IPSec Parameter instruction Paramet Details Operation Basic Settings Select To select which phase of IPSec, Select “IPSec” phase 1, phase 1 or phase IPSec Interface Name of this phase Input name Name Match To select a matching name of...

  • Page 106: Remote Log

    Figure 5-64 Local Log tab Step 3 Select type of “Local Log” and then click “View” to see log. Click “Clear” to clear the log info in the “Log Table”, and click “Export” to export log in your local PC. There are 3 types log: Message: system log, to record the running log of router, usually for most of users.

  • Page 107: Clock

    H8951 3G 4G router 5 Router config Figure 5-65 Remote Log tab Step 3 Configure “Remote Log” parameter. Table 5-36 Remote log parameter instruction Parameter Details Operation Log Status To enable or disable remote log Click “Enable” Remote IP or IP address or Domain of remote log To input the IP address or Domain...
  • Page 108 Figure 5-66 “NTP” Time Synch. Figure 5-67 Manual Time Synch. Type Step 3 Set “clock” parameter . Table 5-37 Clock Parameter instruction Parameter Details Operation To click “Enable” or Status To enable to disable Time “Disable” Synchronization service Select “NTP” or “Manual” Time Synch.

  • Page 109: Account

    H8951 3G 4G router 5 Router config When select “NTP” in “Time Synch. Type” NTP Server IP or IP or domain of NTP server Select from Dropdown List Domain NTP Server Backup Backup NTP server Manual input server domain or IP address NTP Synch.
  • Page 110 Figure 5-68 Account tab Step 3 Set account parameter . Table 5-38 Account parameter instruction Parameter Details Operation Select from Dropdown List Account Type Visit the router on web Account Level Level of account to login router Select from Dropdown List Admin: can view and change the ...

  • Page 111: Network Test

    H8951 3G 4G router 5 Router config Step 4 Click “Save” to finish configuration. After saving, user needs to login again. ---END 5.7.6 Network Test Network Test This function includes Ping function and Trace router function. Step 1 Log-on WEB GUI of H8951 3G 4G router . Step 2 Click “System >...

  • Page 112: Files

    Parameter Details Operation from the router to destination Result Test result ---END 5.7.7 Files Firmware Setting H8951 3G 4G router supports upgrade firmware locally. Step 1 Log-on WEB GUI of H8951 3G 4G router . Step 2 Click “System > Files” to open “Files” tab. Figure 5-70 Files tab If “reset”...
  • Page 113 H8951 3G 4G router 5 Router config Step 3 Click “Browse” to select upgrading file and then click “Upgrade”. ---END CFE mode upgrading If upgrading file is larger than 6MB, CFE mode upgrading shall be used to upgrade. Step 1 Add an IP address 192.168.1. Figure 5-71 Add an IP address Step 2 Press the RESET/DEF interface.

  • Page 114: Backup Setting

    Figure 5-72 CFE mode upgrading Step 4 Click “Browse” to select upgrading file, and then click “Upload” to begin upgrading. Figure 5-73 CFE upgrading page Upgrading will need 4-6 minutes, if RUN light is on, upgrading is OK. You can also PING br0 address on your PC ( eg. ping 192.168.8.1 –t ). if Ping ok, upgrading is OK.

  • Page 115: Factory Setting

    H8951 3G 4G router 5 Router config Click “Browse” to select a configuration file to be imported. And then click “Import” to  resume the configuration as the configuration file. Click “Export” to export configuration file and save it in local PC. ...
  • Page 116 Figure 5-75 Factory setting page Save: to save the current setting as default factory configuration setting.  Load: to resume default factory setting.  reboot click “reboot” to restart the router. (2014-07-01) - 102 -...

  • Page 117: Status

    H8951 3G 4G router 5 Router config Figure 5-76 reboot 5.8 Status 5.8.1 Overview Status provides the basic info, network status info, router info of H8951 3G 4G router . 5.8.2 Base Information Step 1 Log-on WEB GUI of H8951 3G 4G router . Step 2 Click “Status >...

  • Page 118: Lan

    Figure 5-77 Base Information tab Table 5-40 Base information Parameter instruction Parameter Details Operation Router Model Router model info Router SN Router Serial No info Hardware Router hardware version info version Software OS and application software info. version 5.8.3 LAN Step 1 Log-on WEB GUI of H8951 3G 4G router .

  • Page 119: Wan

    H8951 3G 4G router 5 Router config Table 5-41 LAN Parameter instruction Parameter Details Operatio LAN status To shown current LAN interfaces status. IP address To show the LAN IP address. Subnet Mask Subnet mask of LAN interface. MAC address To shown the MAC address of the router.
  • Page 120 Figure 5-80 DHCP WAN status Figure 5-81 PPPoE WAN status Status Local IP Remote IP Table 5-42 WAN Parameter instruction Parameter Details Operatio WAN status To show the current WAN is used or not WAN Type To show the current WAN type Local IP To show the local IP of WAN interface Subnet mask...

  • Page 121: Modem

    H8951 3G 4G router 5 Router config Parameter Details Operatio PPPoE for WAN type Status To show the link status of WAN interface PPPoE Loca IP To show the router IP distributed by PPPoE Remote IP To show IP of PPPoE server 5.8.5 Modem Step 1 Log-on WEB GUI of H8951 3G 4G router .

  • Page 122: Routing Table

    Parameter Details Operatio Modem Status To show the Router’s status to link to the mobile network Network type Current network type of the SIM in use signal Signal of mobile network Value area: 1-31 IP Address To show the external network IP address which the router links To show which DNS router is using SIM Status...

  • Page 123: Reset Button Function

    H8951 3G 4G router 5 Router config Parameter Details Operation Static route Network IP address the router can reach Subnet Mask IP network the router can reach. It is used together with “Network” Gateway Next hop IP address which the router will reach interface Interface from router to gateway metric...

  • Page 124: Typical Application

    Typical application About this chapter Chapter Content 6.1 Overview Summary some typical application of H8951 3G 4G router 6.2 Awake function How to awake H8951 3G 4G router if not auto-dial 6.3 Parameter select Parameter switch to achieve SIM backup function 6.4 VPN H8951 3G 4G router VPN setting 6.5 Timing Task...

  • Page 125: Parameter Select

    H8951 3G 4G router 5 Router config Figure 6-84 Wake up/trigger setting example Effect By this setting, after router power on, if there are data trigger or you could call/SMS SIM1 or SIM2 number from 8618888888888 to trigger corresponding SIM online.ed modem will dial online, After 3600s, router will offline.
  • Page 126 parameters based on switching rules, multi-link switching and good communication ensures the reliability of the network. Parameter Select Let us check an example: Please set the “Parameter select” of modem separately Set rules as below Figure 6-85 Rules setting (2014-07-01) - 112 -...
  • Page 127 H8951 3G 4G router 5 Router config Figure 6-86 parameter select setting 1 Figure 6-87 parameter select setting 2 (2014-07-01) - 113 -...
  • Page 128 When L2TP link is working for some reason disconnected from the server, the router will perform parameter switching in Command "check icmp", through IP ping to detect whether router interrupt with network operators; after 3 IP ping fails, the router will switch to the PPTP link, connecting to maintain the server, continue to work.

  • Page 129: Vpn

    H8951 3G 4G router 5 Router config 6.4 VPN Introduction VPN, virtual private network, a technology based on Internet, now H8951 3G 4G router supports L2TP/PPTP/GRE/IPIP/IPSec of VPN. L2TP used to build a virtual private network, after H8951 3G 4G router connect to company NAS server, PC under H8951 could visit company network like visiting the local area network.

  • Page 130: Parameter Setting

    Parameter Setting Figure 6-89 IPSec Phase 1 Figure 6-90 IPSec Phase 2 (2014-07-01) - 116 -...
  • Page 131 H8951 3G 4G router 5 Router config Figure 6-91 IPSec Company router server should have same setting but with a reverse identity and subnet setting of H8951 3G 4G router . Result After setting H8951 3G 4G router and company router parameter, they can connect each other by IPSEC, and ping peer subnet, you could check status by click “view”...

  • Page 132: Timing Task

    6.5 Timing Task Typical Application H8951 3G 4G router support timing task, by setting timming task, at cretain time, router will operate reboot, online command. Etc. Easier the customer operation. I assume set the router online at certain time and keep a moment, then reboot every 24 hours. You could set like below.
  • Page 133 H8951 3G 4G router 5 Router config Figure 6-95 router off line Figure 6-96 router reboot (2014-07-01) - 119 -...

  • Page 134: Faq

    About this chapter Chapter Content 7.1 Hardware failure Possible hardware failure during using H8951 3G 4G router and how to handle them 7.2 Dial online problem Possible problem during dialing and how to handle them 7.3 VPN Possible problem when connecting VPN 7.4 WEB config problem Possible WEB config problem and how to handle them config problem...

  • Page 135: Sim Slot

    H8951 3G 4G router 5 Router config 7.1.2 SIM Slot Phenomenon Cannot insert SIM card Possible Reason SIM slot damaged  SIM card wrong direction  Solution SIM slot damaged, please contact us to repair  Check the SIM card direction, please make sure the SIM goldfinger is up ...

  • Page 136: Dial Online Problem

    7.2 Dial Online Problem 7.2.1 Dial discontinue Phenomenon H8951 3G 4G router discontinue during dialing, dial failure Possible Reason SIM card network type do not match  SIM charges owed  Power supply do not match  Modem setting wrong ...

  • Page 137: Poor Signal

    H8951 3G 4G router 5 Router config Solution Replace SIM card  Re-install SIM card  7.2.4 Poor Signal Phenomenon H8951 3G 4G router no signal or poor signal Possible Reason Antenna connect wrong  Area signal weak  Solution Check the antenna and re-connect it.

  • Page 138: Vpn Cannot Communicate

    Solution Make sure Modem is online  Set the correct port to VPDN  VPDN parameter wrong  Check VPDN peer server  7.3.2 VPN cannot communicate Phenomenon VPN already connect, but cannot communicate Possible Reason Router table config wrong ...

  • Page 139: Backup Setting Problem

    H8951 3G 4G router 5 Router config Possible Reason Auto reboot during updating H8951 3G 4G router  Power supply problem  Wrong firmware  Power off during updating router  Solution Check setting, disable the function which may cause reboot ...

  • Page 140: Update Failure In Web Gui

    Possible Reason Power supply do not match  Firmware version or format do not match  Power off during updating process  Solution If power supply do not match, please change then update again  If firmware version, format do not match, please change then update again ...

  • Page 141: Fcc Statement

    FCC Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications.
  • Page 142 Déclaration d'exposition aux radiations Cet équipement est conforme Canada limites d'exposition aux radiations dans un environnement non contrôlé. Cet équipement doit être installé et utilisé à distance minimum de 20cm entre le radiateur et votre corps.

This manual is also suitable for:

H7920H7921H8922sH8922H8951

Table of Contents
